ORIGINAL ASSEMBLY AND
OPERATING INSTRUCTIONS
Tubular motor
Rojaflex RB25LEU
Original assembly and operating instructions
Instructions de montage et d'utilisation originales
Instrucciones de montaje y funcionamiento originales
Istruzioni originali per il montaggio e l'uso
Originele montage- en gebruiksaanwijzing
Oryginalna instrukcja montażu i obsługi
Eredeti összeszerelési és kezelési útmutató
Rojaflex_RB25LEU_manual_V4_2022-06-15
EN
FR
ES
IT
NL
PL
HUN
Advertisement
Table of Contents
Related Manuals for rojaflex RB25LEU
Summary of Contents for rojaflex RB25LEU
- Page 1 Tubular motor Rojaflex RB25LEU With electronic limit switches and integrated radio receiver ORIGINAL ASSEMBLY AND OPERATING INSTRUCTIONS Original assembly and operating instructions Eine aktuelle Vollversion der Anleitung finden Sie hier/ You can find a current full version of the manual here/ Vous trouverez ici une version complète et actuelle du mode d‘emploi/...
-
Page 2: Table Of Contents
Herewith declares Schoenberger Germany Enterprises GmbH & Co. KG, Hohenschäftlarn, that the radio system type rojaflex tubular motor "RB25LEU" complies with the directive 2014/53/EU. The full text of the EU Declaration of Conformity is available at the following Internet address: www.rojaflex.com/konformitaetserklaerungen.html... -
Page 3: Safety Instructions
Danger to persons and damage to pro- The plant must be secured against un- perty (electric shock, short circuit). authorized operation. Take safety pre- Never use defective or damaged equip- cautions against unintentional switch- ment. Check that the drive and power adapter (charger) are intact. www.rojaflex.com... - Page 4 The range of radio controls is regulated by the legal requirements for radio systems and is influenced by structural conditions, among other things. www.rojaflex.com...
- Page 5 This applies in particular to information and environment. telecommunications technology devices such as computers and smartphones. In your own interest, please note that each end user is responsible for deleting the data on the old devices to be disposed of! www.rojaflex.com...
-
Page 6: Technical Data / Scope Of Delivery
-10 °C / +50 °C IP 20 30,9 mm ≤ 70 dB c=482 Jacket pipe diameter: RB25LEU = 25 mm 433,05 - 434,79 Scope of delivery Compare after unpacking: • the package contents with the information on the scope of delivery in these instructions. -
Page 7: Compatible Handheld And Wall Transmitters
*With the „DIP“ switch you can, depending on the radio receiver (see receiver instructions), choose between „SI“ and „SI“. (Single = one-way communication) and „BI“ (Bidirectional = two-way communication) - radio. Please follow the instructions of the respective transmitter! www.rojaflex.com... -
Page 8: Mounting
(see drawing) and is seated completely up to the stop in the groove of the base ring on the drive head. Insert the driver (2) onto the output shaft of the drive and secure it with the lock washer (3). www.rojaflex.com... -
Page 9: Mounting The Motor
Do not drill in the area of the casing pipe! Then mount the drive together with the shaft in the bearings of the equipment to be driven. Follow the instructions for the sun protection system (roller blind, screen, etc.). www.rojaflex.com... -
Page 10: Settings And Programming
2. The actuator moves UP/DOWN briefly after each keystroke during programming or the actuator beeps as feedback for a received command. 3. When programming, always wait for the actuator feedback before sending the next command. Battery switch ON / OFF www.rojaflex.com... -
Page 11: Functional Description Programming Key P1
Press the P1 key for approx. 10 Drive is in delivery seconds: condition. Drive moves 3 x UP / DOWN. ALL settings (end positions, transmitter) are deleted! Release the P1 key: Antrieb piept 3 x Direction of rotation is changed. www.rojaflex.com... -
Page 12: Programming The First Handheld Or Wall Transmitter
Afterwards, be sure to check the direction of rotation of the drive with the UP and DOWN keys! If the drive moves in the DOWN direction when the UP key is pressed, the direction of rotation of the drive must be changed (see next chapter)! www.rojaflex.com... -
Page 13: Change The Direction Of Rotation Of The Drive
Motor piept 1 x. 1 sec. press DOWN key Motor vibrates briefly beeps 1 x. on the handheld or wall key on the handheld or and beeps 6 times. transmitter. wall transmitter. Handheld transmitter is reprogrammed! Direction of rotation is changed. www.rojaflex.com... -
Page 14: Setting The End Positions (End Points)
1 x. transmitter and end position (end desired. reached, press the Release key! move the blind (the position), press the STOP key and keep drive) to the desired STOP key. it pressed. End position OPEN upper end position. is set. www.rojaflex.com... - Page 15 1 sec. 1 x. transmitter for 1 sec. 1 x. transmitter for 1 sec. ATTENTION! The end positions must then be readjus- ted! Start with the item “Activating the end position setting”. www.rojaflex.com...
-
Page 16: Setting The Intermediate Position
Down keys to control the respective set end position, e.g. to open or close the blind completely. Delete the intermediate position To delete the intermediate position, move to it (press the stop key for 3 sec.) and then repeat the “Setting the intermediate position” procedure. www.rojaflex.com... -
Page 17: Set Jog Mode
Additional handheld programmed for 1 has already been 1 second. or wall transmitter is second. programmed. programmed. Up to 20 hand-held or wall-mounted transmitters can be programmed. www.rojaflex.com... -
Page 18: Delete Handheld And Wall Transmitters
1 x. transmitter again for or wall transmitter. wall transmitter. 1 sec. ALL handheld and wall transmitters are deleted. ATTENTION! If a new hand-held or wall transmitter is subsequently programmed, the end posi- tions must also be reset! www.rojaflex.com... -
Page 19: Troubleshooting / Faq
4. Drive stops during travel before reaching the end position. End positions incorrectly set Set end positions (see page 16 and 17). Max. Operating time exceeded Operating time of the drive max. 6 minutes. Obstacle in the travel path or hangings too heavy. Check the curtain (roller blind). www.rojaflex.com... - Page 20 Our general terms and conditions apply. Membership number: If you have any questions about this product, please contact us at the following address: rojaflex is a registered trademark of Schoenberger Germany Enterprises GmbH & Co. KG Zechtraße 1-7 82069 Hohenschäftlarn...
