- Page 1 CT-X310 YZ(ST) CT-X325 YVJ(ST) CT-X320 YZ(ST),YVJ(ST) CT-X4100 YL(ST) CT-X4150 YL(ST) SERVICE MANUAL STEREO CAR CASSETTE RECEIVER BASIC TAPE MECHANISM : CDS-363AG1-A • Replace this Service Manual with ”Revision Publishing” when it is issued. S/M Code No. 09-003-339-1T2...
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST - 1 NOTE: The characters in the suffix column indicate the part usage. X310YZ ....XX........C....X325YVJ ....XX........D....X320YZ ....XX........E....X320YVJ ....XX........F....X4100YL ....XX........G..... X4150YL ....XX.........H.... REF.NO PARTS NO. DESCRIPTION SUFFIX 87-A11-179-010 CAP,E 10-16-105 D5*L11 KMF ABCDEFGH.... 87-A21-191-010 IC,KIA6225S ABCDEFGH.... - Page 3 ELECTRICAL MAIN PARTS LIST - 2 87-010-378-010 0E CAP, ELECT 10-16SME A....87-010-378-010 0E CAP, ELECT 10-16SME A....87-010-380-010 0E CAP,E 47-16 SME ABCDEFGH.... 87-010-380-010 0E CAP,E 47-16 SME ABCDEFGH.... 87-010-380-010 0E CAP,E 47-16 SME ABCDEFGH.... 87-010-380-010 0E CAP,E 47-16 SME ABCDEFGH....
- Page 4 ELECTRICAL MAIN PARTS LIST - 3 87-A70-175-010 1B VIB,XTAL 4.5MHZ AT-49 ABCDEFGH.... 87-A91-597-010 1B SW,RTRY SIM-026MT ABCDEFGH.... 8Z-KT1-633-090 1B CAP,E 3300U-16 PW ABCDEFGH.... 88-KTA-603-010 1C CONN,15P CAM-B68 ABCDEFGH.... 8Z-KT1-615-010 1C FLTR,AMORPHOUS -CHOKE ABCDEFGH.... CNA 202 8A-KT1-632-010 1D CONN ASSY,8P ISO-WHITE-A ..CDEF....
- Page 5 SCHEMATIC DIAGRAM-1...
- Page 6 SCHEMATIC DIAGRAM-2...
-
Page 7: Mechanical Parts List
MECHANICAL PARTS LIST - 1 NOTE: The characters in the suffix column indicate the part usage. X310YZ ....XX........C....X325YVJ ....XX........D....X320YZ ....XX........E....X320YVJ ....XX........F....X4100YL ....XX........G..... X4150YL ....XX.........H.... REF.NO PARTS NO. DESCRIPTION SUFFIX 87-KTE-205-010 SPR-C,EJ/FF/REW ABCDEFGH.... 88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABCDEFGH.... -
Page 8: Accessories List
ACCESSORIES LIST NOTE: The characters in the suffix column indicate the part usage. X310YZ ....XX........C....X325YVJ ....XX........D....X320YZ ....XX........E....X320YVJ ....XX........F....X4100YL ....XX........G..... X4150YL ....XX.........H.... REF.NO PARTS NO. DESCRIPTION SUFFIX 86-KT1-237-010 HLDR,REAR MTG ABCDEFGH.... 88-KT1-247-010 S-SCREW,HEXAGON ABCDEFGH.... 88-KT1-250-010 S-SCREW,THIN HEAD+2.6-4 BLK ABCDEFGH.... - Page 9 2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 931196...
