CMOS 16-BIT SINGLE CHIP MICROCONTROLLER
S5U1C17F57T Manual
(Software Evaluation Tool for S1C17F57)
Seiko Epson Corporation
i
S5U1C17F57T Manual
(Rev.0.9)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S5U1C17F57T and is the answer not in the manual?

Questions and answers

Summary of Contents for Seiko Epson S5U1C17F57T

  • Page 1 CMOS 16-BIT SINGLE CHIP MICROCONTROLLER S5U1C17F57T Manual (Software Evaluation Tool for S1C17F57) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 2 Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or circuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as, medical products.
  • Page 3 Tx : A socket for mounting Cx : Compiler package Sx : Middleware package Corresponding model number [17xxx : for S1C17xxx] Tool classification [C : microcomputer use] Product classification [S5U1 : development tool for semiconductor products] Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 4: Table Of Contents

    EPD Panel Interface Connector Pad (CN9-2) ...............21 4.2.7 EPD Module Interface Connector Pad (CN10) ..............22 REVISION HISTORY REVISION HISTORY REVISION HISTORY REVISION HISTORY................................................................................................23 ......Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 5: Overview

    S5U1C17F57T1 and S5U1C17F57T2 (SVT17F57: Software eValuation Tool for S1C17F57) are the evaluation and development support board for S1C17F57 single chip microcontroller made by Seiko Epson. It is composed of CPU board and peripheral board, the CPU board has built-in IC socket, the extension connectors, and the debugging connectors, etc.
  • Page 6 Moreover, the operation power supply voltage of S1C17F57 is fixed by 3.3V. (4)Please install the USB driver of Silicon Laboratories for CP2102 according to the direction of PC. Please prepare the USB cable by the customer. Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 7 JP1-22 JP23 OPEN OPEN BATT OPEN JP24-29 ON: Connect jumper switch, OPEN: remove jumper switch, SHORT: Short by solder, - : No care, OTHERS: The jumper switch is connected with this name side.   Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 8: Name Of Individual Component

    VDD power   supply (JP17)       VDD monitor VDD power   Function switching terminal (TP2) selection jumper   jumpers (JP1-2, (JP14) 18-19) Figure 2.1 Name of S5U1C17F57T1 CPU board surface each part Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 9 Extension connector (CN1-3, J1) Debug connectors CN2-1-2(J5, J6) Extension connector (CN1-2,J3) Extension connector( CN1-4,J2) Crystal oscillator Extension Crystal oscillator (X2) connector(CN (X1) 1-1, J4) Figure2.2 Name of the S5U1C17F57T1 CPU board back each part Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 10 Extension connector (CN1-2, J3) External CPU interface CN6 (J13) Reset switch (SW2) Piezo buzzer (BZ1) Extension connector Key switch REGMON pin (CN1-1, J5) (SW3〜6) (TP5) Figure 2.3 Name of S5U1C17F57T1 Peripheral board surface each part Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 11 2. Name and Function of Individual Component Function switching Function jumpers switching jumpers Battery folder JP13 JP22 JP21 JP10 JP20 JP19 JP14 JP23 JP17 JP18 JP29 Figure 2.4 Name of the S5U1C17F57T1 CPU board back each part Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 12: Functions Of

    : Supply open : No supply JP18 Connection of VE1, VE2 terminals of open short S1C17F57. JP19 Connection of VE2, VDD terminals of open short S1C17F57. In case of S5U1C17F57T1100. In case of S5U1C17F57T2100. Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 13 3(VDD) JP20(SLVSEL) Input to SLVSEL terminal of S1D14F51. open 1(VSS) 3(VDD) JP21(VD1SEL) Input to VD1SEL terminal of S1D14F51. open 1(VSS) 3(VDD) JP22(VPP) Connection of VPP for external EPD open short module connetor pad CN10(J12). Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 14: Functions Of Each Portion

    Measuring resistive sensor 1 (DC bias, channel1) Resistor RREF(R6) Reference resistor (DC bias, channel1) Sensor RSEN2(SENR5) Measuring resistive sensor2 (DC bias, channel1) Resistor RREF(R7) Reference resistor (AC bias, channle1) Measuring resistive RSEN(SENR6) Measuring resistive sensor (AC bias, channel1) sensor Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 15 For coin battery (In case of build-in a coin battery in the battery folder, do not supply power from CN3, CN5 connectors. Moreover, when operating with the battery, only the free run operation is possible. The debugging operation is impossible. Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 16: Block Diagram Block Diagram

    CB1-4 CD1-2 PILOT- S1C17F57 Crystal OSC4 (IC socket) 4.000MHz OSC3 OSC2 Crystal OSC1 32768Hz CPU Board CN2-2 CN2-1 (S5U1C17F57T2) Tact Buzzer switch x 4 ICDmini Ver.2 PC(GNU17 v2.0.0) Figure 3.1 Block Diagram of S5U1C17F57T1 Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 17: Connector Connector Connector

    ESEG59 EPD segment output terminal ESEG41 EPD segment output terminal ESEG58 EPD segment output terminal ESEG40 EPD segment output terminal ESEG57 EPD segment output terminal Power terminal(-) ESEG56 EPD segment output terminal Power terminal(-) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 18 Power terminal Flash memory programming P23/SCLM/RFIN0 Power terminal No connection Power terminal(-) TEST0 Test input terminal P22/SDAM/REF0 #RESET Initial reset output Power terminal(-) Power terminal(-) P21/SCLS/SENA0/#BZ DCLK DCLK/P34 Power terminal(-) Power terminal(-) Power terminal(-) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 19: Debug Interface Connector (Cn2-1~Cn2-2)

