RGBLE M01405 User Manual

18gbps 4k-60hz 4x4 hdmi hdbt matrix system with scaler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
P/N:M01405
18Gbps 4K@60Hz
4x4 HDMI HDBT
Matrix System with Scaler
User Manual
VER 1.0
Stock Code 873117
en.rgble.com
400-1661-021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M01405 and is the answer not in the manual?

Questions and answers

Related Manuals for RGBLE M01405

Summary of Contents for RGBLE M01405

  • Page 1 P/N:M01405 18Gbps 4K@60Hz 4x4 HDMI HDBT Matrix System with Scaler User Manual VER 1.0 Stock Code 873117 en.rgble.com 400-1661-021...

  • Page 2: Table Of Contents

    P/N:M01405 Thank you for purchasing RGBLE product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.

  • Page 3: Introduction

    P/N:M01405 4x4 HDMI HDBT Matrix System with Scaler 18Gbps 4Kx2K@60Hz 1. Introduction The 18Gbps 4x4 HDMI HDBT Matrix System with Scaler can connect four HDMI sources to eight displays. It features four HDMI outputs and each HDMI output is mirrored to provide a CAT-Cable output which runs simultaneously.

  • Page 4: Package Contents

    P/N:M01405 3. Package Contents ① 1 x 18Gbps 4x4 HDBT(150M) Matrix ② 4 x HDBT Receiver ③ 1 x Matrix IR Remote ④ 1 x 100~240V AC 50/60Hz Power cable ⑤ 1 x RS-232 serial cable (1.5 meters, male to female head) ⑥...
  • Page 5 P/N:M01405 Connection Inputs: 4 x HDMI Type A [19-pin female] Outputs: 4 x HDMI Type A [19-pin female] 4 × HDBT port [RJ45] 4 × Coaxial audio [3.5mm Stereo Mini-jack] Matrix 4 × balanced analog audio [5-pin Phoenix connector] Controls: 5 x IR IN [3.5mm Stereo Mini-jack] 5 x IR OUT [3.5mm Stereo Mini-jack]...

  • Page 6: Operation Controls And Functions

    P/N:M01405 5. Operation Controls and Functions 5.1 Matrix Panel Front Panel Name Function Description Display matrix switching status, input / output port, EDID, Baud rate, IP OLED screen Address. The LED will illuminate in green when the product is working normally, and Power LED red when the product is on standby.
  • Page 7 P/N:M01405 Rear Panel Name Function Description Connect to IR receiver cable, the IR receive signal will emit to the IR IN (1/2/3/4/ALL) ports “IR OUT” port of the HDBT Receiver. Connect to IR blaster cable, the IR emit signal is from the“IR IN”...

  • Page 8: Hdbt Receiver Panel

    P/N:M01405 5.2 Receiver Panel ports Number Name Function descriptions Power LED Red LED indicates that the receiver is powered on. DC 24V/1A power supply input port. Note that the extender supports POC function, it means that DC 24V either transmitter or receiver is powered on by 24V/1A power adapter, the other one doesn’t need power supply.

  • Page 9: Ir Remote

    P/N:M01405 6. IR Remote Power on or Standby: Power on the Matrix or set it to standby mode. Output1：Press 1/2/3/4 button to select input source to HDMI OUTPUT1. Output2：Press 1/2/3/4 button to select input source to HDMI OUTPUT2. Output3：Press 1/2/3/4 button to select input source to HDMI OUTPUT3.
  • Page 10 P/N:M01405 Figure 1: IR connection diagram (Matrix end) At HDBT receiver (Remote end): IR signal follows video switch to change. For example, the HDMI output signal on the HDBT Receiver 1 is from the HDMI INPUT 2 port, so IR input signal of the HDBT Receiver 1 will emit to IR OUT 2 port of the Matrix.

  • Page 11: Ir Cable Pin Assignment

    P/N:M01405 Figure 2: IR connection diagram (HDBT Receiver end) 8. IR Cable Pin Assignment Stock Code 873117 en.rgble.com 400-1661-021...

  • Page 12: Edid Management

    P/N:M01405 9. EDID Management This Matrix has 21 factory defined EDID settings, 2 user-defined EDID modes and 16 copy EDID modes. You can select defined EDID mode or copy EDID mode to input port through on- panel button, RS-232 control or Web GUI.

