- Page 1 18V LITHIUM-ION SINGLE BATTERY CORDLESS LINE TRIMMER ASSEMBLY & OWNER'S MANUAL WARNING! Read this manual before operating your product.
- Page 2 IMPORTANT NOTES Details Thank you for purchasing your Victa product. Victa prides itself in the quality and performance of all its products. This instruction manual will aid in the assembly, safe operation and maintenance of your product. Please read the following warnings to ensure safety and the long life of your product.
-
Page 3: Table Of Contents
Table of Contents Features & Definitions Features & supplied items Safety & Handling General/Electrical/Personal safety Power Tool use and care Battery use and care Product Disposal Assembly Procedures Unpacking Handle Assembly Guard Assembly Trimmer line Assembly Cutting Head Assembly Operating Instructions Operating the machine Installing &... -
Page 4: Features & Supplied Items
FEATURES DEFINITIONS Features & Supplied Items - 18V Single Battery Line Trimmer NOTE: Refer to figure 1. Operating Handle On/Off Switch Throttle Trigger Battery Housing Front Handle Speed adjustment panel Shaft Trimmer Guard Bump Head Cut-off Blade Motor Housing Battery (not included with all products) Battery Charger (not included with all products) - Grass Trimmer Instruction/Safety Manual (not shown) - Battery &... -
Page 5: General/Electrical/Personal Safety
General Safety WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your battery-operated (cordless) power tool. Work Area Safety •... -
Page 6: Power Tool Use And Care
• Do not let familiarity gained from frequent use of similar power tools allow you to become complacent and ignore safety principles. A careless action can cause severe injury. • Do not use the machine indoors. Only store the machine indoors in a dry & secure location. -
Page 7: Battery Use And Care
Battery Use and Care • Only use machine with Briggs & Stratton 18V Batteries and Chargers. • Recharge only with the charger specified by the manufacturer. A charger that is suitable for one type of battery pack may create a risk of fire when used with another battery pack. -
Page 8: Product Disposal
Product Disposal CORRECT DISPOSAL OF THE PRODUCT Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your local authority or retailer for recycling advice. The battery contains material which is hazardous to you and the environment. It must be removed and disposed of separately at a facility that accepts lithium-ion batteries. -
Page 9: Handle Assembly
ASSEMBLY PROCEDURES Handle Assembly Fitting the handle 1. Remove all the screws from the handle. (Fig.2) 2. Position brackets on Shaft and tighten the screws.(Fig.3) Fig. 3 Fig. 2 CAUTION! Not too loose or too tight. Over tightening may damage the unit. Guard Assembly Fitting the bent shaft guard 1. -
Page 10: Trimmer Line Assembly
ASSEMBLY PROCEDURES Trimmer Line Assembly - Bump Head Upper spool Cover Housing Middle plate Spool Top of Spool Notches in top of spool 1. Press two cover clips inwards on the housing & remove the cover slowly. 2. Remove the remains of worn line from the spool (if any remains). Note: Remaining line may be sufficient to rewind and reuse if it has been tangled or has retracted back into the housing. - Page 11 ASSEMBLY PROCEDURES Trimmer Line Assembly - Bump Head Cover Cli ps Notches in top of spool Slots in middle plate Eyelet Slot Bump Head Assembly 1. Housing 2. Arbor 3. Spring Upper Spool 4. Spool 5. Eyelet (2) 6. Cover Upper Spool Middle Plate Lower Spool...
-
Page 12: Cutting Head Assembly
ASSEMBLY PROCEDURES Cutting Head Assembly Always ensure the line cutting blade on the guard is covered when fitting, changing or removing the trimmer head. Never operate the machine without a cutting head fitted. Never fit an alternative cutting head that has not been recommended by the manufacturer. -
Page 13: Operating The Machine
ASSEMBLY PROCEDURES Operating The Machine Hold the machine with your right hand on the rear handle and your left hand on the front handle. Keep a firm grip with both hands while in operation. The machine should be held at a comfortable position with the rear handle about hip height. -
Page 14: Speed Adjustment
OPERATING INSTRUCTIONS STARTING the machine: • Push and hold the ON/OFF Button on the Indication Panel (Fig. 8) until the Green LED appears. • Push the presence switch and hold it in place (Fig. 9). • While the presence switch is held, squeeze the throttle trigger to start the machine (Fig. - Page 15 OPERATING INSTRUCTIONS Trimming Procedures Trimming / Mowing • Swing trimmer with a sickle-like motion from side to side. Do not tilt the cutting head during the procedure. Test area to be trimmed for proper cutting height. Keep string head at same level for even depth of cut. Fence / Foundation Trimming •...
-
Page 16: Feeding Bump Head Line
OPERATING INSTRUCTIONS Feeding Bump Head Line To increase the length of nylon trimming line when using the Bump Head; 1. Run the trimmer at maximum RPM while firmly bumping the spool on the ground. 2. The line will come out incrementally each time head is bumped. 3. -
Page 17: Cleaning
Cleaning WARNING To prevent serious personal injury remove the battery from the machine before servicing, cleaning, or removing debris. Clean the unit using a damp cloth with a mild detergent. • Do not immerse the machine or any part of it in water. •... -
Page 18: Maintenance Chart
Maintenance Chart Refer to the following table for routine maintenance. Features Requirements • Throttle trigger Check operation • • Trimmer Visual inspection • • Cutting Head Check & clean • Bump Head Clean • • Replacement Presence trigger Check • •... -
Page 19: Troubleshooting
TROUBLESHOOTING Troubleshooting Problem Cause Solution Motor fails to run Flat battery Recharge battery when trigger is depressed Battery Refit battery disengaged Replace battery Faulty battery Excessive Cut off blade worn Replace cut off blade vibration Bumphead not Refit bumphead fitted correctly Broken drive shaft Replace drive shaft Indication Panel... -
Page 20: Product Specification
TECHNICAL SPECIFICATIONS Product Specifications Model number 80102224 Description 18V Line Trimmer Cut Diameter 330 mm Head Type Bump head Nylon Line Diameter 2.0 mm Motor Type Brushless Motor Specification 18V DC Motor Speed (rpm) 12,500 Cutting Speed (rpm) 3,500 @low... - Page 21 NOTES _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________ _________________________________________________________...
- Page 22 ©2021 Briggs & Stratton Victa is a trademark of Briggs & Stratton Australia Pty. Ltd. All rights reserved. No part of this booklet may be reproduced by any means without prior written permission. All information herein is subject to change without notice.
