USER INSTRUCTIONS
Welcome to the family of SOCO owners! We will guide you to know every function for the right and safe use
of TS smart electric bikes. To ensure your safety, please read this manual carefully before riding and make sure
you are always following the requirements below:
Fully understand the information in (.his manual, including but not limited to the relevant instructions, precautions and warnings.
Fully understand the operation and contingency measures of TS smart electric bikes.
Be fully aware of warning labels of TS smart electric bikes.
SOCO will take any responsibility resulting from the unauthorized modification, failure to use original spare parts, or installation
of components that affect the performance and safety of the bike.
Please contact the SOCO Customer Service Center if you have any questions about this bike. We are at our service at any time.
Wish you safe and pleasant riding experience!

Safety Instructions

To ensure the safety of you and others, please make sure to observe the following matters:
Do not ride after you take medications which may affect your riding ability, drink alcohol, or when you are unwell.
Observe traffic regulations and traffic signs and confirm the surrounding road conditions and bike conditions at any time, so
as to actively avoid danger.
Wear safety equipment, such as helmet, and appropriate protective clothing if necessary, such as gloves and boots.
Perform a basic check each time before riding, so as to confirm the light, brake, tread and tire pressure and check other
parts for looseness or abnormal noise, and regularly go to SOCO Service Center for maintenance.
In order to ensure the safety of you and others, please DO NOT use high beam in good lighting conditions. The continuous
use of high beam will cause the visual disturbance to vehicles and pedestrians on the opposite side, thus affecting normal
driving.
Please do not make or answer any call during riding, which is likely to cause traffic accidents.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for SOCO TS

Summary of Contents for SOCO TS

  • Page 1: Safety Instructions

    Please contact the SOCO Customer Service Center if you have any questions about this bike. We are at our service at any time. Wish you safe and pleasant riding experience!
  • Page 2 DESCRIPTION OF COMPONENTS AND PARTS SCHEMATIC DIAGRAM OF COMPONENTS AND PARTS Rearview mirror Rear brake lever Headlamp Storage box Tail lamp Speed control handlebar Saddle Rear license bracket Right-handlebar switch set Front shock Brake cylinder absorber Rear swingarm Winker FOC vector controller Left-handlebar switch set Electric motor Spoke-type...
  • Page 3 DESCRIPTION OF COMPONENTS AND PARTS DIAGRAM OF INSTRUMENT PANEL Speed / fault code Real-time current Display current speed When Display current output current. fault indicator goes on, fault Power display bar code will be displayed. Display current battery level Ambient temperature Power display Display current Display current battery level.

  • Page 4: Start Button

    OPERATION GUIDE START BUTTON SMART REMOTE CONTROLLER OPERATION High/low beam switch button Headlamp button Press up to turn on the high beam. Dial up to to turn on the headlamp.Turn downward to AUTO Press down to turn on the low beam. to automatically turn on the headlights.The headlights turn on automatically according to the brightness of the environment.

  • Page 5: Handlebar Lock

    OPEN THE STORAGE BOX AND SADDLE HANDLEBAR LOCK With the advanced Smart Remote Controller, you can easily lock or unlock your TS smart electric bike by simply pressing After unlocking the bike with the Smart Remote Controller, the button within 50 meters.
  • Page 6 OPERATION GUIDE OPEN THE STORAGE BOX AND SADDL How to lock the bike How to Unlock the bike Insert the key and rotate it rightwards, and the After the bike stops, turn the handlebar to the far storage box will be opened when you hear a [Click] left, insert the key into the physical handlebar lock, sound.
  • Page 7 OPERATION OF ADJUSTABLE PEDAL The original adjustable pedal provides three riding modes, As the protection switch for the main power of TS smart electric bike, and can be adjusted for comfort. the air switch will automatically disconnect to ensure safety when the...

  • Page 8: Riding Guide

    RIDING GUIDE CHECKS BEFORE RIDING Make sure to check the following items before riding a TS Smart Electric Bike, which will guarantee your safety on the road. 1.Whether the handlebar is stable and flexible when turning. 2.Whether the switches on the right and left handlebars can work normally.

  • Page 9: Checks Before Riding

    CHECKS BEFORE RIDING CHECKS BEFORE RIDING Make sure to check the following items before riding a TS Smart Electric Bike, which will guarantee your safety on the road. 2.Put on the helmet, ride the TS, and retract the electronic side stand.
  • Page 10 CHECKS BEFORE RIDING Press the "Start" button, and the bike and the enters Press the "Parking" button to exit the oarking state, the button to exit the parking state, "Powered" state. and the parking indicator goes off Gently turn the handlebar to ride on the road. TIPS: Before riding, make sure the electronic side stand retracted and rotate the handlebar to ensure that the handlebar lock is closed.
  • Page 11 BATTERY USE INSTRUCTIONS How to charge the battery on the bike Insert the main charger plug into the charging port of the bike. Insert the chargers AC power plug into the socket, and the battery starts charging when the charger indicator turns red. The battery is fully charged if the charger indicator turns from red to green.
  • Page 12 BATTERY USE INSTRUCTIONS How to charge the battery off the bike Disconnect the main battery plug. Open the storage case, close the air switch and take out the storage. Insert the key into the anti-theft battery lock and rotate it rightwards to remove the battery from the bike.

  • Page 13: Storage, Maintenance And Transportation

    BATTERY USE INSTRUCTIONS Cuando la batería este completamente cargada, los indicadores de carga estarán en color verde. TIPS: TIPS: Do not expose the battery to water, and prevent it from being damped Short circuit of the cathode and the anode at the battery's input. by water or rained Keep it away from children, fire and heat source.

  • Page 14: Regular Inspection And Maintenance

    MAINTENANCE Regular maintenance can enhance the service life and driving safety of the TS smart electric bike. Please refer to the following suggestions and take care of your bike. ROUTINE CLEANING AND MAINTENANCE Cleaning： Please use clean water and neutral detergent to clean it, and use soft cloths and sponges to clean the surface;...

  • Page 15: Routine Cleaning And Maintenance

    ROUTINE CLEANING AND MAINTENANCE Regular maintenance can improve the service life and driving safety of the TS smart electric bikes. Please refer to the fol-lowing suggestionsand take care of your bike. Failure Causes Solutions Battery is poorly connected Connect the battery properly at its main plug...
  • Page 16 ROUTINE CLEANING AND MAINTENANCE Failure Causes Solutions Please contact after-sales service or dealer The instrument panel shows 99 Controller communication failure The controller stops working (possibly over current, Please stop for a while and then start again The instrument panel shows 98 blocking, under pressure, over temperature ) Controller pauses operation (possibly over current, Please contact after-sales service or deale...
