Creamsource Sky User Manual page 9

16 BIT MODES
Scenario 6: 16 Bits - White and RGBWA
Slot No Slot Name
1 Master Level
2
3 CCT
4
5 Green/Magenta
6
7 White-Colour Crossfade
8
9 Red
10
11 Green
12
13 Blue
14
15 White
16
17 Amber
18
Scenario 7: 16 Bits - White
Slot No Slot Name
1 Master Level
2
3 CCT
4
5 Green/Magenta
6
Scenario 8: 16 Bits - White and Hue/Saturation
DMX Value
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
HI 00000 ... 05000
05001 ... 35267
LO 35268
35269 ... 65535
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
DMX Value
HI 00000 ... 65535
LO
HI 00000 ... 65535
LO
HI 00000 ... 05000
05001 ... 35267
LO 35268
35269 ... 65535
Hofmann Teknik AB | www.hofmann.se
Output Value
0 ... 100%
2200 ... 15000K
Neutral
-100 to -1 Green
Neutral
+1 to +100 Green
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
0 ... 100%
Output Value
0 ... 100%
2200 ... 15000K
Neutral
-100 to -1 Green
Neutral
+1 to +100 Green
