THANK YOU FOR PURCHASING A HOTONE PRODUCT!
FX LOOP
INPUT
BALANCED
LINE
SPEAKER
OUTPUT
OUTPUT
OUTPUT
Owner's Manual
Specifications
CAB SIM
POWER AMP
Built-in Boost: Max. +12 dB pure clean boost
Power Requirement: 18-20V DC center positive
Current Consumption: Min. 4.5A
Speaker Output: 4-16Ω, self-adaptive
Max. Output Power (19V):
75 Watts @ 4Ω / 40 Watts @ 8Ω / 20 Watts @ 16Ω
Dimensions: 190mm(D)×118.5mm(W)×53.5mm(H)
REVERB
CH A/B
BOOST
Weight: 792g (without PSU)
IMPORTANT: TURN ON FIRST, TURN OFF LAST.
Signal Path
Always mute the mixer/audio interface or turn down the volume knob on your amp
before plugging or unplugging power jacks, cables, etc.
When you're using a mixer or an audio interface, please adjust the knobs onboard
carefully to avoid signal clipping.
This unit CANNOT be supplied by phantom power.
www.hotoneaudio.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Hotone Mojo Attack
Summary of Contents for Hotone Mojo Attack
- Page 1 THANK YOU FOR PURCHASING A HOTONE PRODUCT! FX LOOP INPUT BALANCED LINE SPEAKER OUTPUT OUTPUT OUTPUT Owner's Manual Specifications CAB SIM POWER AMP Built-in Boost: Max. +12 dB pure clean boost Power Requirement: 18-20V DC center positive Current Consumption: Min. 4.5A Speaker Output: 4-16Ω, self-adaptive...
- Page 2 CH A: Hotone Mojo Diamond, inspired by legendary Fender Tweed* CH B: Hotone Heart Attack, inspired by legendary Mesa Boogie Rectifier* BASS/MIDDLE/TREBLE: Controls the low, mid and high frequency response GAIN: Controls the gain amount 0 to +12 dB of clean boost VOL.
