GreenBrook T17B Installation & Operating Instructions

Installation /Operating
Instructions for
7 Day Electronic Plug-in Timer
Model: T17B
Please read these instructions fully
before attempting installation
OPERATING
INSTRUCTIONS
• Timer uses a standard AAA size
non-rechargeable battery to back up
the timer memory function. The
battery allows for programming while
the unit is not plugged in and provides
for memory retention during power
failures.The battery back up will last at
least 150 hours.
CURRENT TIME AND
DAY SETTING
1. When the timer is powered up set
current time & day. If no display is
showing leave on charge for 30 mins &
display should then show, If not gently
press the reset button.
2. Press Y to enter function setup.
(Note: If another button is not pressed
within 10 seconds the display will
revert to the normal screen)
3. Use the + or - button to scroll to the
clock icon (flashing) and press Y to
enter the current time setting mode
(hours flashing).
4. If you keep the + or - buttons pressed
for more than 3 seconds, the display
will enter fast scroll mode.
5. Use the + or - button to adjust the
hours and press Y to confirm, minutes
will flash.
6. Use the + or - button to adjust the
minutes and press Y to confirm, day
will flash.
7. Use the + or - button to adjust the day
and press N to exit.
PROGRAMMING THE
SWITCHING TIMES
1. There are 24 ON/OFF programmes
available
2. Press the Y button twice to enter the
programme setting mode.
(Note: If another button is not pressed
within 10 seconds the display will
revert to the normal screen)
3. Default is programme 01 ON, this can
be changed if required by pressing
the + or - button to scroll through the
24 ON/OFF programmes as required,
pressing the Y will confirm the
programme.
4. Press the Y button to confirm
programme 01 ON, hours will flash.
5. Use the + or - button to adjust the
hours and press Y to confirm, minutes
will flash.
6. Use the + or - button to adjust the
minutes and press Y to confirm, days
will flash.
7. Apart from individual days of the
• Monday to Sunday
• Monday to Friday
• Saturday & Sunday
• Monday to Saturday
. • Monday + Wednesday + Friday
• Tuesday + Thursday + Saturday
• Monday + Tuesday + Wednesday
• Thursday + Friday + Saturday
8. Select day or day block as required
9. Press the + button, this will select the
10. Follow 4 to 7 above to set the 01
11. If no more programmes are
12. If more programmes are required,
13. To cancel a programme once set,
14. Repeat 13 to delete 01 OFF. This
1. Timer has a 100 hour countdown
2. Press the Y button then use the + or -
3. Use the + or - button to adjust the
4. Use the + or - button to adjust the
5. Press the N button to start the
6. Output switched to ON during the
7. Press the N button to pause the
8. To resume countdown simply press
9. Press and hold the N button for more
week, the following day
combinations of multiple day blocks
can be selected by pressing the +
or - buttons.
and press the Y button to confirm.
programme 01 OFF, press Y to
confirm.
OFF programme.(day or day block
must be the same as programme
ON)
required, press the N button to exit.
follow 3 above.
press and hold the N button for
more than 3 seconds when the
desired programme number is
flashing, i.e. to cancel programme
01 ON, press the Y button twice and
hold the N button down for more
than 3 seconds to delete. Pressing
the + button again will select the 01
OFF.
procedure can be repeated to
delete any of the 24 programmes.
TIMER COUNTDOWN
FUNCTION
feature i.e. The timer can be set to
any period from 1 minute to 100
hours and will countdown in the ON
state and turn OFF at the end of the
countdown period.
button to select the "down" icon on
the right hand side of the display,
press Y again to enter the
countdown mode.
hours and press Y to confirm, minutes
will flash.
minutes and press Y to confirm and
complete the countdown time
setting.
countdown.
countdown period.
countdown (output switched to OFF)
the N button again.
than 3 seconds to exit the
countdown function.
