Oregon Scientific BBL218 - Lullaby Music Player With Color Changing Nightlight Manual

INTRODUCTION

NOTE Please keep this manual handy as you use your new product. It contains practical step-by-step instructions, as well as technical specifications and warnings you should know.

  • This product should only be operated by an adult and should not to be used as a toy for children.
  • This product is not intended and should not be used as a replacement for responsible adult supervision; it only acts as a support for your child-caring purpose. Any type of liability beyond statutory warranty regulations or resulting from improper use of this product and/or use not in accordance with product warnings, precautions and instructions is excluded.
  • Please ensure that this product and adapter cables are always kept out of the reach of your child and at least 1 meter away.

OVERVIEW

FRONT VIEW

Front View

  1. Nightlight
  2. : Activates / deactivates nightlight
  3. SLEEP/: Sets sleep timer; enters clock setting mode
  4. : Turns soothing sounds ON / OFF and selects the sound
  5. PROG.: Programs CD play list
  6. /: Selects random play list or repeats song
  7. : Ejects CD
  8. +/-: Decreases / increases the volume
  9. /: Plays a song; turns the CD player ON; pauses a song
  10. : Stops a song; turns the CD player OFF
  11. /: Skips to previous / next song
  12. Speaker

BACK VIEW

Back View

  1. Adapter cable storage area
  2. Battery compartment
  3. AC adapter

LCD

LCD

  1. Programmed play list
  2. CD player mode
  3. Track number
  4. Soothing sound mode
  5. Clock / sleep timer display
  6. Random play list
  7. Repeats 1 or all songs
  8. Volume level
  9. Low-battery status

GETTING STARTED

POWER

The adapter should be used at all times.
Using the adapter

The batteries (4 x AA / UM-3 1.5V) are for back-up use only. Insert batteries matching the polarity (+ and -).
Inserting batteries

NOTE appears when batteries are low.

NOTE The unit will be RESET whenever the adapter is unplugged.

CD PLAYER

TIP: For optimal performance, make sure the unit is placed on a flat surface, such as a desk, that will not be affected by any sudden movement. If the product is subjected to force or shock, it may experience temporary skipping during sound playback.

The CD player can play CDR or CDRW discs.

CD FUNCTION BUTTON
Open CD player Press
Turn ON Press
Play Press when the CD player is turned on
Pause Press
Skip to previous / next song Press /
Stop Press
Turn OFF Press when no music is playing
Repeat 1 song, repeat all, or play songs in random order Press / repeatedly

To program a play list (when no music is playing):

  1. Press PROG. to enter program list.
  2. Press / to select a song and PROG. to confirm. Repeat this step to build a play list up to a max. of 32 songs.

To review and edit the play list:

  1. Press PROG. to review the program list (repeat this step to review up to a max. of 32 songs.
  2. Press / to edit the selected song and PROG. to confirm.

NOTE

  • Whenever the CD player is stopped the programmed play list will be deleted.
  • The Random feature is not available when using the program mode.
  • The CD will go into standby mode when it has not been used for 5 mins.
  • "OP" displays when you press and the cover opens.
  • "NO" displays when no disc is detected.

VOLUME

The volume range is from 0 (mute) to 20. Whenever you turn the CD player or soothing sound on, they will automatically go to their default setting (12 / 10 respectively).

To change the volume level, press + or -.

NIGHTLIGHT

The nightlight color display changes in different modes.

Nightlight mode: 1 of 7 static colors.

  • To turn the nightlight ON and select a color, press repeatedly until you reach the color you want.
  • Press and hold to turn the nightlight OFF.

CD mode: 7 colors are rotated.

  • Automatically turns on when CD plays.
  • Press and hold to turn the nightlight OFF.

Soothing sound mode: 2 similar colors gradually blend from 1 to the other e.g. for lullaby 1, orange and yellow will blend.

  • Automatically turns on when soothing sound plays.
  • Press and hold to turn the nightlight OFF.

SOOTHING SOUNDS / SLEEP TIMER

To select and play 1 of 12 soothing sounds:

  • Press repeatedly until you reach the sound you want; lullaby 1, lullaby 2, lullaby 3, bird, cricket, rain drop, brook, sea wash, TV white noise, vacuum cleaner, ticking clock or heartbeat.
    OR
  • Press , this will automatically activate the last setting you used.

To turn the soothing sound OFF:

  • Press and hold .

