Exitronix CP-EMW Series Installation Instructions

CP-EMW Series

Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

• Installation and servicing of this equipment should be performed by qualified service personnel only.

• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations, if

applicable.

• Do not mount near gas or electric heaters.

• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering

by unauthorized personnel.

• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

• Any modification or use of non-original components will void the warranty and product liability.

• Do not use this equipment for other than intended use.

• Allow battery to charge for 48 hours before first use.

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

Technical Support

Table of Contents

Do you have a question about the CP-EMW Series and is the answer not in the manual?

Page 1 CP-EMW Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: • DISCONNECT AC POWER SUPPLY BEFORE SERVICING. • Installation and servicing of this equipment should be performed by qualified service personnel only.
Page 2 CP-EMW Series Installation Instructions Wall Mount Fig. 1 Lens Cover aside. 4a. Wall Mount - Remove the center knockout and any desired knockouts for Housing knockouts on the supplied gasket. Apply the gasket to the back of the 4b. Wall Mount with conduit - Remove the desired knockouts on the backplate and the corresponding knockouts on the supplied gasket.
Page 3 CP-EMW Series Installation Instructions Pole or I-beam Mounting (Option) Fig. 4 POLE OR I-BEAM MOUNTING Note: The universal bracket is an accessory and needs to be ordered separately. Conduit Access Plug 1. Follow steps 1-4b under Wall Mount. Universal –...
Page 4 CP-EMW Series Installation Instructions Self-Test/Self-Diagnostics (G2) I M P O R T A N T: Once all emergency lamps have been connected to the unit equipment, apply normal AC power and Following installation and after AC power has been supplied, charge for 48 hours, then press and hold the test button until the LED indicator turns orange.
