R-200WR
WIRELESS REARVIEW SYSTEM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R-200WR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BlackVue R-200WR

Summary of Contents for BlackVue R-200WR

  • Page 1 R-200WR WIRELESS REARVIEW SYSTEM...
  • Page 2 BLACKVUE R-200WR For manuals, customer support and FAQs go to www.blackvue.com...

  • Page 3: Important Safety Information

    Don't use voltages other than the input voltage. It may cause malfunction or fire. y Please disconnect the power cable if you will not be using the product for a long time. R-200WR...

  • Page 4: Fcc Compliance Information

    This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation of this device. FCC ID: YCK-R-200WR BLACKVUE...
  • Page 5 It is desirable that it be installed and operated with at least 20cm or more between the radiator and a person’s body (excluding extremities: hand, wrists, feet, and ankles). R-200WR...
  • Page 6 L’exploitation est autoriséee aux deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, méme si le brouillage est susceptible d’encompromettre le fonctionnement. IC: 23402-R200WR BLACKVUE...
  • Page 7 * Components of this product may be changed/modified without prior notice in order to improve product performance. * The Rearview system (R-200WR) is compatible with the front camera of DR750S-2CH and DR900S-2CH provided that the latest firmware is installed in the dashcam.

  • Page 8: Front View

    At a glance Wireless Rearview Kit (Receiver) - Top view Recording LED Pairing LED - Front view Pairing Button Wireless Rear Camera Image Mirroring Button BLACKVUE...

  • Page 9: Back View

    The illumination sensor detects when it is dark and activates the IR LEDs which help to pick up more detail in dark areas. The rear camera housing is dust-proof and waterproof. * When installing, make sure that the orientation of the camera is correct. If installed otherwise its image/video will display upside down. R-200WR...
  • Page 10 Installation guide Blackvue dashcam y Install the product in a location that doesn’t interfere with diver’s vision. y Turn off the engine before installation. y Refer to your vehicle Owner’s Manual to locate the fuse box. 10 BLACKVUE...

  • Page 11: Full Wiring Diagram

    The RearView kit and Wireless rear camera are compatible with DR750S-2CH and DR900S-2CH. However Resolution, Image quality and Camera (video) orientation settings of the wireless rear camera are fixed and cannot be changed from the dashcam’s firmware settings. R-200WR 11...
  • Page 12 Find a power source (12V/24V) on the backside of your vehicle that stays constantly powered on as long as engine is ON. Connect the power cable of rear camera to it according to wires’ color; red to red (power) wire and black to black (ground) wire. 12 BLACKVUE...
  • Page 13 3. Connecting R-200 to the display * Explained for BlackVue RearView LCD only. Other LCDs in use might have different configuration. 3.1. There are two ways to connect LCD to R-200. A. If you want the rear camera image to display on LCD only when the reverse...
  • Page 14 5.3. Plug the power cable of the front camera into the cigarette lighter socket Pairing R-200 and ERC-100W: The BlackVue Wireless Rear camera (ERC-100W) and the Rear View Kit (R-200) are factory paired. However, if you replace any of these with another one, you will have to pair the new set manually using a magnet.
  • Page 15 LCD. Restart the wireless rear camera (if the rear camera is already installed and hardwired, simply turn OFF ignition of your vehicle and turn back ON) and the image will appear on the LCD. If pairing fails, repeat the above procedure or contact the BlackVue dealer...
  • Page 16 Power Magic Pro R-200 Power Cable Fuse Box Dashcam Then use another Power Magic Pro to hardwire the wireless rear camera. y Use wire connectors for stable and secure connection. y If wires are connected directly, insulate them properly. 16 BLACKVUE...

  • Page 17: Product Specifications

    Output Power(for DC 12V-24V, 0.5A display) Operation Temperature -20 °C − 70 °C (-4 °F − 158 °F) Storage Temperature -20 °C − 70 °C (-4 °F − 158 °F) Certificates FCC, CE, RoHS, IC R-200WR 17...
  • Page 18 -20 °C − 70 °C (-4 °F − 158 °F) Certificates FCC, CE, RoHS, IC * The Rearview system (R-200WR) is compatible with the front camera of DR750S-2CH and DR900S-2CH. You can download the latest firmware of the dashcams from www.blackvue.com > Support > Downloads.
  • Page 19 Notes...
  • Page 20 Notes...
  • Page 21 Notes...

  • Page 22: Product Warranty

    Product Warranty  The term of this product warranty is 1 year from the purchase date. (Accessories such as Battery/microSD Card : 6 Months) We, PittaSoft Co., Ltd., provide the product warranty according to Consumer Dispute Settlement  Regulations (drawn up by the Fair Trade Commission). PittaSoft or designated partners will provide the service upon request.
  • Page 23 Гарантия Срок гарантии на данное устройство составляет 1 год с даты покупки. (для аксессуаров, таких как батарея/карта памяти microSD: 6 месяцев) Мы, компания PittaSoft Co., Ltd, предоставляем гарантию на продукт в соответствии с правилами урегулирования потребительских споров (составленными Комиссией по справедливой...
  • Page 24 FCC ID : YCK-R-200WR / HVIN : R-200WR / IC : 23402-R200WR Wireless Rearview System R-200WR © 2019...
