- Page 1 MHD-88SK/MHD-1010S/MHD-1616SK/MHD-2020S/ MHD-3636SK/MHD-3636S/MHD-7272S/ MHD-144144S Multi Format Digital Matrix System User Manual VER 1.0 Stock Code 873117 en.rgble.com 400-1661-021...
- Page 2 This manual is for user's operation guide only, not for maintenance service purpose. From the date of issue, any subsequent changes to the performance and technical parameters will be supplemented. Details can be obtained from our company or major distributors. Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 3: Table Of Contents
5.1 RS-232 communication port and connection methods......19 5.2 Matrix control software...............21 6. Technical Parameter...................22 6.1. Technical Parameter of Matrix Switcher...........22 6.2. Technical Parameter of I/O Cards..........23 7. Package Contents..................24 8. Appendix: Single Board Output Resolution Setting Table......24 Stock Code 873117 en.rgble.com 400-1661-021... -
Page 4: Introduction
◼ The matrix switcher available in I/O sizes: 8*8, 10*10, 16*16, 20*20, 36*36, 72*72, 144*144, fully covers the industry applications. ◼ Model range: MHD-88SK, MHD-1010S, MHD-1616SK, MHD-2020S, MHD-3636SK, MHD- 3636S, MHD-7272S and MHD-144144S, 8 Models of matrix switcher of touch screen series and key LCD series. - Page 5 IR signals can be transmitted alongside the video signal, allowing the remote device to be controlled without the need for additional cabling. Bidirectional control insertion eliminates the need for control system wiring to remote devices. Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 6: Schematic Diagram
3. Schematic Diagram 3.1 8 by 8 I/O Channels key LCD Interface 3.2 16 by 16 I/O Channels key LCD Interface Stock Code 873117 en.rgble.com 400-1661-021... -
Page 7: By 36 I/O Channels Key Lcd Interface
3.3 36 by 36 I/O Channels key LCD Interface 3.4 10 by 10 I/O Channels Touch Screen Interface Stock Code 873117 en.rgble.com 400-1661-021... -
Page 8: By 20 I/O Channels Touch Screen Interface
3.5 20 by 20 I/O Channels Touch Screen Interface 3.6 36 by 36 I/O Channels Touch Screen Interface Stock Code 873117 en.rgble.com 400-1661-021... -
Page 9: By 72 I/O Channels Touch Screen Interface
3.7 72 By 72 I/O Channels Touch Screen Interface Stock Code 873117 en.rgble.com 400-1661-021... -
Page 10: 144 By 144 I/O Channels Touch Screen Interface
3.8 144 By 144 I/O Channels Touch Screen Interface Stock Code 873117 en.rgble.com 400-1661-021... -
Page 11: Operation Controls And Functions
Key 0-9, to select input channel numbers Output Key Key 0-9, to select output channel numbers / Key To keep channel numbers apart ALL Key Widespread mode, i.e. all outputs are the same input signal Stock Code 873117 en.rgble.com 400-1661-021... - Page 12 Click the Navigation keys to 4.1.2.2.3 select the above mentioned three modes, refer to Figure Figure 3, Switching 3, Switching. （Note: This Matrix only supports ooee Stock Code 873117 en.rgble.com 400-1661-021...
- Page 13 ⚫ Click State key to enter to the Status Query Page ⚫ Click the OK key to view the current configuration details. ⚫ Click the Exit key to return to main menu. Figure 5, Status Query Stock Code 873117 en.rgble.com 400-1661-021...
- Page 14 Figure 6, Resolution Setting Error Correction 4.1.2.6 In case of inputting setting error, click ►key to move the cursor to the position to be modified, Click the Back key to delete the error, re-input the right one. Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 15: Touch Control Lcd Panel
Indicates Infrared control of central control module Touch Matrix setup and control (to wake up in-sleep screen please Click the Control panel screen to resume display) Input Board Insert signal input board Slot Output Board Insert signal output board Slot Stock Code 873117 en.rgble.com 400-1661-021... - Page 16 Figure 8, Switching Operation Page ⚫ LCD displays switching operation page by default ⚫ 4 Display Areas: ❶Status Display area: Display the operating temperature of the core chip board and the working status of the cooling fan. Stock Code 873117 en.rgble.com 400-1661-021...
- Page 17 ⚫ Click the corresponding save location key to save in where you want, (you can save plan in any of A, B, C, D). ⚫ Click the Take Key to save the switching plan ⚫ Click the Exit key to return to main menu. Stock Code 873117 en.rgble.com 400-1661-021...
- Page 18 ▲▼ drag the Scroll Bar, you can view the current state of the corresponding channel ⚫ Click the Exit key to return to main menu. Figure 11, Status Query Stock Code 873117 en.rgble.com 400-1661-021...
- Page 19 ⚫ Click the Take key, the screen will flip to the output display. ⚫ Tap the screen and return to the Preview screen. ⚫ Click the Exit key to return to main menu. Figure 13, Output Preview Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 20: Rs232 Tcp / Ip Control
Description RS-232 protocol for transmitting data RS-232 protocol for receiving data Signal earthing Figure 14, RS-232 Pins Table 4, Pins definition 5.1.3 RS-232 control interface and computer connection Figure 15, 5.1.3 RS-232 PC control connection Stock Code 873117 en.rgble.com 400-1661-021... - Page 21 Cat x wiring have two categories: direct connection and cross connection Direct connection: Both ends are connected according to T568B wiring order Cross connection: One end is connected according to T568A wiring order, while the other end is connected according to T568B wiring order. Stock Code 873117 en.rgble.com 400-1661-021...
-
Page 22: Matrix Control Software
5.1.7 The Matrix is connected to an ethernet switcher or hub over a direct connection Cat x cable (A few computers require cross connection cable) Figure 19, Matrix to PC via switcher or hub 5.2 Matrix control software Refer to: Matrix Controller-Matrix Control Software User Manual Stock Code 873117 en.rgble.com 400-1661-021... -
Page 23: Technical Parameter
Table 6, Technical Parameter of Matrix Switcher * The net weight of the matrix switcher does not include the weight of the input and output cards. The average weight of the cards is 0.1 kg Stock Code 873117 en.rgble.com 400-1661-021... -
Page 24: Technical Parameter Of I/O Cards
3Gbps, Backward compatible 1.5 Gbps HD-SDI high definition signal and SDI 3G-SDI clear video signal 400MHz(-3dB), Support 1920X1080p high definition all high-resolution signal 150MHz(-3dB), Support NTSC, PAL, SECAM, HDTV analog signal CVBS 150MHz(-3dB) Y’PBPR Table 7, Technical Parameter of I/O Cards Stock Code 873117 en.rgble.com 400-1661-021... -
Page 25: Package Contents
720X480i 60 DVI / VGA signal splicing output board (Factory default: 1920X1080p 60) 1920X1080p 60 1920X1080p 50 1680X1050p 60 1440X900p 60 1400X1050p 60 1366X768p 60 1280X1024p 60 1280X720p 60 1024X768p 60 Table 8, Output Resolution Setting Stock Code 873117 en.rgble.com 400-1661-021...
