- Page 1 ASSEMBLY MANUAL CHCFSP 4 Wheel Steer Combine Header Carrier HORST WAGONS 8082 Rd 129 Listowel, ON N4W 3G9 Canada 519-291-4162 1-866-567-4162 Fax 1-519-291-5388 sales@horstwelding.com www.horstwelding.com...
- Page 2 TABLE OF CONTENTS CHCFSP36, CHCFSP45 Included Parts (pg.1)--------------- 2 CHCFSP36, CHCFSP45 Included Parts (pg.2)--------------- 3 Step by Step Assembly Instructions------------------ 4 - 6 Adjustable Shoe Assembly Instructions--------------- 7 - 11 Spring Tongue Balancer------------------------------------ 12...
- Page 3 CHCFSP Included Parts (pg.1) Bolt List " x 6" bolts 2 - adjustable shoe " x 4 " bolts " bottom rail U-bolts assemblies 16 - " x 1 " carriage bolts " x 2" bolts " top rail U-bolts...
- Page 4 CHCFSP Included Parts (pg.2) Front Axle Rear Axle 2 - split top rail sections 36' = 18' section 45' = 22 ' section 1 - 357" bridged bottom rail 2 - 2" x 52" nylon straps 1 - diagonal 1 - Double Spring...
- Page 5 CHCFSP36, CHCFSP45 Model Step by Step Assembly Instructions STEP 1 : A. Install wheels. (Torque to 180 Lbs.-ft.) B. Bolt reach tubes between front & rear axles. Insert from top side and tighten nut on bottom. (repeat on opposite end) C.
- Page 6 STEP 3 : A. Pin vertical adjuster brackets to right bushing on top Top Rail Bracket of axles using 5/8" drawpins (single hole toward top). " Drawpin B. Secure diagonal channels to left bushings on top of axles, and top hole on vertical adjuster brackets, using 5/8"...
- Page 7 Step 5: A. Secure light bar to rear axle. B. Fasten fender light bracket to fenders with existing top 2 bolts. (The 2 red lights go on the back side of the rear fenders. The 2 amber lights go the the front side of the front fenders.) C.
- Page 8 Step 6: A. Assemble with 4 - " x 1 " bolts and nuts B. Assemble with 2 - " x 11" pins and hitch pins Step 7: Adjust shoe to desired option: Option 1: Base pad ideal for low pofile corn heads or combines with low lifting clearance. Follow these instructions for set up: Step A: Remove pins...
- Page 9 Option 2: Standard large pad for draper heads. Follow these instructions for set up: Step A: Remove pins and clips Step B: Swing 2 corn head plates 180 Step C: Reinstall pins and clips Step D: Locate pad on header carrier bottom rail to desired position...
- Page 10 Option 3: Highback pad for flex draper head. Follow these instructions for set up: Step A: Remove pins and clips Step B: Swing 2 corn head plates and large pad assembly 180 and reinstall longer pin and clip Step C: Position back extension here and reinstall shorter pin and clip Step D:...
- Page 11 Option 4: Low back pad for standard cutting platform. Follow these instructions for set up: Step A: Step B: Remove pins and clips Swing 2 corn head plates and large pad assembly 180 Step C: Position back extension here and reinstall longer pin and clip Step D: Reinstall shorter pin and clip...
- Page 12 Option 5: Standard corn head pad with low back. Follow these instructions for set up: Step A: Remove pins and clips Step B: Swing large pad assembly 180 Step C: Position back extension here and reinstall longer pin and clip Step D: Position corn head plates and reinstall shorter pin and clip...
- Page 13 Double Spring Tongue Balancer Kit Included Parts & Assembly Instructions Bolt to Tongue Bracket Bolt to Tongue Lift front of tongue at 45 angle to start eye bolts. Thread 5/8" nuts on eye bolts (approx. 2" - 3") until tongue can be lifted effortlessly. Parts List ITEM PART NUMBER...
