- Page 2 Please comply with warnings operating instructions in this manual strictly. Save this manual properly and read carefully the following instructions before installing the unit. Do not operate this unit before reading through all safety information and operating instructions carefully.
-
Page 3: Table Of Contents
1.SAFETY PRECAUTION ..............................3 1.1 W ..............................3 SING BATTERY 1.2 W ................................4 HILE HARGING 1.3 W ..........................4 ISCHARGING THE ATTERY 2.PARAMETERS OF BATTERY ............................5 2.1 B ..............................5 ASIC LOCK IAGRAM 2.2 B ............................... 6 ATTERY PECIFICATIONS 2.3 P .................................. -
Page 4: Safety Precaution
1.Safety Precaution 1.1 When Using battery Danger of High Voltage： The high voltage power supply offer the equipment power, wet object contact high voltage power supply directly or indirectly , can cause fatal danger. Using a special tool : Working in high voltage and ac power, be sure to use a special tool instead of individual tools. Static‐free：... -
Page 5: While Charging
1.2 While Charging CAUTION The temperature range over which the battery can be charged is 0°C to 45°C. Charging the battery at temperatures outside of this range may cause the battery to become hot or to break. Charging the battery outside of this temperature range may also harm the performance of the battery or reduce the battery’s life expectancy. -
Page 6: Parameters Of Battery
2.Parameters of Battery 2.1 Basic Block Diagram • There are Battery cells and BMS board inside, before connecting the terminal, please read the diagram, and make sure the output is no short or other abnormal connection. Fig1 Battery Block Diagram... -
Page 7: Battery Specifications
2.2 Battery Specifications Battery Specifications Model NO. LFP300-48 Nominal Parameters Voltage Capacity 300Ah Energy 14.4KWh Dimensions(L*W*H) 600*1100*230mm Weight 158Kg Basic Parameters Design life time(25℃) 20 years Life cycles(80% DOD,25℃） 8000 Cycles Storage tiome/temperature 5 moths @ 25℃;3 moths @ 35℃;1 moths @ 45℃... -
Page 8: Panel View
Enclosure protection rating IP30 Electrical Parameters Operation voltage 51.2Vdc Max. charging voltage 57.6Vdc Cut-off discharge voltage 43.2Vdc Max. charge and discharging current 150A 2.3 Panel View Description Functional Description Battery + Positive terminal Battery - Negative terminal Metal Button Battery ON/OFF Button... -
Page 9: Led Indicators
Wheel Output ON/OFF ON/OFF LED Battery ON/OFF Indicator LED RST Key Reset Button Display Connection Address ADS Dialer 2 Road Dry Contacts RS485 Communication Port RS485 Communication Interface CAN Communication Port CAN Communication Interface RS232 Communication Port RS232 Communication Interface 2 Road RS485 Ports For Battery RS485 Communication Port Communication In Parallel... -
Page 10: Buzzer Operation (Optional)
Overcurrent protection Normal Flash 3 Alarm Flash 3 Flash 3 Over Discharge Stop discharge Discharg Protection Indication by SOC Temperature/ Over current Stop discharge /Short circuit protection Fault Stop charge & discharge NOTE: LED function can be set by monitor software, the default is on. Flash Flash1 0.25Sec... -
Page 11: Display Function Instruction
2.6 Display function instruction 2.6.1 Display rendering 2.6.2 Functional Specifications 2.6.2.1 Main menu page Electricity / dormancy activated, will show the welcome screen, press the MENU button to enter the main menu page. As shown in the figure below：... - Page 12 2.6.2.2 Battery parameters collection page When the cursor“》”is point to “Analog Info”，press ENTER key will enter into the page of “Analog Info”，As shown in the figure below： 2.6.2.3 Battery status page When the cursor“》”is point to “BMS Status”，press ENTER key will enter into the page of “BMS Status”，As shown in the figure below：...
- Page 13 2.6.2.4 Battery Parameters Setting page When the cursor“》”is point to “Para Setting”，press ENTER key will enter into the page of “Para Setting”，As shown in the figure below： 2.6.2.5 Battery System Setting page When the cursor“》”is point to “Sys setting”，press ENTER key will enter into the page of “Sys setting”，As shown in the figure below：...
