Panasonic WJ-PB85T08 Instructions

Before attempting to connect or install this product,
please read these instructions carefully and save this manual for future use.
Caution
Hold this board only by its edges. Otherwise components on the board may be damaged by static electricity.
Preface
The WJ-PB85T08 On Screen Display Board is an optional board for displaying the camera title,
clock, and system status on the active monitors.
Appearance
q Monitor Output Connector (MONITOR OUT, 1 - 8)
Outputs the video signal connected to the VIDEO IN port with the character display for the
video monitor.
w Video Input Port (VIDEO IN)
Accepts the video signal from the VIDEO OUT Port on the WJ-PB85M16 Cross Point Output
Board of the Cross Point cage (MXSW).
Pin No.
25
24
13
25
12
24 23
11
23
10
22
22
9
21
8
21
20
7
19
20
6
18
5
17
19
4
16
3
15
18
2
14
1
17
16
15
14
Designation Pin No.
VIDEO 1 13
VIDEO 2 12
VIDEO 3 11
VIDEO 4 10
VIDEO 5
VIDEO 6
VIDEO 7
VIDEO 8
Not used
Not used
Not used
Not used
-1-
WJ-PB85T08
Model No.
Designation
Ground
Ground
Ground
Ground
9 Ground
8 Ground
7 Ground
6 Ground
5 Ground
4 Ground
3 Ground
2 Ground
1 Ground
Extend Card (O.S.D.)
OSD
1
2
3
4
q
5
6
7
8
MONITOR OUT
w
VIDEO IN
