Spectrum Technologies WatchDog 2000 Series Technical Bulletin

TECHNICAL BULLETIN NO. 20110126
SUBJECT

PRODUCT FAMILY

DETAILS

Important: The clock board alone draws about
1/3 the power of the original station, so
Alkaline batteries can be expected to last 8-9
months. Use Lithium batteries ("Ultra" or
"High Energy") to obtain 12 month battery life.
1. Examine the clock board carefully to ensure
the battery is in the socket and there are no
bent pins .
2. Disconnect all sensor wires on the bottom of
the Weather Station display module.
3. Remove the 4 Phillips head screws on the
front of the module.
4. Pull the module straight out of the station
enclosure (may require light prying or
manipulation.
5. Remove the battery
cover, and remove all
batteries.
6. Flip over the display
module and locate the
microcontroller chip in its
socket. With a small
screwdriver or flat blade,
gently pry the chip out of
the socket by alternating
ends. Grasp the
microcontroller by the
ends of the black plastic,
not the pins.

Clock Board Installation Instructions

WatchDog 2000 Series Weather Stations
Page 1 of 2
January 26, 2011
