- Page 1 INFRARED ZONE HEATING SYSTEM OWNER’S MANUAL Model No. GD9315BCW-NP PLEASE SAVE THESE INSTRUCTIONS WARNING: READ THIS OWNER’S MANUAL CAREFULLY BEFORE USE.
-
Page 2: Important Instructions
Thank you for choosing a RD-WORKS Infrared Zone Heating System. This owner’s manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new heater. -
Page 3: Specifications
17. Use only for intended household use as described in this manual. Any other use not recommended by the manufacturer may cause fire, electric shock, or injury to persons. The use of attachments not recommended or sold by unauthorized dealers may cause hazards. -
Page 4: Product Diagram
WARNING: This heater has a voltage rating of 120 volts. The cord has a plug as shown in A. An adapter as shown in C is available for connecting three-blade grounding-type plugs to two-slot receptacles. The grounding lug extending from the adapter must be connected to a permanent ground such as a properly grounded outlet box. - Page 5 Control Panel RCIN ℃ ℉ Timer High Power Timer ON/OFF Mode 1、Signal receiving window: For receiving remote control signal. 2、Digital display：Indicate set room temperature or time 3、Power indicator light：Indicates that the heater is receiving power from outlet. Will flash when powered “ON” 4、ON/OFF button: Powers the display on and off.
- Page 6 Remote Control Temp up button: to make set temperature rise ON/OFF button: Used for power-on or power-off Temp down button: to make set temperature decline Mode button：Used for mode selection ℃/℉ button: Button for alternating between Fahrenheit and Celsius Timer button: Used for setting timer and adjust time value of timing PREPARATION Place the heater on a firm, level surface and plug into a grounded 120V 60Hz power outlet.
- Page 7 High Mode uses 1500W; Low Mode uses 1000W. ECO mode is an Economic Energy Saving Function. When ECO mode is chosen, the heater will manage itself from less to more heating power (watts) in an attempt to maintain a constant warm 68℉(20℃). 2、Setting Desired Temperature Adjust the desired temperature by pressing the Up/Down arrows on the control panel or remote control.
- Page 8 The selected hour increments will flash for a few seconds, then revert back to the set desired temperature .The Timer indicator light will remain lit as long as the Timer is set. The heater will power OFF when the internal heater clock counts down the hour increments you set.
-
Page 9: Maintenance
MAINTENANCE 1. Turn off the power switch in the rear of the unit. 2. Unplug the unit and let it cool completely. 3. To keep the heater clean, the outer shell may be cleaned with a soft, damp cloth. You may use a mild detergent if necessary. -
Page 10: Basic Troubleshooting
STORAGE Store the heater in a cool, dry location when not in use. To prevent dust and dirt build-up, use the original packaging to repack the unit. BASIC TROUBLESHOOTING If the heater will not operate, please check the following before seeking repair advice: 1.
Need help?
Do you have a question about the GD9315BCW-NP and is the answer not in the manual?
Questions and answers
Heater doesn’t heat like it used to
@Bruce where do I get heating elements
The RD WORKS GD9315BCW-NP heater may not be heating properly due to several possible reasons:
1. Incorrect Mode Selection – Ensure the heater is set to High Mode (1500W) or Low Mode (1000W) for proper heating. If in ECO mode, the heater adjusts power automatically to maintain 68℉ (20℃), which may not provide continuous high heat.
2. Temperature Setting – Check if the desired temperature is set correctly. The heater will turn off once the room reaches the set temperature and cycle on and off to maintain it.
3. Obstructed Ventilation – Blocked air intakes or exhaust openings can reduce heating efficiency. Ensure the heater is placed on a hard surface without obstructions.
4. Power Supply Issues – Ensure the heater is plugged directly into a 120V AC outlet without using an extension cord or power strip, as these can reduce power delivery.
5. Safety Features Activated – If the heater detects overheating or an issue, it may temporarily shut down or reduce heating. Allow it to cool and restart.
6. Fan Delay Feature – When turning off, the fan runs for 3 minutes to emit remaining heat. If the heater does not resume heating afterward, check the settings.
Checking these factors should help identify and resolve the heating issue.
