VCOM AX20-B Control Panel Installation Manual
Connecting Float and Pump wires to the Control Panel
Connect the wires coming from the recirc and discharge external splice boxes to the numbered
terminal points in the Control Panel. Refer to the appropriate Float & Splice Box Wiring Diagram for
the correct terminal locations for your system. For the AX20-B Control Panel the wiring is as follows:
Terminal Point No.
A Wiring diagram is provided with every control panel that is sold. Please reference the wiring
diagram provided with your panel if you have any questions or suspect that it differs from the
examples included in this document.
KEY POINTS:
● Voltage for the controls in the panel is always 120 VAC, although the pump voltage may
be 120 VAC or 240 VAC depending on the pump voltage.
● All wire nut connections should be tested by gently pulling on the wirenut, if the
connection is solid, the wire nut will not pull off. If the wire nut pulls loose, the
connection is not good and should be redone with a fresh, waterproof wire nut.
●
AQWA Inc. 1507 Drexel St. N, Wilson, NC 27893
1
2
3
4
5
6
11
12
13
14
15
16
Ground lugs
17
18
19
20
21
22
23
24
25
26
27
28
Float Function/Location on Float Stem
Recirc bottom float, Timer Enable/Redundant OFF
Recirc middle float, Override ON
Recirc HLA
Recirc Float neutral/commons
Recirc Pump Load wire (black)
Recirc Pump Neutral (white)
Discharge bottom float, OFF
Discharge middle float, ON
Discharge top float, HLA Override ON
Discharge Float neutral/commons (white)
Discharge pump load (black)
Discharge pump neutral (white)
Recirc and Discharge pump ground wires (green)
Spin Filter (If applicable)
Spin Filter (If applicable)
Field Flush (If applicable)
Field Flush (If applicable)
Zone1 (If applicable)
Zone1 (If applicable)
Zone2 (If applicable)
Zone2 (If applicable)
Zone3 (If applicable)
Zone3 (If applicable)
Zone4 (If applicable)
Zone4 (If applicable)
