Creamsource Sky User Manual page 5

SPECIFICATIONS F OR F IXTURE
Model N umber
Input
Maximum A mbient T emperature
Cooling
Weight
Protec0on C lass
SPECIFICATIONS F OR P OWER S UPPLY
Model N umber
Input
Output
Maximum A mbient T emperature
Cooling
Weight
Protec0on C lass
DMX I MPLEMENTATION T ABLES
The Creamsource Sky offers a number of different DMX implementaJon scenarios, in both 8 and 16 bit resoluJons.
The acJve scenario can be changed by selecJng 'DMX Scenario' from the main menu on the fixture.
Note it is possible that some combinaJons of CCT and Green/Magenta will not be able to be accurately reproduced. This is most likely to
occur at warm colour temperatures (<2500K) combined with Minus Green. In this situaJon the light will output the closest colour it can
reach.
These DMX implementaJon tables are valid for Firmware Versions 2.3.0 and above.
Changes to DXM profiles in Firmware Versions 2.3.0:
•
Added Scenario's 11-­‐18 to solve compaJbility issues between V0 and V1 hardware.
• Adjusted HSV implementaJon to get more saturated primary colours
DMX R efresh R ate
The smoothest dimming will be achieved when the DMX refresh rate on the console is set to 40-­‐44Hz. The dimming may not be as smooth
for refresh rates above or below this.
Note o n ' Version 0 ' S ky H ardware D ifferences
The first Sky units manufactured (V0 units with serial numbers beginning in "2") have the Amber colour LEDs physically linked to the Red
colour LEDs in hardware, so they operate in tandem when the Red DMX Channel is adjusted. AdjusJng the Amber DMX Channel will have no
affect on these units.
Version 1 and above Sky's (serial number starJng in "3" or above) have the Amber channel is separated out so it can be controlled
independantly.
If u sing a m ix o f V 0 a nd V 1 S ky h ardware i n t he s ame D MX s etup a nd R GBW o r H ue/SaturaLon c ontrol i s r equired, i t i s r ecommended t o u se
scenarios 1 1-­‐18 o n a ll fi xtures, s o t hey a ll r espond t he i n t he s ame w ay. I f u sing W hite ( CCT) c ontrol o nly, t here a re n o c ompaLbility i ssues.
Scenario Bits
1 8 Bit
2 8 Bit
3 8 Bit
4 8 Bit
CSS-­‐1200-­‐C
2 c ircuits: 5 0.0V D C, M ax 1 2.0A e ach, c ombined t otal d raw 2 4A M AX
40°C
Passive ( Silent)
23kg / 5 0lbs ( head)
IP65
CSS-­‐PSU-­‐1200
90-­‐277V A C, 5 0-­‐60Hz, 1 4A @ 1 15V, 6 .6A @ 2 30V
2 c ircuits: 5 0.0V D C, 1 2.8A M AX e ach c ircuit, c ombined c apacity 2 5.6A M AX
40°C
Passive ( Silent)
13kg / 2 8lbs ( power s upply)
IP65
Description
White and RGBWA
White
White and Hue/Saturation
RGBWA
