PTS90X3X Series
PTS91X3X Series
PTS92X3X Series
120V/208V/240V AC Power Distribution Panel
60A - 125A Main Breaker
Suitable for Use as Service Equipment
Small Cell, Pico, Micro, CRAN or Macro
INSTALLATION GUIDE
Single SPD (L-G) per Leg or Dual SPD (L-N) per Leg, (N-PE)
PTS90X3X - 70A, 120V/208V/240V AC, 12 UL489 Breaker Positions
PTS91X3X - 100A, 120V/208V/240V AC, 16 UL489 Breaker Positions
PTS92X3x - 125A, 120V/208V/240V AC, 12, 16 or 20 UL489 Breaker Positions
1-888-820-3508
All Rights Reserved, 2020
www.pactechsol.com
www.pts5g.com
1
Advertisement
Table of Contents
Related Manuals for Pts PTS90X3X Series
Summary of Contents for Pts PTS90X3X Series
- Page 1 PTS90X3X Series PTS91X3X Series PTS92X3X Series 120V/208V/240V AC Power Distribution Panel 60A - 125A Main Breaker Suitable for Use as Service Equipment Small Cell, Pico, Micro, CRAN or Macro INSTALLATION GUIDE Single SPD (L-G) per Leg or Dual SPD (L-N) per Leg, (N-PE)
-
Page 2: Table Of Contents
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide Table of Contents Model Overview ..........................3 Figure 1: Dimensional Drawings....................4 Specifications ..........................5 1.2 Breaker Load Out Examples......................6 Application………………………………………………………………………………………..……..7 Features ............................7 Main Breaker..........................7 Distribution Breakers ........................7 Optional Surge Protection Device……………………………………………………………....7 Optional External Disconnect Switch ................ -
Page 3: Model Overview
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide 1.0 Model Overview The PTS9XX3X Series of Small Cell 120/240V AC Power Distribution Panels with optional External Disconnect Switch, provides a custom factory fully assembled load center for Small Cell, Pico, Micro, CRAN and Macro Deployments. The PTS9XX3X Series products are SUSE Rated: Suitable for Use as Service Equipment and conform to UL standards. - Page 4 PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide PTS9XX3X – Example of Dimensional Drawings PTS90X3X Models PTS92X3X Models Figure 1: Example Dimensional Drawings 1-888-820-3508 www.pactechsol.com All Rights Reserved, 2020 www.pts5g.com...
-
Page 5: Specifications
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide Ambient Derating of QOU Circuit Breaker 1.1 Specifications Electrical Specifications: 120/208/240V AC Panel Rating Phase Single Phase Load Center Breakers (12, 14, 16, 20 Pos.) UL489 2/0 – 14 awg, model specific Load Center Input 4 awg –... -
Page 6: Breaker Load Out Examples
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide Breaker Load Out Examples: Caution: Installation shall be completed per all NEC and Local Codes. Do not install PTS9000 Systems before reading and understanding all specifications and installation guides provided. -
Page 7: Application
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide 1.3 Application The PTS9XX3X are compact 120V/208V/240V AC Load Centers designed for Small Cell, Pico, Micro, CRAN and Macro Deployments where distribution of AC power is required. The PTS9XX3X Series of compact AC Load Centers can also be used for AC Power Distribution applications where limited space exists, excluding the ability to use a larger load center. -
Page 8: Inspecting And Unpacking
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide 3.0 Inspecting and Unpacking 3.0.1 Inspect the packaging for obvious signs of rough handling and/or external damage. 3.0.2 Review Installation Guide. 3.0.3 Remove from plastic packaging. 4.0 Installation The PTS9XX3X Systems are certified for outdoor installations. -
Page 9: Wiring Ground Connections
PTS9XX3X 120/240V AC Power Distribution Load Centers Installation Guide 4.4 Wiring Ground Connections 4.4.1 Ensure enclosure is grounded as per NEC and Local Jurisdictions Code requirements. 4.4.2 Ensure that the neutral buss bar is grounded per NEC and Local Jurisdictions Code if required. -
Page 10: Wiring Service And Load Connections
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide 4.5 Wiring Service and Load Connections 4.5.1 Wiring to be done in accordance with NEC and Local Jurisdictions Code. 4.5.1.1.Field conductors should be 70C copper minimum. 4.5.1.2 See QOU Breaker derating chart for proper operating ampacity on page 6. Wire the Service Ground to the internal ground bar 4.5.2 Wire the Service Neutral to Neutral bar connection according to use and Local... - Page 11 PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide Figure 4: Standard Wiring Space Example Caution: Installation shall be completed per all NEC and Local Codes. Do not install PTS90000 Systems before reading and understanding all specifications and installation guides provided.
- Page 12 PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide Figure 5: PTS9XX39 Series External Disconnect Switch Location ( Yellow/Red Rotary Switch) with Tag Out / Lock Out ( White Tab) Function Caution: Installation shall be completed per all NEC and Local Codes. Do not install PTS9000 Systems before reading and understanding all specifications and installation guides provided.
-
Page 13: Installation Review
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide 5.0 Installation Review Inspect the installation, verifying that all is in accordance with this document, NEC, and local Codes. Caution: Installation shall be completed per all NEC and Local Codes. Do not install PTS9000 Systems before reading and understanding all specifications and installation guides provided. -
Page 14: Document And Revision Control
PTS9XX3X Series Small Cell 120/240V AC Power Distribution Load Centers Installation Guide 6.0 Document and Revision Control Author Tom Cooleen 11/15/2019 Date File Location www.pactechsol.com Revision Control Issue Number 10/11/2020 Date Description PTS9XX3X Series Installation Guide Prime Contact 1 Name Email Phone Department / Responsibility...
