Canyon Series
Installation Instructions
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations, if
applicable.
• Do not mount near gas or electric heaters.
• Do not use outdoors.
• Do not let power supply cords touch hot surfaces.
• Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. If acid is spilled on skin
or in eyes, flush acid with fresh water and contact a physician immediately.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• The AC voltage rating of this equipment is specified on the product label. Do not connect equipment to any
other voltage.
• Do not use this equipment for other than intended use.
R
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS!
Technical Support
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Canyon Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Exitronix Canyon Series

  • Page 1 Canyon Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only.
  • Page 2: Table Of Contents

    Canyon Series Installation Instructions Table of Contents Specifications ..................................• Table 1 - Electrical and Physical Specifications ......................Receiving, Moving and Storing Systems and Batteries ....................• Shipping Damage ................................• Temporary Storage of Units and Batteries ........................Installation Requirements ..............................
  • Page 3: Specifications

    Canyon Series Installation Instructions Specifications Input Output • Minimum loading: None required • Time to transfer to inverter after a utility power failure: <1 second Battery Note: • Battery type: Maintenance-free sealed lead calcium • Battery charger: Fully automatic dual-mode with temperature compensation •...
  • Page 4: Receiving, Moving And Storing Systems And Batteries

    Installation Requirements Operating Environment Install the Canyon Series inverter system in a clean, cool, dry place with normal ventilation for human habitation and in such a location to hamper vandalism but allow easy access for testing and maintenance. Operating Temperature:...
  • Page 5: Cabinet Mounting

    Canyon Series Installation Instructions Cabinet Mounting Tools Required The following tools are required to install the system: Socket set, Phillips screwdriver, diagonal wire cutters, long nose pliers, electrical tape, digital Volt-Ohm meter, safety Mounting Hardware Mounting hardware is not provided. Care should be taken when selecting mounting hardware to assure that it is the proper type for the application and sized to safely support the system’s full weight when installed, assuring safe and...
  • Page 6: Ac Wiring Preparations

    Canyon Series CAUTION: To prevent electrical shock or equipment damage, for all units, make sure the Canyon Series battery is disconnected and the AC input circuit breaker at the service panel is OFF before making AC connections to the Canyon Series inverter system.
  • Page 7: Ac Input/Output Wiring Connections To Terminal Block

    Canyon Series Installation Instructions AC Connections, Continued AC Input/Output Wiring Connections to Terminal Block Depending on how the fixture load is to be operated, wire the system as described below: CAUTION: Legend...
  • Page 8 Canyon Series Installation Instructions AC Connections, Continued NOTE: Dimming switches S1-1 and S1-2 are designed for independent circuit...
  • Page 9: Battery Information

    Remove rings and metal wristwatches or other metal objects and jewelry. Do not carry metal objects in pockets where the objects can fall onto the batteries or into the Canyon Series inverter system.
  • Page 10 Canyon Series Installation Instructions Battery Information, Continued Battery Wiring CAUTION: To prevent possible damage to the unit when connecting batteries, verify that the unit battery circuit breaker CB-1 is in the OFF position. Table 2 - Battery Chart Model System...
  • Page 11: Battery Voltage Check

    Canyon Series Installation Instructions Battery Information, Continued Battery Wiring Diagrams Battery Voltage Check Using a digital Volt-Ohm meter, check for correct nominal battery voltage between DC input NEG and POS wires. Voltage...
  • Page 12: Final Installation Checklist

    System Start-Up Procedure IMPORTANT: The Canyon Series inverter system is a sophisticated electronic backup power supply. Care must be taken to follow the steps below in their exact sequence. Failure to do so may result in possible equipment failure.
  • Page 13: System Test

    Canyon Series Installation Instructions...
  • Page 14: Maintenance

    The Canyon Series system was designed with a front panel test switch to facilitate monthly testing. Simply depress the button and hold to test the inverter at any time. Once released, the Canyon Series will breaker at the service panel.
  • Page 15: Instructions For Self-Test/Self-Diagnostics

    Canyon Series Installation Instructions Instructions for Self-Test/Self-Diagnostics Once the unit is properly installed in accordance with the installation instructions and AC power is supplied to the unit, the indicates the unit’s status. A steady GREEN LED indicates normal service; A blinking GREEN/RED LED indicates the will be illuminated only during inverter operation initiated by the loss of utility power or during any manual or automatic self-test.
