M-system R7D-DC16A Instruction Manual page 10

• Points of cautions applicable when wiring the R7D Series
To external apparatus
Keep the cable as
short as possible.
Motor
Drive Cable
Maintain distance between
cables and noise sources.
SEN TRONIC
Earth
Clamp
Remove a part of the shielded
cable cover and ground it
to the internal panel
plate using an earth
To external apparatus
Grounding in pig tail form
is not effective.
056 222 38 18 mailbox@sentronic.com
AG
Keep the wires away from
each other at both ends of
the filter.
Noise
Filter
Shielded
Cable
clamp.
www.sentronic.com
R7D-DC16A
EM-7802-G Rev.5 P. 10 / 10