To set the sleep timer:

  • Press SLEEP repeatedly to set the unit to turn off after 15 -> 30- > 60->120 or 0 minutes. When 0 minutes is selected the sleep timer will automatically turn off after a few seconds.
    OR
  • Press SLEEP, this will automatically activate the last setting you used.

To turn the sleep timer OFF:

Press SLEEP until you set the sleep timer to "0".

CLOCK

To set the clock:

  1. Press and hold to enter the setting mode.
  2. Press + or - to change the setting. Press and hold + or - to speed through the values.
  3. Press to confirm a setting and move on to the next one. The clock setting sequence is: 12 / 24-hour format, hour and minute.

BACKLIGHT

The backlight will turn on for 8 seconds when any key is pressed.

PRECAUTIONS

This unit is engineered to give you years of satisfactory service if you handle it carefully. Here are a few precautions:

  • Do not cover the ventilation holes. Make sure items that are nearby such as newspapers, tablecloths, curtains, etc., cannot accidentally cover the ventilation holes. To ensure sufficient ventilation, there must be a minimum of 0.5 meters of open space around the apparatus.
  • Do not place any naked flame items, such as lighted candles, on the unit.
  • Do not immerse the unit in water.
  • Use a soft, slightly moistened cloth to clean the unit. Do not use abrasive or corrosive cleaning agents, as these may cause damage.
  • Do not subject the product to excessive force, shock, dust, temperature changes, humidity and direct sunlight for extended periods.
  • Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Use the apparatus in moderate climates. Do not use or store the unit in locations that may adversely affect the product such as rain, snow, moisture, dust or desert.
  • Do not tamper with the internal components. Doing so will terminate the product warranty and may cause damage. The unit contains no user-serviceable parts.
  • Remove the batteries when storing the product for a long time. Do not mix new and old batteries. Make sure you dispose of batteries at proper battery-refuse collection points.
  • The apparatus and AC/DC adapter should not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, should be placed on the apparatus.
  • To completely disconnect the power input, unplug the AC/DC adapter from the main power socket.
  • The AC/DC adapter should not be obstructed or be easily accessible during intended use.
  • Placement of this product on wood surfaces with certain types of finishes, such as clear varnish, may result in damage to the finish. Consult the furniture manufacturer's care instructions for direction as to the types of objects that may safely be placed on the wood surface. Oregon Scientific shall not be responsible for any damage to wood surfaces from contact with this product.

NOTE The technical specifications for this product and the contents of the user guide are subject to change without notice.

SPECIFICATIONS

TYPE DESCRIPTION
Clock time 12 or 24-hour format
CD play list Max. 32 songs
Volume 0 (mute) to 20
Nightlight 7 core colors
Soothing sounds 12
Sleep timer 15, 30, 60, or 120 mins
Adapter 7VDC 650mA
Battery type 4 x AA (UM-3) 1.5V
Unit dimension 160 mm (diameter) x 70 mm (depth)
(6.3 x 2.8 inches)
Unit weight 562g (19.8 ounces) without battery

NOTE The model number and rating information for the apparatus is located at the bottom of the enclosure.

ABOUT OREGON SCIENTIFIC

Visit our website (www.oregonscientific.com) to learn more about Oregon Scientific products such as digital cameras; MP3 players; children's electronic learning products and games; projection clocks; health and fitness gear; weather stations; and digital and conference phones. The website also includes contact information for our Customer Care department in case you need to reach us, as well as frequently asked questions and customer downloads.

We hope you will find all the information you need on our website, however if you're in the US and would like to contact the Oregon Scientific Customer Care department directly, please visit:

www2.oregonscientific.com/service/support
OR
Call 1-800-853-8883.

For international inquiries, please visit: www2.oregonscientific.com/about/international

EU-DECLARATION OF CONFORMITY

Hereby, Oregon Scientific, declares that this Lullaby Music Player with Color Changing Nightlight BBL218 is in compliance with the essential requirements and other relevant provisions of EMC directive 89 / 336 / CE and LVD directive 73 / 23 / EC. A copy of the signed and dated Declaration of Conformity is available on request via our Oregon Scientific Customer Service.

LIMITATION OF WARRANTY AND LIABILITY

Oregon Scientific provides warranty for products with manufacturing defects. A product which is: damaged, misused, abused, improperly used by user; used not in accordance with any product warnings, precautions or instructions mentioned in this Manual; used inconsistently with the technical or safety standards in force in the country where this product is used, or damaged due to leaky or defective batteries; used by children as a toy or placed less than 1 meter away from and within the reach of the child, is not subject to warranty/liability.
