! Tools supplied:

! Do not throw away packaging materials until assembly is complete.
! Assemble this item on a soft surface, such as cardboard or carpet, to protect fi nish.
! Proper assembly of this item requires 2 people.

Hardware

A
bolt M8 x 55 x8
C
spring washer x9
6231575/7162092 - 06/23/08
B
bolt M8 x 90 x1
D
fl at washer x9
monroe chair
Page 1 of 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the monroe chair and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for West Elm monroe chair

  • Page 1 ! Tools supplied: ! Do not throw away packaging materials until assembly is complete. ! Assemble this item on a soft surface, such as cardboard or carpet, to protect fi nish. ! Proper assembly of this item requires 2 people.
  • Page 2 1. Flip the seat frame over onto a clean table top. Insert the front legs into the bottom of the seat frame. 2. Align holes and insert bolt (A), spring washer (C), fl at washer (D). Do not tighten completely.
  • Page 3 3. Align back of chair with the seat frame, insert bolt (B), spring washer (C), fl at washer (D) in center hole. Insert bolt (A), spring washer (C), and fl at washer (D) into other 4 holes. Do not tighten completely.
  • Page 4 4. Flip chair upright and sit in it to be sure legs are seated properly. Flip chair back over and fully tighten all bolts. CARE INSTRUCTIONS Hardware may loosen overtime. Periodically check that all connections are tight.
