4" STRAP-ON
ELECTRONIC
LOW PRESSURE METERS
OPERATION AND MAINTENANCE MANUAL
*MODEL FC101 FLOWCOM REGISTER INDICATOR-TOTALIZER
*ONE PIECE SEPARATOR/SPINDLE AND THREADED REVERSE THRUST BEARING CARTRIDGE
VISIT OUR WEBSITE:
MODEL
LP04D, LP12D, LP22D
PARTS LIST
FEATURING:
*CERAMIC BEARING CARTRIDGE
*STAINLESS STEEL SADDLE & U-BANDS
3255 WEST STETSON AVENUE
HEMET, CALIFORNIA 92545 U.S.A.
PHONE:
951-652-6811
FAX:
951-652-3078
www.mccrometer.com
30119-16
Rev. 4.9/07-09
Advertisement
Related Manuals for Water Specialties LP04D
Summary of Contents for Water Specialties LP04D
- Page 1 30119-16 Rev. 4.9/07-09 4” STRAP-ON ELECTRONIC LOW PRESSURE METERS MODEL LP04D, LP12D, LP22D OPERATION AND MAINTENANCE MANUAL PARTS LIST FEATURING: *CERAMIC BEARING CARTRIDGE *STAINLESS STEEL SADDLE & U-BANDS *MODEL FC101 FLOWCOM REGISTER INDICATOR-TOTALIZER *ONE PIECE SEPARATOR/SPINDLE AND THREADED REVERSE THRUST BEARING CARTRIDGE 3255 WEST STETSON AVENUE HEMET, CALIFORNIA 92545 U.S.A.
-
Page 2: Warranty
30119-16 Rev. 4.9/07-09 WARRANTY This Warranty shall apply to and be limited to the original purchaser consumer of any McCrom- eter product. Meters or instruments defective because of faulty material or workmanship will be repaired or replaced, at the option of McCrometer, free of charge, FOB the factory in Hemet, California, within a period of one (1) year from the date of delivery. -
Page 3: Installation
30119-16 Rev. 4.9/07-09 ELECTRONIC LOW PRESSURE METER ELECTRONIC LOW PRESSURE METER INSTALLATION INDEX I. UNCRATING. When uncrating the meter, any damage due to rough or improper handling should be reported to the I. UNCRATING transportation firm and McCrometer. If, for any reason, it is determined that the unit or parts of the unit should II. - Page 4 30119-16 Rev. 4.9/07-09 D. STRAIGHTENING VANES are recommended when PROPELLER REMOVAL can be accomplished by there are less than ten pipe diameters of straight pipe first removing the thrust bearing cartridge assembly (#5). (no fittings or obstructions) directly upstream from the Loosen the set screw (#27) in the side of the nose of meter location.
- Page 5 30119-16 Rev. 4.9/07-09 gearbox (#16). The clearance should be approximately SEPARATOR/SUPPORT SPINDLE ASSEMBLY .01” between the gearbox (#16) and trailing edge of the (#12) can be removed for replacement by removing the propeller when the propeller in pushed back (toward the four mounting screws (#13) which thread into the gear- gearbox).
- Page 6 30119-16 Rev. 4.9/07-09 FC101 (#34) and sensor (#15) should be checked to be sure they are connected and that the battery is good. Turn the propeller by hand at a fairly fast even speed and the indicator should display a flow rate. METER SADDLE O-RING (#22) should be inspected for any sign of damage and covered with a thin coat of silicone grease.
- Page 7 30119-16 Rev. 4.9/07-09 NOTES...
- Page 8 30119-16 Rev. 4.9/07-09 4” STRAP-ON LOW PRESSURE METERS MODEL LP04D, LP12D, LP22D PARTS LIST Description Part Number Model LP-22D Low Pressure Saddle Assembly none 7-LP22D-04 Propeller Assembly (Items 2 thru 8) 5-2425-‡-PT Propeller 3-2425-‡-P Set Screw, Nylon Point 1-1125-6 Screw, Bearing Cartridge Mounting...
- Page 9 30119-16 Rev. 4.9/07-09 6”-20” STRAP-ON LOW PRESSURE METERS MODEL LP04D, LP12D, LP22D *MODEL FC101 INDICATOR-TOTALIZER ASSEMBLY *CERAMIC BEARING CARTRIDGE PROPELLER *ONE PIECE SEPARATOR/SPINDLE & THREADED REVERSE THRUST BEARING CARTRIDGE References to 27-29 not used.
- Page 10 30119-16 Rev. 4.9/07-09 WARNING: BEFORE REMOVING THE METER SADDLE FROM THE PIPELINE THE WATER MUST BE TURNED OFF AND PRESSURE MUST BE RELIEVED FROM THE LINE. SERIOUS INJURY CAN RESULT FROM REMOVING A METER SADDLE UNDER PRESSURE.
