Spectrum Technologies WatchDog 2000 Manual

The following conventions are used in this manual:
• Quoted capital letters relate to what you will see on the WatchDog
2000 display.The actual display may use both capitals and
lowercase letters. For example, "SEE SPDS" indicates the following
will be shown on the WatchDog 2000 display.
Some letters cannot be displayed in their true form. For instance,
K's will look like capital H's. Therefore H's are always represented
in lowercase on the display. Also, an "m" requires two digit fields to
represent it in the display. For example, "KEYTIME" on the display
looks like;
About this Manual
1
• The button functions: UP, DOWN and MAIN are always in bold
type. These refer to the buttons on the thumb switch, as shown
below.
• For reference, typical route sheet entries are shown below:
4.20 SPEED 30
4.30 R TAR
This is the
AT mileage
for a speed
14.40 RESET TO 9:39:20
change or
17.00 R TR
reset
96.20 END
This is the TO mileage
for a reset
Last mileage
MAIN
UP
DOWN
This is the SPD
for a speed change
9:12:00
9:12:12
.
.
10:07:30
.
.
13:40:00
Keytime
2
