Installation manual
Disinfectant dispenser; non-contact; spray; for
the pole with diameter 34 mm
Ordering code: DD-MOL-006
Thank You for purchasing our product. Read this Installation manual carefully before the installation of the product.
Date: 24. 9. 2020
NM_DD-MOL-006_000_24092020_EN.doc
©MOLPIR 2020. All rights reserved.
Advertisement
Related Manuals for Molpir DD-MOL-006
Summary of Contents for Molpir DD-MOL-006
- Page 1 Disinfectant dispenser; non-contact; spray; for the pole with diameter 34 mm Ordering code: DD-MOL-006 Thank You for purchasing our product. Read this Installation manual carefully before the installation of the product. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc ©MOLPIR 2020. All rights reserved.
-
Page 2: Components List
Components list Po Po Pos s s s ..Item description Item description Item description Item description Ordering code Ordering code Ordering code Ordering code Pc Pc Pc Pcs s s s ① Disinfectant dispenser; non-contact; 600 ml; spray; white DD-MOL-000 ②... -
Page 3: Installation Procedure
Tools necessary for the installation • screwdriver Torx 20 • screwdriver Torx 25 • scissors Installation procedure Mount the brackets ④ with the screws ⑦. Place the dispenser on propper place. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 3/12... - Page 4 Mount the second screws onto brackets ⑦ and tight them evenly to assure the same gaps between the main bracket plate ③ and the brackets ④. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 4/12...
- Page 5 Cut the gaskets ⑥ at the indicated place on the gasket so that they can be fitted to the pole. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 5/12...
- Page 6 Place the gaskets ⑥ on the pole (2 pcs) on the upper and bottom side of the dispenser so that the gaskets fit exactly into the slots in the metal holder of the dispenser ③. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 6/12...
- Page 7 Place the rear cover of the dispenser ⑤ - first the lower side and then the upper side and check that the rear cover fits exactly into the grooves of the gaskets. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 7/12...
- Page 8 Use 6 screws ⑪ to firmly attach the back cover to the dispenser body. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 8/12...
-
Page 9: Preparation For Operation
Preparation for operation Use the key ②and open the front cover of the dispenser. Date: 24. 9. 2020 NM_DD-MOL-006_000_24092020_EN.doc Page 9/12... -
Page 10: Inserting Batteries
Inserting batteries Open the battery cover by pushing the latch in the direction of the arrow and then remove the battery cover. Insert 4 pcs new AA alkaline batteries so that the polarity of the inserted batteries matches the polarity markings on the dispenser control unit body. - Page 11 Pouring disinfectant Remove the cap of disinfectant tank and fill the reservoir with a suitable disinfectant. Then close the tank with the cap. Use a funnel for filling to prevent the disinfectant from spilling! Do not overfill the tank! The volume of the tank is 600 ml. Recommended disinfectant may contain max.
- Page 12 Dose volume setting Switch the main switch to position I or II to select the volume of each dose (position I is 0.5 ml; position II is 1.0 ml) and then close the front cover of the dispenser. This sets the dispenser to energy saving mode and it "waits" for the hands to approach the detection space under the dispenser nozzle.
