SEIF MULTIFRIO Series Instruction Manual

www.self-electronics.com
MULTIFRIO
INSTRUCTION MANUAL
SERIES：MULTIFRIO
Read these instructions completely and carefully.
• Read the instruction carefully before installation，non-observance of this instruction may cause damage
to the fixture or hurt to human body. The installation must be carried out by a qualified electrician in
accordance with local or national codes.
• Cut off the power supply before installation and maintenance !
• Regularly check the light source , the LED power supply, the cord and other accessories.
• If any part is damaged, the product should not be used.
• Keep this instruction manual handy for future use
• The light source of these product are non-changeable light diodes(LED).
• Do not disassemble the product, as the light diode can cause damage to the eyes.
• The production is only for indoor and dry location.
• Use only with SELV power supply
Dimensions: mm
L
Specification:
Model Rated input Power
MULTIFRIO-L18-24V 24VDC 3W
MULTIFRIO-L36-24V 24VDC 6W
MULTIFRIO-L48-24V 24VDC 8.5W
MULTIFRIO-L72-24V 24VDC 12W
MULTIFRIO-L96-24V 24VDC 17W
MULTIFRIO-L42-24V 24VDC 7.5W
MULTIFRIO-L36-24V-1 24VDC 6W
MULTIFRIO-L72-24V-1 24VDC 12W
MULTI LINEAR-L72-24V 24VDC 6W
MULTI LINEAR-L108-24V 24VDC 8.5W
MULTI LINEAR-L144-24V 24VDC 12W
ATTENTIONS
12
18.5
14.3
Length ta IP Rating
300mm -25°C~35°C IP44
600mm -25°C~35°C IP44
850mm -25°C~35°C IP44
1200mm -25°C~35°C IP44
1700mm -25°C~35°C IP44
750mm -25°C~35°C IP44
550mm -25°C~35°C IP44
1150mm -25°C~35°C IP44
600mm -25°C~35°C IP65
850mm -25°C~35°C IP65
1200mm -25°C~35°C IP65
1
