Summary of Contents for SOCO TC WANDERER
- Page 1 Follow us Vmoto Soco e-mobility vmotosoco vmotosoco USER MANUAL vmotosoco Vmoto...
- Page 2 SAFE INSTRUCTION To ensure your safety, please read this manual carefully before riding and make sure you are always following the requirements below: Fully understand the information in this manual, including but not limited to the relevant instructions, precautions and warnings Fully understand the operation and contingency measures of TC intelligent electric vehicle Be fully aware of warning labels of TC intelligent electric vehicle Do not disassemble the electric vehicle and parts without permission, Please contact customer service department and dealers...
- Page 3 USER INSTRUCTION Do not ride after you take medications which may effect your riding ability, drink alcohol or when you feel physically upset Observe traffic regulations and traffic signs, manned and loaded in accordance with local laws and regulations and confirm the surrounding road conditions and bike’s conditions at any time, so as to actively avoid danger In case of rain and snow, the braking distance shall be increased.
- Page 4 QUICK START Parts inspection Quick start Mirrors User manual Keys Spanner for mirrors Charger...
- Page 5 QUICK START Install battery Open storage box, Remove the storage protector switch，put Connect power plug, take out cover the storage box in and make sure it's plugged close in and hear a click...
- Page 6 QUICK START Quick start Press “unlock”on remote Put helmet on Get on motorcycle, kick side control stand out Press “Parking" button, Turn accelarator gently, Press “Power", power on unparking TC, parking symbol motorcycle run off...
- Page 7 Android system: APP only supports Android 4.4 system and above. From the date of purchase of the vehicle, you will automatically receive a free two-year central control SIM card data in order to use the SOCO electric vehicle APP function. Please be sure to complete the next year's data recharge before the end of the two-year free period.
-
Page 8: Table Of Contents
CONTENTS Accessories checklist Operation guide Ride guide Battery use guide APP instructions Maintenance... -
Page 9: Accessories Checklist
DESCRIPTION OF COMPONENTS AND PARTS a. SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS Front brake lever Accelerator Right-handlebar switch assy Speedometer Winker Tail lamp Saddle Rear brake lever Left-handlebar switch assy TOP VIEW... - Page 10 DESCRIPTION OF COMPONENTS AND PARTS a. SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS Storage box Back mirror Headlight Battery compartment FOC vector controller Disc brake system Hub motor Spoke-type Electronic side stand aluminum hub SIDE VIEW...
- Page 11 DESCRIPTION OF COMPONENTS AND PARTS SCHEMATIC DIAGRAM OF THE SPEEDOMETER READY Start indicator The vehicle can be started when READY is displayed OBD Indicating OBD checking error codes See page 24 FAQ & TROUBLESHOOTING Charging Error High beam indicator Battery error Winker indicator Parking indicator Indication P shows in parking mode...
-
Page 12: Operation Guide
OPERATION GUIDE Left Switch Assy High/low beam switch button Winker button Horn button Press up to turn on the high beam Dial to the left side to turn on the Press to make a sound and release Press down to turn on the low beam left winker;... - Page 13 OPERATION GUIDE Right Switch Assy Gear shift button Emergency flashers Parking button The bike is set with 1 ECO mode, 2 “ Emergency flashers " Press the “Parking button" Press up the vehicle Cruise mode, and 3 Sport mode. To vehicle up to turn on the double flash to enter the parking state, the the right is the ECO mode, to the...
- Page 14 OPERATION GUIDE c.Intelligent Remote Control Operation We use the second generation of SUPER SOCO intelligent remote control key. You can easily lock or unlock the vehicle by tapping the button within the effective distance. 1.Generation smart remote control After unlocking TC via remote control, press the“POWER”, power on, press again, power off.
- Page 15 OPERATION GUIDE d. How To Operate The Physical Handlebar Lock After the bike stops, turn the handlebar to the far left, insert the key into the physical handlebar lock, and rotate it rightwards to lock the bike. Insert the key into the physical handlebar lock, and rotate it leftwards to unlock the bike e.
- Page 16 OPERATION GUIDE f. Circuit Protector Switch Operate As the protection switch for the main power of electric vehicle, the circuit protector will automatically disconnect to ensure safety when the vehicle circuit is abnormal or the current caused by short circuit exceeds the set safe value. TIPS：...
-
Page 17: Ride Guide
RIDING GUIDE a. Check List Before Riding Make sure to check the following items before riding a TC intelligent electric vehicle, which will guarantee your safety on the road. Whether the handlebar is stable and flexible when turning. Whether the switches on the right and left handlebars can work correct. Whether the throttle working properly. - Page 18 OPERATION GUIDE b. Start the vehicle Press “unlock”on remote Put helmet on Get on motorcycle, kick side control stand out Press“Parking" button, Turn accelarator gently, Press “Power", power on unparking TC, parking motorcycle run symbol off...
