NEW ZEALAND (HEAD OFFICE)
GILTRAP ENGINEERING LTD
7 Main North Road
PO Box 83
Otorohanga
TEL:
+64 7 873 4199
FAX:
+64 7 873 8131
FREE:
0800 804 458 (NZ ONLY)
GENERAL:
info@giltrapag.co.nz
PARTS:
parts@giltrapag.co.nz
WEBSITE:
www.giltrapag.co.nz
Part Number: 13257
RS2 Feeder
Operators & Parts Manual
AUSTRALIA
GILTRAP AG EQUIPMENT PTY LTD
105-117 Boundary Road
Laverton North
Melbourne
Vic 3026
TEL:
+61 3 936 96 548
FAX:
+61 3 936 96 549
FREE:
1800 127 030 (AU ONLY)
SALES:
sales@giltrapag.com.au
PARTS:
melboffice@giltrapag.com.au
WEBSITE:
www.giltrapag.com.au
Advertisement
Chapters
Table of Contents
Related Manuals for Giltrap RS2
Summary of Contents for Giltrap RS2
- Page 1 RS2 Feeder Operators & Parts Manual NEW ZEALAND (HEAD OFFICE) AUSTRALIA GILTRAP ENGINEERING LTD GILTRAP AG EQUIPMENT PTY LTD 7 Main North Road 105-117 Boundary Road PO Box 83 Laverton North Otorohanga Melbourne Vic 3026 TEL: TEL: +64 7 873 4199...
- Page 2 Although every endeavour has been made to compile as near to complete records as possible for the machine described, it is possible some information is incomplete or missing. Giltrap Engineering request that you treat this book as a guide only, and offer any assistance necessary to procure the information or part you may require.
-
Page 3: Table Of Contents
Page 3 RS2 Feeder – Operator’s Manual & Parts Book Table of Contents INTRODUCTION ......................4 SAFETY - GENERAL ...................... 7 SAFETY – MACHINE SPECIFIC ................... 11 PRE-SERVICE GUIDELINES & SETTINGS ..............12 SETUP & OPERATING INSTRUCTIONS ..............13 Hydraulic Requirements ............................. 13 Setup ................................... -
Page 4: Introduction
Thank you for purchasing a Giltrap product. Giltrap Engineering Ltd has enjoyed a long-standing success with their machinery. We would like you to enjoy the benefits of owning a Giltrap too. By following the guidelines laid out in this book, you will ensure trouble free, low maintenance operating for years. - Page 5 RS2 Feeder – Operator’s Manual & Parts Book Warranty The Goods specified in the Price List as designed and supplied by Giltrap Engineering Ltd are warranted against faulty workmanship and defective materials for a period of 24 months from the date of purchase.
- Page 6 Page 6 RS2 Feeder – Operator’s Manual & Parts Book Serial Number Identification Before ordering any parts, check the serial number and the delivery date of the machine and include this information with all orders. If the Serial Number Plate is missing, the serial number will be stamped on the front of the drawbar.
-
Page 7: Safety - General
Page 7 RS2 Feeder – Operator’s Manual & Parts Book Safety - General This section of the manual offers general guidelines for the safe operation of machinery. For the safety of others and yourself, please read and follow the precautions in this operator’s manual. - Page 8 Page 8 RS2 Feeder – Operator’s Manual & Parts Book Carry a suitable fire extinguisher. A fire can ignite under certain conditions, so please take the following precautions: After running your machine for a short time, check for defective bearings. A faulty bearing can become very hot, eventually discolouring, requiring immediate replacement.
- Page 9 Giltrap Engineering has made every effort to highlight all risks to personnel or property. Owners and operators have a responsibility to exercise care and safe work practices at all times in the vicinity of the machine.
- Page 10 Page 10 RS2 Feeder – Operator’s Manual & Parts Book Avoid tip-overs Run the machine along hillsides with the elevator on the high side of the hill. Avoid holes, ditches and obstructions which may cause the machine to tip over, especially on hillsides. Never drive near the edge of a gully or steep embankment - it might cave in.
