Moxa Technologies MAR-2000 Hardware User Manual
Hide thumbs
Also See for MAR-2000:
- Quick installation manual (2 pages) ,
- Quick installation manual (2 pages)
Related Manuals for Moxa Technologies MAR-2000
Summary of Contents for Moxa Technologies MAR-2000
- Page 1 MAR-2000 Hardware User’s Manual Edition 2.0, February 2017 www.moxa.com/product © 2017 Moxa Inc. All rights reserved.
- Page 2 MAR-2000 Hardware User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2017 Moxa Inc. All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc.
-
Page 3: Table Of Contents
DIN Rail Assembly ..........................3-2 Hardware Connection Description ..................... 4-1 Wiring Requirements ........................... 4-2 Connecting the Power ......................... 4-2 Grounding the MAR-2000 ........................4-3 Connecting to the Network ........................4-3 Connecting a Serial Device ........................4-3 Connecting to the Console Port ......................4-4 CompactFlash ............................ -
Page 4: Introduction
RS-232/422/485 serial ports, 2 Ethernet ports, 4 digital input channels, 4 digital output channels, a CompactFlash socket, and 2 USB 2.0 ports. The MAR-2000 is particularly well-suited for rolling stock or other vehicle applications, giving a solid, convenient foundation for configuring an intelligent, cost-effective, multiple-WAN mobile communications environment. -
Page 5: Overview
The MAR-2000 offers optimal data routing with the built-in dynamic routing feature. When a train travels to a different region, it often faces different wireless interface switches, such as WiFi, UMTS and HSPA+. Through multiple-WAN support and backup, the MAR-2000 helps ensure that your wireless connections are always available. -
Page 6: Product Hardware Specifications
MAR-2000 Hardware Introduction Product Hardware Specifications Computer CPU: Intel XScale IXP435, 533 MHz OS (pre-installed): Linux 3.8.13 DRAM: 512 MB DDR2 SDRAM onboard Flash: 32 MB NOR Flash onboard to store OS 512 MB NAND Flash, up to 1 GB for OS file system, caching storage, and data logger USB: USB 2.0 hosts x 2... - Page 7 MAR-2000 Hardware Introduction Cellular Module (Cinterion PH8) Frequency Bands: GSM/GPRS/EDGE/UMTS/HSPA+ Band Options: • Five band UMTS(WCDMA/FDD) • 800/850/1900 AWS and 2100 MHz • Quad-band GSM: 850/900/1800/1900 MHz HSDPA/HSUPA Data Rates: DL: 3.6/7.2/14.4 Mbps; UL: 2.0/5.76 Mbps UMTS Data Rates: DL: max 384 Kbps; UL: max 384 Kbps EDGE Class 12: DL: max 237 Kbps;...
- Page 8 MAR-2000 Hardware Introduction Physical Characteristics Housing: SECC sheet metal (1 mm) Weight: 1.2 kg Dimensions: 200 x 57 x 120 mm (7.87 x 2.24 x 4.72 in) Mounting: DIN rail, wall Environmental Limits Operating Temperature: Standard Models: -25 to 55°C (-13 to 131°F) Wide Temp.
-
Page 9: Appearance And Dimensions
Appearance and Dimensions The following topics are covered in this chapter: Appearance Dimensions Hardware Block Diagram LED Indicators Reset Button Real Time Clock... -
Page 10: Appearance
MAR-2000 Hardware Appearance and Dimensions Appearance Front View Top View Rear View NOTE The Configuration Switch, which is for turning on the power, is available by request... -
Page 11: Dimensions
MAR-2000 Hardware Appearance and Dimensions Dimensions Unit = mm (inch) MAR-2001-T MAR-2002-T... -
Page 12: Hardware Block Diagram
Hardware Block Diagram The following block diagram shows the layout of the MAR-2000’s internal components. LED Indicators The MAR-2000 has 14 LED indicators on the top panel. Refer to the following table for information about each LED. LED Name LED Color... -
Page 13: Reset Button
Existing configuration will be erased after the you reset the device to the factory defaults." Real Time Clock The MAR-2000’s real time clock is powered by a lithium battery. We strongly recommend that you do not replace the lithium battery without help from a qualified Moxa support engineer. If you need to change the battery, contact the Moxa RMA service team. -
Page 14: Mounting Options
Mounting Options The following topics are covered in this chapter: Wall or Cabinet Mounting DIN Rail Assembly... -
Page 15: Wall Or Cabinet Mounting
Wall or Cabinet Mounting The two metal brackets that come standard with the MAR-2000 are used to attach the MAR-2000 to a wall or the inside of a cabinet. First, use two screws (M3 type, torque 4.5±0.5 kgf-cm) per bracket to attach the brackets to the bottom of the MAR-2000 (Fig. -
Page 16: Hardware Connection Description
Hardware Connection Description This section describes how to connect the MAR-2000 to serial devices for initial testing purposes. The following topics are covered in this chapter: Wiring Requirements Connecting the Power Grounding the MAR-2000 Connecting to the Network ... -
Page 17: Wiring Requirements
Connecting the Power The MAR-2000 has a 5-pin M12 connector for the 24 VDC power input (see the attention note below). The following figures show how the power input connects to an external power source. If the power is properly supplied, the Ready LED turns solid green after about five minutes. -
Page 18: Grounding The Mar-2000
Connecting a Serial Device Use properly wired serial cables to connect the MAR-2000 to serial devices. The MAR-2000’s serial ports (P1 to P2) use 9-pin male DB9 connectors. The ports can be configured for RS-232, RS-422, or 2-wire RS-485 from the MAR-2000’s management Web page. -
Page 19: Connecting To The Console Port
Hardware Connection Description Connecting to the Console Port The MAR-2000’s console port is an RS-232 4-pin header connector. Refer to the following figure for pin assignments on the console port cable. Use the CBL-4PINDB9F-100 cable included with the MAR-2000 to connect a PC to the MAR-2000’s serial console port. -
Page 20: Compactflash
MAR-2000 Hardware Hardware Connection Description CompactFlash The MAR-2000 provides one CompactFlash (CF) slot that supports CompactFlash type I/II card expansion. WARNING Be sure to power off the computer before inserting or removing the CompactFlash card. The following description explains the installation process for CompactFlash cards. -
Page 21: Sim Card
For additional storage expansion, the MAR-2000 provides two USB 2.0 ports on the rear panel. Digital Inputs/Outputs The MAR-2000 has 4 digital outputs and 4 digital inputs. The pinouts for the I/O are shown in the following figures with suggested wiring:... -
Page 22: Regulatory Approval Statements
Regulatory Approval Statements This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