- Page 19 RIDING GUIDE TIPS： Before riding, please make sure that the electronic side stand is stowed and turn the handlebar to make sure that the front lock is closed; During riding, if you press the “park button" or turn on the electronic side stand, the whole vehicle will be powered off.
-
Page 20: Battery Use Guide
BATTERY USE INSTRUCTION a.Vehicle Body Charging Insert the main charger plug into the charging port of the vehicle. Insert the chargers AC power plug into the socket, and the battery starts charging when the charger indicator turns red. The battery is fully charged if the charger indicator turns from red to green Battery level display Charging: red light is on continuously Full: green light on continuously... - Page 21 BATTERY USE INSTRUCTION b. External charging Open the storage box, turn off the circuit protector switch and take out the storage box. Disconnect the main plug of the battery. Insert the main plug of the charger into the charging port of the battery, and then insert the AC power plug of the charger into the socket.
- Page 22 BATTERY USE INSTRUCTION c. Storage, Maintenance And Transportation Please charge the battery to half-saturation state when storing or transporting it (after the battery is discharged, charge it for 3 hours).Disonnect the battery to the vehicle to prevent the battery from over-discharging, place it in a dry and ventilated place, and charge it with a charger for 3.5 hours in two months.
-
Page 23: App Instructions
The functions of soco Electric Vehicle APP may vary with version updates, function upgrades and different vehicle types. Please refer to the actual content of the latest version. -
Page 24: Maintenance
TIPS： The maintenance provided by Super Soco Authorized Service Center is free of charge, which can be did by yourself or at a regular electric vehicle repair shop Daily Cleaning And Maintenance ·Cleaning: Please use clean water, neutral detergent, soft cloth and sponge to clean the surface of the vehicle;... - Page 25 MAINTENANCE Warning Please switch off the circuit protector switch before cleaning. Do not use strong pressure water to wash it directly, in order to prevent internal electrical components and lines from intruding or soaking water and causing vehicle mechanical failures or other hidden dangers of accidents. In case don’t use for long time, please turn off...
-
Page 26: Faq
Battery aging or normal scrap Change battery Battery cannot be charged Poor contact of charger plug Check whether the battery plug is at right position or not Used wrong charger Use SUPER SOCO charger Battery aging or normal scrap Change the battery... - Page 27 FAQ& TROUBLESHOOTING Error Causes Solutions Error 99 on speedometer Controller communication error Please contact after sales service or dealer Error 98 on speedometer Controller stop working(Possible over Please stop riding and wait for a while then restart or current,motor blocking,under voltage, contact after sales service or dealer over temperature) Error 97 on speedometer...
- Page 28 FAQ& TROUBLESHOOTING Error Causes Solutions Error 90 on speedometer Battery discharging over current error Please stop riding if keep showing and contact after sales service or dealer Error 89 on speedometer Battery charging low temperature error Please move the bike to warm indoor place and wait for a while Error 88 on speedometer Battery discharging low temperature...
- Page 29 FAQ& TROUBLESHOOTING c. BATTERY FAULT REMOVAL Battery Status Issues Causes Solution Before using Battery runs out, unable to Battery no power Please charge the battery activate the vehicle In Operation In battery low power mode. Battery runs out, low-voltage Please charge the battery Battery below 10% ,vehicle protection power-off...
- Page 30 FAQ& TROUBLESHOOTING Battery Status Issues Causes Solution Storage Press “Start” , no power The battery is stored too long time, Please charge the battery. If it is battery runs out not possible to charge,please contact after sales service or dealer In Charge Display 89 error code Charging at low temperature...
- Page 31 SOCO APP Download APP Bind APP PASTE BARCODE Only iOS and Android are currently available now, please confirm your smart phone operating system in advance. iOS system: APP only supports Apple iOS 9.0 system and above. Android system: APP only supports Android 4.4 system and above.
- Page 32 1000KM 3000KM 6000KM 9000KM 12000KM 15000KM 18000KM 21000KM 24000KM Torque CHECK LIST 3months 6months 12months 18months 24months 30months 36months 42months 48months (N·m) Brake uid "FR 175 KPa Tire pressure and wear RR 225 KPa" Front and rear lining pad wear Front and rear brake disc wear Fasten front axle nut and rear wheel bolt Fasten the swingarm nut...
- Page 33 MAINTENANCE RECORD： CONTENT： DATE： MAINTENANCE RECORD： CONTENT： DATE：...
- Page 34 MAINTENANCE RECORD： CONTENT： DATE： MAINTENANCE RECORD： CONTENT： DATE：...
- Page 35 MAINTENANCE RECORD： CONTENT： DATE： MAINTENANCE RECORD： CONTENT： DATE：...
- Page 36 MAINTENANCE RECORD： CONTENT： DATE： MAINTENANCE RECORD： CONTENT： DATE：...
- Page 37 MAINTENANCE RECORD： CONTENT： DATE： MAINTENANCE RECORD： CONTENT： DATE：...
