Series
Amplifier Head
Owner's Manual
THANK YOU FOR PURCHASING A HOTONE PRODUCT!
※ In the interest of product improvement, the specifications and/or the content of
products (including but not limited to appearances, packaging design, manual content,
accessories, size, parameters and display screen), are subject to change without prior
notice. Please check with local supplier for exact offers. Specifications and features
(including but not limited to appearances, colors and size) may vary by model owing to
environmental factors, and all images are illustrative.
www.hotoneaudio.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotone Nano Legacy Series
Summary of Contents for Hotone Nano Legacy Series
- Page 1 Series Amplifier Head Owner’s Manual THANK YOU FOR PURCHASING A HOTONE PRODUCT! ※ In the interest of product improvement, the specifications and/or the content of products (including but not limited to appearances, packaging design, manual content, accessories, size, parameters and display screen), are subject to change without prior notice.
- Page 2 Front Panel Series Amplifier Head 1. INPUT: 1/4" mono jack to plug in your guitar. 2. BASS: Controls the low frequency response. 3. MIDDLE: Controls the mid frequency response. 4. TREBLE: Controls the high frequency response. 5. GAIN: Controls the gain level. 6.
- Page 3 Rear Panel 18V DC: Plug in 18V DC adapter (center negative). PHONES/LINE OUTPUT: 1/8" stereo jack, for using headphones or recording. AUX IN: 1/8" stereo jack, for connecting an external music player. FX LOOP SEND: 1/4" mono jack, connect to your effects input jack. (The Effects Loop is a patch point between the pre-amp and power amp).
- Page 4 Series Amplifier Head is a 5W Class AB Guitar Amplifier Head Features Sound inspired by Legendary VOX AC30* Extremely compact configuration for portability High quality tone with Volume and Gain controls 3 Band EQ controls for shaping your tone FX LOOP for using external effects Compatible with cabinets of different impedances ranging from 4-16 Ω...