-
Page 14: Connectors
2.7 Connectors Charge / Discharge connectors: to connect the positive pole (+) and negative pole (-) from the battery to the inverter via DC isolator. RS485: Active communication portal between battery and inverter. RS232: To get dynamic monitoring data of the battery from upper computer. RS485/CAN: To get dynamic monitoring data of the battery from inverter. -
Page 15: Tools
3.2 Tools The following tools are required to install the battery pack: • Wire cutter • Crimping Modular Plier • Screw Driver NOTE:Use properly insulated tools to prevent accidental electric shock or short circuits. If insulated tools are not available, cover the entire exposed metal surfaces of the available tools, except their tips, with electrical tape. -
Page 16: Installation Location
Mounting frame screw M8*70mm Power cable(1.5M) 6AWG Wire-M8 125A/1000V RS232 Communication Option Can monitor battery through upper software Cable Battery-Inverter Option Battery communicated with inverter Communication Cable 3.4.2 Installation Location Make sure that the installation location meets the following conditions: •... -
Page 17: Operating Intructions
4. Operating intructions 4.1 Software Installation For optional computer system protection, install battery monitoring software to fully configure battery shutdown and other setting value. 4.2 Pre-operation step Circuit breaker of battery circuit is set to OFF, connect it to switch power supply, and output voltage of switch power supply is set to 52.5-54V/56-57.6V, current set to 0.2C;... -
Page 18: Communication Function
4.3 Communication Function 4.3.1 Communication port definition RS485 Terminal Port Definition Pin1，8 RS485_B Pin2，7 RS485_A Pin3，6 Pin4，5 RS485 Communication Port Definition CAN Terminal Port Definition Pin4 CAN H Pin5 CAN L Pin7 Pin1,2,3,6,8 CAN Communication Port Definition RS232 Terminal Port Definition Pin3 BMS Transmit, PC Receive... -
Page 19: Battery Communicate With Pc/Software
4.3.2 Battery communicate with PC/Software 4.3.2.1 Single battery communicate with PC/software 4.3.2.2 Batteries parallel communicate with PC/software While battery in parallel communication , dial-up addresses of battery are different. Dial Switch Remark Address bit1 bit2 bit3 bit4 Battery 1 Battery 2 Battery 3 Battery 4 Battery 5... -
Page 20: Batteries Communicated With Inverter
…… …… …… …… …… …… Battery 14 Battery 15 The range of batteries’ address bit1-bit4 is 1-15. Note: For example:15 sets batteries in parallel communicated with PC/software as below: 4.3.3 Batteries communicated with inverter 4.3.3.1 Single battery communicate with inverter... - Page 21 Note: 1. If communicated with LUX inverter, please connected with RS485 port of battery. 2. If communicated with DEYE inverter, please connected with CAN port of battery. 4.3.3.2 Batteries parallel communicate with inverter While battery in parallel communication , dial-up addresses of battery are different. Dial Switch Remark Address...
-
Page 22: Troubleshooting
Battery 4 Battery 5 …… …… …… …… …… …… Battery 14 Battery 15 The range of address bit1-bit4 is 1-15. Note: For example:15 sets batteries in parallel communicated with inverter as below: 5. Troubleshooting If the battery does not operate correctly, please solve the problem by using the table below. Symptom Possible cause Remedy... -
Page 23: Storage And Maintenance
Alarm for protection when BMS show alarm, protect and Red LED Flashing when charging charging adjustment Red LED Flashing when Battery too low and will Charge battery immediately Discharging shutdown RED LED Lighting continuous Battery wrong Need to repair 6. Storage and Maintenance 6.1. -
Page 24: Product Responsibilities And Consulting
Batteries may cause electric shock and have a high short-circuit current. Please remove all wristwatches, rings and other metal personal objects before maintenance or repair, and only use tools with insulated grips and handles for maintaining or repairing. When replace the batteries, install the same number and same type of batteries. When replace the parallel batteries, make sure the new battery is full charged. - Page 25 Warranty Card Mr/Mrs./Ms/Miss:________________________________________________ Telephone Number:______________________________________________ Address:_______________________________________________________ ______________________________________________________________ E-mail:________________________________________________________ Purchase Date:___________/____________/___________ (DD/MM/YYY) Dealer's Name:__________________________________________________ Dealer's' Telephone Number:_______________________________________ Dealer's Address:________________________________________________ Serial Number:__________________________________________________...
- Page 26 MSDS UN38. 3 OHSAS ISO9001 ISO14001 OHSAS18001 www.solarwaysuppliers.co.za...