-
Page 11: Safety - Machine Specific
Page 11 RS2 Feeder – Operator’s Manual & Parts Book Safety – Machine Specific The lists below are not all-inclusive and serve only to highlight the more obvious areas of risk. The labels attached to the machine are a general reminder that there are hazardous areas on the machine, rather than specifically highlighting all possible hazards. -
Page 12: Pre-Service Guidelines & Settings
Axle Mounting Bolt Recommended Torque Settings 180 ft/lbs or 245Nm THERE ARE SEVERAL GREASE POINTS on all Giltrap feeders. Check the yellow label on the side of your machine to see how many grease points there are. You should fully grease everything before running it... -
Page 13: Setup & Operating Instructions
Setup & Operating Instructions Hydraulic Requirements The RS2 Feeder requires two double acting hydraulic remotes. It is important to use the correct type of quick release coupling ends to suit your tractor couplings as some brands of couplings have different spring tension within the coupling which may impede full oil flow - it pays to check this. -
Page 14: Feeding Out
Page 14 RS2 Feeder – Operator’s Manual & Parts Book Feeding Out Set the tractor hydraulics so the machine is running at 25-30 litres per minute flow. 1. Ensure that all plastic wrapping, mesh and loose string has been removed. -
Page 15: Maintenance
Page 15 RS2 Feeder – Operator’s Manual & Parts Book Maintenance The Giltrap Bale Feeder is designed for minimal maintenance. Your Giltrap RS2 Feeder will give long and efficient service if given normal care and maintained properly. Lubrication The feed chains should be lubricated on a weekly basis to prolong operational lifespan. Giltrap Engineering recommends the use of food grade chain oil to avoid contamination of livestock feed. -
Page 16: Feed Chain Adjustment
Page 16 RS2 Feeder – Operator’s Manual & Parts Book Feed Chain Adjustment Check frequently and clean out any build up of debris between the chain links under feed bars. Straighten any bent feed bars and teeth. Feed chains should not require much adjustment; however, if this should become necessary adjust the chain until the slack has been minimised. -
Page 17: Parts Section
Page 17 RS2 Feeder – Operator’s Manual & Parts Book Parts Section Contents GENERAL LAYOUT ...................... 18 BED ASSEMBLY ......................19 CHASSIS ASSEMBLY ....................21 LOADING MECHANISM ....................22 STRING BIN ASSEMBLY ....................23 50MM 6 STUD HUB MONROC ..................24... -
Page 18: General Layout
Page 18 RS2 Feeder – Operator’s Manual & Parts Book General Layout Item Part No. Description Refer below Bed Assembly Refer below Chassis Assembly Refer below Loading Mechanism 1 Refer below String bin Assembly... -
Page 19: Bed Assembly
Page 19 RS2 Feeder – Operator’s Manual & Parts Book Bed Assembly... - Page 20 Page 20 RS2 Feeder – Operator’s Manual & Parts Book Bed Assembly Item Part Number Description Quantity 3”P15000LB S/pin conv chain CH15000-3/60 13152 Elevator Bar YET 208 bearing FYJ 508 Bearing flange 12756-9 Bearing adjuster 12587-12 Sprocket cover 12620 6T 40mm Bore sprocket...
-
Page 21: Chassis Assembly
Page 21 RS2 Feeder – Operator’s Manual & Parts Book Chassis Assembly Item Part Number Description Quantity 12833 RS2 Drawbar drawbar 127-2521 tow hitch 12825 RS2 Chassis chassis HSGF208 bearing flange BRGYAR208-2F bearing 12845 CQ1267 3 x 1.5 x 468... -
Page 22: Loading Mechanism
Page 22 RS2 Feeder – Operator’s Manual & Parts Book Loading Mechanism Item Part Number Description Quantity 12843 12844 12846 EZX04505040 bush 13259 Boom 12848 43169 spear 13258 Headstock CQ1263 3 x 1.5 x 270 Crowd ram 12847... -
Page 23: String Bin Assembly
Page 23 RS2 Feeder – Operator’s Manual & Parts Book String Bin Assembly Item Part Number Description Quantity 13253-6 Stop plate 13253-7 Stop link 13255 Upper hinge mount 13253-5 Stop mount 13253-1 Lower hinge 13252 String bin 13253-3 Vert inner reinf... -
Page 24: 50Mm 6 Stud Hub Monroc
Page 24 RS2 Feeder – Operator’s Manual & Parts Book 50mm 6 Stud Hub Monroc... - Page 25 Page 25 RS2 Feeder – Operator’s Manual & Parts Book 50mm 6 Stud Hub Monroc Item Code Description Quantity Body Stub Axle Square 479555Q010-L 50 01 Washer – 45x96x2 3512004000 Ring seal contact 416701Q00A 45x55x14.5 339101Q002 Seal AS NBR 55x88x10...
-
Page 26: 50Mm 6 Stud Hub Adr
Page 26 RS2 Feeder – Operator’s Manual & Parts Book 50mm 6 Stud Hub ADR Item Part Number Description Quantity GRN8-45x1.25 M8 grease nipple 110-0917 M18 Wheel nut 110-1018 Crown nut M27x1.5 + spring pin 110-0843 Hub cap 62mm BRG30206J2... - Page 27 Page 27 RS2 Feeder – Operator’s Manual & Parts Book Notes:...
