Key Features - NetComm NP560 Specifications

NP560/NP562

kEY FEATURES

Dramatically increase your
wireless coverage and
throughput
Compatible with 802.11g/b
wireless equipment
Industry standard SMA
connector
Ideal for use with Wireless
Access Points, Routers and
Gateways with detachable
aerials
TECHNICAL SPECIFICATIONS
OPERATING RANGE
• 2400 ~ 2500 MHz
OPERATION MODE
• Bi-directional, half-duplex, auto-switching via
carrier sensing
CONNECTOR
• SMA Receptacle
IMPEDANCE
• 50 ohm
OUTPUT POWER
NP560: 200mW (23dBm nominal) for 11g@54Mbps
•
• NP562: 500mW (27dBm nominal) for 11g@54Mbps
TRANSMIT INPUT POWER
• Maximum 100mW
• Minimum 6mW
TRANSMIT GAIN
• 12dB(adjustable)
ATTENTION: The use and installation of this WiFi device must comply with the Australian Spectrum Management legislation which specifies that a WiFi transmitting station must not have an
Effective Radiated Power (ERP) exceeding 4-Watts.
ERP is a radio frequency signal strength field measurement and can be calculated as: Wireless device output power, less the power lost in the antenna feed-line (antenna connection cable),
plus the power gain of the antenna itself. If you are unsure about any of these parameters or how to calculate them, please consult your installer or dealer. Alternatively you can visit the
Australian Communications & Media Authority (ACMA) website at www.acma.gov.au
Exceeding such power restriction limits is illegal and may result in undesirable radio interference which is strictly monitored by the ACMA.
Your NetComm dealer:
200mW/500mW Indoor 11g/b Wireless Booster
TYPICAL SCENARIO
PCs
RECEIVE GAIN
• 14dB(typical)
FREQUENCY RESPONSE
• +/- 1dB over operating range
RECEIVE NOISE FIGURE
• 3.5dB nominal
OPERATING TEMPERATURE
• -20 ~ +70°C
POWER
• 6V DC maximum current <1A, 100 ~ 240V for AC adaptor
BOOSTER
• 7.8 x 5.6 x 2.9cm
MATERIAL
• Cast Aluminium
WEIGHT
• <0.2kg
NETCOMM LIMITED
P: 02 9424 2070 F: 02 9424 2010 E: sales@netcomm.com.au W: www.netcomm.com.au
Trademarks and registered trademarks are the property of NetComm Limited or their respective owners. Specifications are
subject to change without notice. Images shown may vary slightly from the actual product.
Switch
Access
Point
NP560/NP562
Indoor Wireless Booster
DC ADAPTOR
•
LED INDICATOR
•
PACkAGE CONTENTS
•
•
•
•
ONE YEAR WARRANTY*
One year warranty out of the box. Online registration at
www.netcomm.com.au
*Conditional upon online registration
PO Box 1200, Lane Cove NSW 2066 Australia
ABN 85 002 490 486
RJ-45 Ethernet cable
Booster connector cable
Broadband
Modem Router
Wireless-enabled PCs
<6.0 x 4.4 x 2.5cm
TX LED
NP560/562 200mW/500mW Indoor 11g Wireless Booster
Power Supply
Antenna Connection Cable
Quick Connection Guide
Internet