    Table 4.8 CPU Board USB Connector (CN4) Pin Assignment Table Name Function VBUS Power(+5V) USBGND Peripheral Board Connector 4.2.1 Power Connector (CN5) Table 4.9 Peripheral Board Power Connector (CN5) Pin Assignment Table Name Function Power(+) Power(-) Flash memory programming power input Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 20: General Cpu Interface Connector (Cn6)

    CN20 ESEG46(MCU) CN65 ESEG1(MCU) CN19 ESEG47(MCU) CN64 ESEG2(MCU) CN18 ESEG48(MCU) CN63 ESEG3(MCU) CN17 ESEG49(MCU) CN62 ESEG4(MCU) CN16 ESEG50(MCU) CN61 ESEG5(MCU) CN15 ESEG51(MCU) CN60 ESEG6(MCU) CN14 ESEG52(MCU) CN59 ESEG7(MCU) CN13 ESEG53(MCU) CN58 ESEG8(MCU) CN12 ESEG54(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 21 ESEG9(MCU) CN11 ESEG55(MCU) CN56 ESEG10(MCU) CN10 ESEG56(MCU) CN55 ESEG11(MCU) ESEG57(MCU) CN54 ESEG12(MCU) ESEG58(MCU) CN53 ESEG13(MCU) ESEG59(MCU) CN52 ESEG14(MCU) ESEG60(MCU) CN51 ESEG15(MCU) ESEG61(MCU) CN50 ESEG16(MCU) ESEG62(MCU) CN49 ESEG17(MCU) ESEG63(MCU) CN48 ESEG18(MCU) EBP1(MCU) CN47 ESEG19(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 22: Epd Panel Interface Connector (Cn7-2)

    ESEG33(MCU) CN11 ESEG15(Driver) CN56 ESEG34(MCU) CN10 ESEG16(Driver) CN55 ESEG35(MCU) ESEG17(Driver) CN54 ESEG36(MCU) ESEG18(Driver) CN53 ESEG37(MCU) ESEG19(Driver) CN52 ESEG38(MCU) ESEG20(Driver) CN51 ESEG39(MCU) ESEG21(Driver) CN50 ESEG40(MCU) ESEG22(Driver) CN49 ESEG41(MCU) ESEG23(Driver) CN48 ESEG42(MCU) EBP(Driver) CN47 ESEG43(MCU) ETP(Driver) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 23: Epd Panel Interface Connector Pad (Cn8-1~3)

    ESEG7(MCU) CN11 ESEG55(MCU) CN58 ESEG8(MCU) CN10 ESEG56(MCU) CN57 ESEG9(MCU) ESEG57(MCU) CN56 ESEG10(MCU) ESEG58(MCU) CN55 ESEG11(MCU) ESEG59(MCU) CN54 ESEG12(MCU) ESEG60(MCU) CN53 ESEG13(MCU) ESEG61(MCU) CN52 ESEG14(MCU) ESEG62(MCU) CN51 ESEG15(MCU) ESEG63(MCU) CN50 ESEG16(MCU) EBP1(MCU) CN49 ESEG17(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 24: Epd Panel Inerdface Connector Pad (Cn9-1)

    ESEG5(MCU) CN11 ESEG55(MCU) CN60 ESEG6(MCU) CN10 ESEG56(MCU) CN59 ESEG7(MCU) ESEG57(MCU) CN58 ESEG8(MCU) ESEG58(MCU) CN57 ESEG9(MCU) ESEG59(MCU) CN56 ESEG10(MCU) ESEG60(MCU) CN55 ESEG11(MCU) ESEG61(MCU) CN54 ESEG12(MCU) ESEG62(MCU) CN53 ESEG13(MCU) ESEG63(MCU) CN52 ESEG14(MCU) EBP1(MCU) CN51 ESEG15(MCU) ETP1(MCU) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 25: Epd Panel Interface Connector Pad (Cn9-2)

    ESEG33(MCU) CN11 ESEG15(Driver) CN56 ESEG34(MCU) CN10 ESEG16(Driver) CN55 ESEG35(MCU) ESEG17(Driver) CN54 ESEG36(MCU) ESEG18(Driver) CN53 ESEG37(MCU) ESEG19(Driver) CN52 ESEG38(MCU) ESEG20(Driver) CN51 ESEG39(MCU) ESEG21(Driver) CN50 ESEG40(MCU) ESEG22(Driver) CN49 ESEG41(MCU) ESEG23(Driver) CN48 ESEG42(MCU) EBP(Driver) CN47 ESEG43(MCU) ETP(Driver) Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 26: Epd Module Interface Connector Pad (Cn10)

    Chip select terminal for XRES Initial reset output SPI Interface terminal MFDO Serial data output terminal Power(+) for Flash memory control MFDI Serial data input terminal Flash memory for Flash memory control programming power Seiko Epson Corporation S5U1C17F57T Manual (Rev.0.9)
  • Page 27: Revision History Revision History

    Revision History Revision History Attachment-1 Code No. Page Contents All First edition Seiko Epson Corporation S5U1C17F57 Manual (Rev.0.9)
