- Page 1 BROME User Guide...
-
Page 2: Table Of Contents
BROME User Guide TABLE OF CONTENTS INTRODUCTION ……………………………………….…..………………………3 IMPORTANT PRECAUTIONS ……………………………………………………4 BEFORE DRIVING THE SCOOTER - pg. 4 CAUTIONS WHEN DRIVING - pg. 5 GENERAL SAFETY INFORMATION - pg. 6 CAUTION WHEN DRIVING ON INCLINES- pg. 6 CAUTION WHEN CLIMBING- pg. 7 ELECTROMAGNETIC INTERFERENCE AND WARNINGS - pg. -
Page 3: Introduction
Also, retain this booklet for future reference. In case of a serious incident with the product, you should inform the manufacturer and the competent authority in your country. If you have any questions, you can contact: info@movoevolution.com Tél.: 1-888-480-MOVO (6686) Granby, Québec Canada... -
Page 4: Important Precautions
Keep your weight toward the middle of the deck. Putting most or all of your weight on • the edge of the deck may cause an unstable condition. Only one person at a time could ride a Movo Mobility Scooter. Do not carry passengers • under any circumstances. -
Page 5: Cautions When Driving
BROME User Guide CAUTIONS WHEN DRIVING Please do the daily check before your journey always. (Refer to 6-1 Daily check.) • Do not extend your body over the mobility scooter. • Please make sure your safety when crossing the level crossing. •... -
Page 6: General Safety Information
BROME User Guide GENERAL SAFETY INFORMATION FOR SCOOTER Batteries should be fully charged before using for maximum performance and • longevity. (see section 5-2) The maximum load of the scooter is 350 lbs (160 Kg) . Do not exceed the maximum •... -
Page 7: Caution When Climbing
BROME User Guide CAUTIONS WHEN CLIMBING • The maximum height of obstacle and curb that scooter can climb is up to 10 cm (A). The maximum gap that scooter can drive over is • 15-20 cm (B). When driving scooter on ramp, adjust body •... - Page 8 BROME User Guide Mobility Scooter Electromagnetic Interference： Because EM energy rapidly becomes more intense as one move closer to the transmitting antenna (source), the EM fields from hand-held radio wave sources (transceivers) are of special concern. It is possible to unintentionally bring high levels of EM energy very close to the motorized scooter control system while using these devices.
-
Page 9: Product Overview
BROME User Guide PRODUCT OVERVIEW THE SCOOTER ITEM ITEM Rear Mirror Control Panel Emergency Hand Brake Front Turn Signal Tiller Angle Adjustment Lever Charging Port Front Basket Key Switch Headlight Tie-down Hooks Decorative Light Anti-Tipper Side Reflector Rear Reflector Seat fore-aft Adjustment Lever N-D Lever Seat Swivel Lever Brake Light... -
Page 10: Control Panel
Signal Right Turn Deceleration Horn Acceleration Signal Figure 5 - Sutton Control Press the Hazard lights button once to switch on, press again to Hazard Light switch off High / Low mode, see section 4-2 Hi/Lo Switch Press the turn signal button once to switch on, press again to switch... -
Page 11: Operation And Set-Up
BROME User Guide OPERATION AND SET-UP [H/L] Switch: Press H/L Speed button once, the High/Low Speed Indicator will light • on, means driving in high speed mode; Press again, the indicator will extinguish, means driving in low speed mode. (Hi/Lo speed will vary which depends on your current speed settings) H / L switch: Maximum speed can be 100% (Max) if [H/L] is set to "H"... -
Page 12: Operating Your Scooter
BROME User Guide [ ODO ] Odometer mode (Figure 13) : Range : 0~99999. • The odometer will be reset automatically to zero after the total distance • reaching 99999km (62149 mile). The odometer (hrs) will stop counting after reaching 99999hrs. •... - Page 13 BROME User Guide Horn : Press down the button to sound buzzer. Throttle : Pull the right throttle to move scooter forward. /Pull the left throttle to move • scooter backward. This can be reversed if required by local dealer. (Figure 10) •...
-
Page 14: Free-Wheeling (N-D Lever)
BROME User Guide Figure 15 Figure 16 FREE-WHEELING (N-D LEVER) • When lever is in Neutral (N) position, scooter can be moved manually without power. (Figure 17-2) When lever is in Drive (D) position, scooter can be driven. Normal position is D. (Figure •... -
Page 15: Disassembling Batteries
BROME User Guide Figure 21 Figure 19 Figure 20 DISASSEMBLING BATTERIES Release the battery velcro straps and disconnect the battery connectors to remove the batteries. Figure 33 Figure 34 Figure 35 Figure 26 Figure 27 Figure 36 Batteries are heavy, be careful when removing the batteries. Do not connect battery terminal [+] [-] with any metals to avoid danger. -
Page 16: Important Precautions
BROME User Guide IMPORTANT PRECAUTIONS BATTERY GAUGE Status Display Capacity >80 <8 <65 <50 <35 <25 <20 Check battery capacity before driving. Recharge the battery immediately when the red light is flashing as the remaining power can only keep scooter going for buffering 3km or less OPERATING THE CHARGER Batteries must be charged before using the scooter for the first time and should be recharged after each day use. -
Page 17: Information For Battery & Charger
BROME User Guide ‧If the Indicator (F) is off, check if the connection is secure, otherwise the battery may be defective. ‧If the Steady Red light doesn't turn Green, please remove the defective battery as it can't be charged. ‧If the Steady Red light turns Green immediately, the battery may be fully charged, otherwise please remove defective battery. -
Page 18: Care And Maintenance
BROME User Guide CARE AND MAINTENANCE DAILY CHECK Please always check your scooter before you start your every journey. Check point Inspection What to do if the inspection is failed N-D lever Check for correct function Contact your dealer. Horn Check for correct function Contact your dealer. -
Page 19: Monthly Check
BROME User Guide MONTHLY CHECK Check point Inspection What to do if the inspection is failed Seat / Check for movement and if Contact your dealer. Upholstery it’s worn Check if all the battery cables and connectors are firmly tighten to Electronics Contact your dealer. - Page 20 BROME User Guide Recommended range of storage, T emperature : -30 c ~ +50 c, Humidity : 25% ~ 85% Follow these easy steps to replace the tire : Turn off the scooter and remove the key. Make sure the lever is in D position before you lift the scooter.
-
Page 21: Other Information
BROME User Guide OTHER INFORMATION RECYCLING & DISPOSAL The equipment wrapping is potentially recyclable. The metal parts are used for scrap metal recycling. The plastic parts are used for plastic recycling. Electric components and printed circuit boards are disposed of as electronic scrap. Exhausted or damaged batteries can be returned to your medical equipment supplier. -
Page 22: Error Code
BROME User Guide ERREUR CODE Flash Description Initial check points The batteries have run out of charge. Recharge the batteries. • Low Battery Fault Check the battery and associated connections and wiring. • Battery voltage is too high. This may occur if overcharged and/or traveling down a long slope. -
Page 23: Technical Specifications
BROME User Guide TECHNICAL SPECIFICATION Overall Length 1400 mm / 55.1" Overall Width 680 mm / 26.8" Overall Height 1325 mm / 52.2" Front Wheels 330 mm / 13" Rear Wheels 330 mm / 13" Weight W/ Batteries 142 kg / 313 Ibs Max. -
Page 24: Warranty
For any warranty claim on an item deemed to be defective by both parties, Movo will, at its discretion, replace, repair or refund the defective item. The warranty begins upon receipt of the product by the retailer. Any damage or defect caused by misuse of the product is not covered by the warranty.
