TOYOTA SIENNA
HYBRID 2022
SECONDARY CONTROLS
INSTALLATION GUIDE
Applicable to Sienna models & Limited, starting from 2021
LAST UPDATED October 3, 2022
REV:
01
2020© R.A.SH Tronics Ltd™ All rights reserved.
Reproduction by any means, electronic, graphics (GUI) or mechanical, including photocopying, recording or by any information storage and retrieval
system or translation in whole or part is NOT PERMITTED without written authorization from R.A.SH Tronics Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIENNA HYBRID 2022 and is the answer not in the manual?

Questions and answers

Summary of Contents for Toyota SIENNA HYBRID 2022

  • Page 1 TOYOTA SIENNA HYBRID 2022 SECONDARY CONTROLS INSTALLATION GUIDE Applicable to Sienna models & Limited, starting from 2021 LAST UPDATED October 3, 2022 REV: 2020© R.A.SH Tronics Ltd™ All rights reserved. Reproduction by any means, electronic, graphics (GUI) or mechanical, including photocopying, recording or by any information storage and retrieval...
  • Page 2: Table Of Contents

    CONTENTS IMPORTANT RELEASE NOTES ..........................TO OUR VALUED CUSTOMER ..........................CUSTOMER CARE CENTER ............................ABSTRACT ................................USEFUL HINTS ................................ SYSTEM OVERIEW ...........
  • Page 3: Important Release Notes

    IMPORTANT RELEASE NOTES This manual contains a new kit with new hardware, it is important to read through the diagrams and understand it. The Multi-Function module is divided into two modules doing all steering functions including Cruise control. It is easier to install, and less time consume.
  • Page 4 SYSTEM OVERIEW...
  • Page 5: Recommended Installation Procedure

    RECOMMENDED INSTALLATION PROCEDURE...
  • Page 6: Installing The Lcd Module & Lin Junction Box

    "P" position. Toyota implemented two different CANbus systems in the 2022 Hybrid Sienna, tapping into the wrong wires WILL cause loads of errors and WILL cause many OEM systems to malfunction. You MUST carefully follow all the instructions in this manual.
  • Page 7: Description Of Main Components

    All modules of the system are usable in two modes, 1) as stand-alone using hardware switches or LIN input devices and 2) as part of the LCD kit. The LIN junction box is designed to simplify the connection of all modules in a central connection box;...
  • Page 8: Description Of Main Components (Continued)

    DRIVEIN STA-035 TOUCH-DISPLAY Through this 3.5” single touch screen displays you can control all operation and programming functions for the DRIVEIN system. All secondary functions are also controlled and programmed Through the display. It’s location in the vehicle will vary, depending on the system set-up and mounting options for the driver.
  • Page 9: Vehicle Interface Module (Gateway)

    ENGINE START/ STOP MODULE (UIS-28X) This module is used to override the OEM Push/Start system. UNIVESAL 12 RELAYS MODULE (MRB-612) Can do many functions: 1. Power windows 2. Power mirrors & LIMITED (MRB-112) 3. B-Directional motor control 4. Docking station INPUT DEVICES: RID-1X or RID-2X round input device.
  • Page 10 • Circulate The Toyota multi-function control box is a relay-based system using two VAC-10X modules marked A and B. The turn signals canceling system is based on the steering position CANbus information, no further wiring is required. The turn signals and lights control box. The wires are thin, follow the instruction carefully in order to avoid damages to ant...
  • Page 11 IDENTIFYING THE CAN-BUS LOCATION The CANbus wires are located on the front left A pillar, tap in parallel, never cut. Identifying the first CANbus wires connector Connect the gateway ORG & GRN wires to the GRY & WHT.
  • Page 12 Identifying the second CANbus wires connector. Connect the gateway BLU and BRN wires to the BLU and WHT.
  • Page 13 These two CANbus wires are applicable for 2021/2022 Toyota Sienna Hybrid to present. Tap to them according to the wiring diagrams below. Make sure the soldering point is at least 2” away from the connector in order to avoid damaging the connector.
  • Page 14 VEHICLE INTERFACE MODULE WIRING...
  • Page 15 SHIFT BY WIRE WIRING DIAGRAM...
  • Page 16: Ignition Start Stop Module

    ENGINE START STOP Two different engine start stop systems available for the Sienna, depending on your vehicle model, you might have a standard rotating key for engine starting, alternatively you might find a push button start. The Drivein touch system supports the two types using two different modules.
  • Page 17: Ignition Start Module Wiring (Smart Key System)

    IGNITION START MODULE WIRING (SMART KEY SYSTEM)
  • Page 18: Electronic Parking Brake Wiring

    ELECTRONIC PARKING BRAKE WIRING...
  • Page 19 MULTI-FUNCTION TURN SIGNALS, HORN, HIGHBEAM WIRING VAC-10X_A MODULE...
  • Page 20: Multi-Function Front Wipers Wiring Vac-10X_A Module

    MULTI-FUNCTION FRONT WIPERS WIRING VAC-10X_A MODULE...
  • Page 21: Multi-Function Rear Wipers Wiring Vac-10X_B Module

    MULTI-FUNCTION REAR WIPERS WIRING VAC-10X_B MODULE...
  • Page 22: Multi-Function Headlights Wiring Vac-10X_B Module

    MULTI-FUNCTION HEADLIGHTS WIRING VAC-10X_B MODULE...
  • Page 23: Heating Ventilation And Airconditioning Module

    HEATING VENTILATION AND AIRCONDITIONING MODULE...
  • Page 24: Power Mirrors Module

    POWER MIRRORS MODULE...
  • Page 25: Power Mirrors (Limited)

    POWER MIRRORS (LIMITED)
  • Page 26: Using The Egrees Module

    USING THE EGREES MODULE It is extremely important for your customer to understand how does this module helps him and save you from towing the van to the workshop. It is designed to save one battery for emergency modes when the main battery is flat. Also important to install two switches, one inside and another outside of the van with in reach of the driver (switches can be magnetic switches).
  • Page 27 EGRESS MODULE WIRING...
  • Page 28 VOICE SCAN WIRING...
  • Page 29 USING THE HVAC The HVAC module is very smart, it can control almost all funtions of the driver side only. Some touch buttons can do two or more functions, please read the instructions and practice yourself before driving. The rear fan speed control is not supported.
  • Page 30 Shortly press this touch button to toggle the AC “Air conditioning” on or off. Press and hold to engage full automatic operation Shortly press this touch button increase (Hot) the tempereture one step. Press and hold to constantly increase the temperature until the button released or the maximm temperature reached.
  • Page 31 APPENDIX SPECIFICATIONS The following chart lists the standard wire colors and their corresponding abbreviations that will be used for the installation of all R.A.SH Tronics Ltd products. WIRE COLOR COLOR ABBREVIATION WIRE GAUGES CURRENT RATING BLACK 0.3mm AWG22 BROWN 0.5mm AWG20 7A- 13A 0.85 mm...