  • Page 13: Web Gui User Guide

    P/N:M01405 4K2K30Hz_444, Dolby/DTS 5.1 4K2K30Hz_444, HD Audio 7.1 4K2K60Hz_420, Stereo Audio 2.0 4K2K60Hz_420, Dolby/DTS 5.1 4K2K60Hz_420, HD Audio 7.1 4K2K60Hz_444, Stereo Audio 2.0 4K2K60Hz_444, Dolby/DTS 5.1 4K2K60Hz_444, HD Audio 7.1 4K2K60Hz, Stereo Audio 2.0 HDR 4K2K60Hz, Dolby/DTS 5.1 HDR 4K2K60Hz, HD Audio 7.1HDR...
  • Page 14 P/N:M01405 the Matrix. Step 3: Input the current IP address of Matrix into your browser on the PC to enter Web GUI page. After entering the Web GUI page, there will be a Login page, as shown below: Select the Username from the list and enter the password. The default passwords are:...
  • Page 15 P/N:M01405 ■ Status Page The Status page provides basic information about the product model, installed firmware version and the network settings of the device. ■ Video Page You can do the following operations on the Video page: ① Output: The current device’s OUTPUT port. You can select signal source for it.
  • Page 16 P/N:M01405 ⑥ Presets Clear: You can clear the saved audio-video matrix switching relationship. ■ Input Page You can do the following operations on the Input page: ① Inputs: Input channel of the device. ② Active: It indicates whether the channel is connected to a signal source.
  • Page 17 P/N:M01405 Download the EDID File for the Corresponding Input Channel Click the drop-down box of “Select EDID File” to select the corresponding input channel. Then click “Download” to download the corresponding EDID file. ■ Output Page You can do the following operations on the Output page: ①...
  • Page 18 P/N:M01405 ■ CEC Page You can perform CEC management on this page: ① Input Control: You can control the operation of each input source by pressing the icons on the page. (You can control multiple inputs simultaneously.) ② Output Control: You can control the operation of each display, such as power on/off, volume +/-, active source switching.
  • Page 19 P/N:M01405 Set the Default Network Click “Set Network Defaults” button, there will be a prompt, as shown in the following figure: Click “OK” to search the IP Address again, as shown in the following figure: After searching is completed, it will switch to the login page, the default network setting is completed.
  • Page 20 P/N:M01405 Note: Input rules for changing passwords: (1) The password can’t be empty. (2) New Password can’t be the same as Old Password. (3) New Password and Confirm Password must be the same. Modify Network Setting Modify the Mode/IP Address/Gateway/Subnet Mask/Telnet Port as required, click “Save”...

  • Page 21: Rs-232 Control Command

    P/N:M01405 ① Panel Lock: Click to lock/unlock panel buttons. “On” indicates that panel buttons are unavailable; “Off” indicates panel buttons are available. ② Beep: Click to turn on/off the beep. ③ LCD: You can turn on/off the LCD, and set the turn-on time (15s/30s/60s).
  • Page 22 P/N:M01405 The ASCII command list about the product is shown as below. ASCII Commands Serial port protocol. Baud rate: 115200, Data bits: 8bit, Stop bits:1, Check bit: 0 x - Parameter 1 y - Parameter 2 ! - Delimiter Command Code...
  • Page 23 P/N:M01405 Command Code Function Description Example Feedback Default Setting s lock z! Lock/Unlock front panel button, s lock 1! panel button lock on panel panel button lock off z=0~1 (z=0 lock off,z=1 lock button lock off r lock! Get panel button lock state...
  • Page 24 P/N:M01405 Command Code Function Description Example Feedback Default Setting s hdbt y stream z! Set hdbt output y stream on/off, y=0~4(0=all) s hdbt 1 stream enable hdbt output 1 enable z=0~1(0: disable,1: enable) stream s hdbt 0 stream disable hdbt output 1...
  • Page 25 P/N:M01405 Command Code Function Description Example Feedback Default Setting r edid in x! Get EDID status of the input x， r edid in 0! input1 EDID: 4K2K60_ x=0~8(0=all input) 444,Stereo Audio 2.0 input2 EDID: 4K2K60_ 444,Stereo Audio 2.0 input3 EDID: 4K2K60_ 444,Stereo Audio 2.0...
  • Page 26 P/N:M01405 Command Code Function Description Example Feedback Default Setting s cec hdmi out y vol-! set hdmi output y volume down by CEC, s cec hdmi out 1 hdmi output 1 volume down y=0~4(0=all hdmi output) vol-! s cec hdbt out y vol-!
  • Page 27 P/N:M01405 Command Code Function Description Example Feedback Default Setting r subnet! Get network subnet mask r subnet! Subnet Mask: 255.255.255.0 s gateway Set network gateway s gateway Set gateway: 192.168.1.1 xxx.xxx.xxx.xxx! 192.168.1.1! Please use "s net reboot!" command or repower device to...

  • Page 28: Application Example

    P/N:M01405 Application Example Stock Code 873117 en.rgble.com 400-1661-021...
