- Page 1 CT-X218 CT-X258 CT-X458 STEREO CAR CASSETTE RECEIVER • • TYPE BASIC TAPE MECHANISM CDS-36SCH-94 MODEL CODE : 88CD5-0137(S) SIMPLE MANUAL Replace this Service Manual with "Revision Publishing" when it is issued. S/M Code No 09-98B-301-4T1...
-
Page 2: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C504 87-010-053-080 CAP,E 1-50V C509 87-010-866-010 CAP,E 10UF-63V S3-320-622-564 IC,KIA6225S C510 87-010-377-010 CAP,E 3300UF-16V S3-375-373-E16 IC,LC75373E C602 87-015-682-040 CAP,E 22-16V 87-A20-599-010 IC,HA13154A<258,218> C603 87-010-248-040 CAP,E 220-10V 87-A20-876-010 IC,HA13158<458>... - Page 3 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION J801 S6-1MO-JB3-2B0 JACK,AUX HEAD C.B SW C.B...
-
Page 4: Accessories List
ACCESSORIES LIST REF. NO PART NO. KANRI DESCRIPTION 1 S7-0X8-147-201 IB<218> 1 S7-0X8-147-201 IB<258> 1 S7-0X8-147-201 IB<458> 2 S2-2X8-KT2-000 KEY,RELEASE 3 S2-2X5-KT4-000 REAR MOUNTING BRACKET 4 S0-9X6-KT1-000 CASE,PANEL 5 S2-050-654-091 NUT,5M 6 S1-850-031-520 SCREW,ST5-15 7 S3-309-005-203 SPR,WASHER M5 8 S0-650-651-014 SCREW,10-M5-10 9 S3-410-005-003 WASHER PLANE 10-5-0.5... -
Page 5: Mechanical Parts List
BTN-HRABS PRESET 1/2 A 87-067-643-010 SCREW,2-10 B/T 11 S5-8X8-KT3-001 BTN-HRABS SEL 12 S5-8X8-KT2-001 BTN-HRABS +/- B 87-255-073-410 SCREW,M2.6-6 B/M 13 S8-6X5-KT1-101 BADGE(AIWA LOGO)<258,218> C 87-353-034-210 SCREW,2-5 P/T 13 87-054-089-010 BADGE(AIWA LOGO)<458> D 87-253-072-410 SCREW,M2.6-5 PH E 87-745-094-410 SCREW,3-6 B/T/B 14 S0-0X8-KT1-001 F.PANEL-HRABS... - Page 6 SCHEMATIC DIAGRAM-1(X458)
- Page 7 SCHEMATIC DIAGRAM-2(X218,258)
- Page 8 SCHEMATIC DIAGRAM-3...
