SEIF SAGE Series Instruction Manual

www.self-electronics.com
INSTRUCTION MANUAL
SERIES: SAGE/SAGE M
Read these instructions completely and carefully.
• Read the instruction carefully before installation，non-observance of this instruction may cause damage
to the product or hurt to human body. The installation must be carried out by a qualified electrician in
accordance with local or national codes.
• Cut off the power supply before installation and maintenance !
• Regularly check the light source , the LED power supply, the cord and other accessories. If any part is
damaged, the product should not be used.
• The product is only for indoor and dry location. Clean the product with a damped cloth (no dripping
water), preferably anti-static.
• Do not stare into LED beam.
Dimensions: (Inches/mm)
L
SAGE-LX-24V/SAGE M-LX-24V
SAGE-LX-24V/SAGE M-LX-24V
(Interconnected version)
L
SAGE FROST-LX-24V/SAGE FROST M-LX-24V
SAGE FROST-LX-24V/SAGE FROST M-LX-24V
(Interconnected version)

ATTENTIONS

3/16"(5mm) 9/32"(7mm)
1/2"(13mm)
1/2"(13.4mm) 19/32"(15mm)
1/2"(13mm)
www.self-electronics.com
Specifications：
Mode
SAGE-LX-24V
SAGE M-LX-24V
SAGE FROST-LX-24V
SAGE FROST M-LX-24V
* X: The quantity of LEDs, will be multiples of seven.
L: The maximam length of the luminaire is up to 90-9/16"

Accessories:

Clip 1
1/2"(13mm)
0° mounting clip
X1

Tools:

1/2"(13mm)
Ruler
Rated Length Power Minimum Mounting
Input Space(LXWXH)
(L+1/2")X9/16"X9/16"
24VDC 9/16"xX+1" X/7W
((L+12)X15X15mm)
(L+1/2")X9/16"X9/16"
24VDC 9/16"xX+1" X/7W
((L+12)X15X15mm)
(L+1/2")X9/16"X13/16"
24VDC 9/32"xX+1" 2xX/21W
((L+12)X15X20mm)
(L+1/2")X9/16"X13/16"
24VDC 9/32"xX+1" 2xX/21W
((L+12)X15X20mm)
(2300mm) .
Clip 2
45° mounting clip 0° magnet mounting clip
X1 X1
(For SAGE-LX-24V,
SAGE FROST-LX-24V use only)
Pencil Screwdriver
ta Max. Linkable
Length
-20°C~35°C
4.8m
(-4~95°F)
-20°C~35°C
4.8m
(-4~95°F)
-20°C~35°C
3.6m
(-4~95°F)
-20°C~35°C
3.6m
(-4~95°F)
45° magnet mounting clip
X1
