- Page 1 PRODUCT INSTALL GUIDE M4xx Series Reference No: 10001 Version: V1.9.9 Date of Version: 03/11/22 Author: Christian Ståhle Approved by: eLearning Team Translated by: Classification: MCF Internal...
-
Page 2: Table Of Contents
table of contents TABLE OF CONTENTS IMPORTANT NOTES REQUIRED TOOLS AND CONSUMABLES M4XX VERSIONS PARTS WIRING DIAGRAM M40X M41X VEHICLE SPECIFICS POWER SUPPLY +POWER +IGNITION GROUND POWER I/O CONNECTOR IGNITION SOLDERING METHOD CRIMPING TERMINAL METHOD ANTENNAS INTERNAL ANTENNAS (M41X) GSM & GSM/LTE ANTENNA (M40X) GPS ANTENNA (M40X) GSM, GSM/LTE &... - Page 3 1. table of contents I/O PROTECTION AND WARRANTY/TAMPER SEALS ATTACHING THE I/O PROTECTION WARRANTY/TAMPER STICKERS COMMISSIONING MASTER MANAGER MOBILE VEHICLE INFORMATION CONFIGURATION INSTALL INFORMATION VALIDATION SPECIALIST SOLUTIONS INPUT/OUTPUT (OPTIONAL) INPUT COMPATIBILITY TACHOFRESH (OPTIONAL) TACHOFRESH COMPATIBILITY WIRING GRITTERS (OPTIONAL) COMPATIBILITY WIRING TEMPERATURE (OPTIONAL) COMPATIBILITY WIRED PROBES WIRING...
-
Page 4: Important Notes
2. Important Notes NOTE! Read carefully this contains important information. • Before you begin installing and commissioning this equipment please ensure that you have read this manual thoroughly referring to any supplementary information provided for the OBU as required. • Failure to comply with the following Warnings, Approval and Safety information may invalidate the warranty, certification or type approval of this product. -
Page 5: Required Tools And Consumables
3. Required Tools and Consumables Torch Torx screwdrivers Plastic Lever Flat screwdrivers Multimeter Plastic Cutter Wire Cutter Wire Stripper Crimping Tool Heat Gun (Gas) Round File Drill Ratchet Soldering Iron Solder Wire Ring Terminals Cable Ties Amalgamating Reinforced Tape Heatshrink (different sizes) Tape Product Install Guide –... -
Page 6: M4Xx Versions
4. M4xx versions M400 / M404 / M414 / M410 M403 M405 M415 External Antennas Internal Antennas NOTE: For instructions that do not refer to the full M4xx series will be referred to as follows: M40x = M400, M403, M404 & M405 M400/3 = M400 &... -
Page 7: Parts
5. Parts Power Loom Security Seal 070196 071211 M4xx GPS 040215 GSM/LTE 040112 GPS/GSM 040303 GSM 040101 (M404 / M405) (M400/3) (M400/3) (M400/3) SCN4 CAN/J1587 #2 HMI Sustainability+ SCN4 CAN #1 White Label 030433 Green Label 030438 031118 Tachofresh & Gritter Parts Kline + D8 Interface D8 Cable Kline Cable... -
Page 8: Wiring Diagram
6. Wiring Diagram M40x GSM: M400/3 GSM/LTE: M404/M405 J1587 POWER LOOM K-LINE + D8 INTERFACE 4RS232 ADAPTER TACHO 1. Power (+) - 5A Fused K-LINE 2. Ground (-) 3. Ignition (+) - 5A Fused 4. Input 2 5. Input 3 6. -
Page 9: M41X
Wiring Diagram M41x J1587 POWER LOOM K-LINE + D8 INTERFACE 4RS232 ADAPTER TACHO 1. Power (+) - 5A Fused K-LINE 2. Ground (-) 3. Ignition (+) - 5A Fused 4. Input 2 5. Input 3 6. Input 4 GRITTER GRITTER 7. -
Page 10: Vehicle Specifics
BLUE Ignition(+) BROWN VEHICLE SPECIFICS Always refer and follow MICHELIN Connected Fleet’s recommended Power (+), Ignition (+), and Ground (-) connection points for the vehicle you are working on. The recommended connection points are available: • In the Vehicle guides, available on your job on Salesforce... -
Page 11: Ignition
8. Ignition It is important to differentiate between the first (accessories) stage and second (ignition) stage. You have to make sure that you connect the ignition wire to a second (ignition) stage ignition feed. If connected to the first (accessories) stage the data recorded by the M4xx will be wrong, for example idling. -
Page 12: Soldering Method
9. Soldering Method Strip about 10mm of Twist the wires together. Solder the wires together. the insulation. Insulate and waterproof the Best practise. Bad practise. connection with electrical and amalgamiting tape/heat shrink. When making multiple connections on the same loom it is good practise to space out the connection points. -
Page 13: Antennas
11. Antennas Internal antennas (M41x) GSM ANTENNA The GSM antenna in the M41x is located internally by the connectors on the side with the label. GPS ANTENNA The GPS antenna in the M41x is located internally by the LEDs on the side with the label. - Page 14 12. Antennas POSITIONING EXAMPLES Mercedes-Benz Trucks Actros & Arocs (MP4) Iveco Daily (Euro 6) Citroen Jumper/Relay & Fiat Ducato & Peugeot Boxer Renault Master 3 & Vauxhall/Opel Movano 2 Scania R (Passenger side) Fiat Doblo (2) NOTE: The M41x must be installed behind the dash trim of the vehicle and not accessible to the end user (driver).
-
Page 15: Gsm & Gsm/Lte Antenna (M40X)
(M40x)” on page 16 for examples. 7.87” 20 cm (20 cm) from the GSM The MICHELIN Connected Fleet logo on the antenna. GPS antenna must face the sky, see below. There is also an arrow on the side indicating MOUNTING the way it must face.
