- Page 1 Quick Start Guide Portable Bluetooth Speaker OontZ Dual Speaker Model Designed and Engineered By Lastest version of TheOontZ.com Quick Start Guide available online at www.theoontz.com/support...
-
Page 2: Table Of Contents
To Play with Non-Bluetooth Audio Source Devices Use the 3.5mm Audio Cable IPX5 Water Resistance Wireless Hands Free Personal Speakerphone OontZ Dual Speaker - Connect Two OontZ Angle 3 Speakers Together 17 - 21 Resetting Your OontZ Angle 3 Troubleshooting & Customer Support... -
Page 3: In The Package
In the Package Quick-Start Guide USB Type C Charging Cable Note: The USB Type C Charging Cable is packed below the cardboard insert at the end of the triangle box. Slide out the insert to locate the cable. Page 1... - Page 4 Down for 2 Seconds Important - Make sure the volume level is set high on your audio source device. The volume on the OontZ Angle 3 and your audio source device both need to be set to the highest level for the loudest volume. The volume controls on your audio source device and the speaker work independently of each other.
-
Page 5: Lights
AUX IN Jack Lit White/Orange when the speaker is the second speaker connected in OontZ Dual Speaker - With a second OontZ Angle 3 speaker (sold separately) you can wirelessly connect both speakers together to play with OontZ Dual Speaker. -
Page 6: Connectors
Connectors Built-in Mic for Speakerphone AUX IN Jack USB Type C Charging Connector Rubber Flap Note: The rubber flap needs - covers connectors to be closed to keep the - pull gently from the bottom to access speaker water resistant connectors, it is a snug fit to provide water resistance Page 4... -
Page 7: Play Horizontally Or Vertically
Play Horizontally or Vertically Play Horizontally Play Vertically Controls on side Controls on top Dual Precision Stereo Drivers Passive Bass Radiator – Has its own grille – Faces bass away from Dual Precision Stereo Drivers – Rich bass does not interfere with Mids and Highs Page 5... -
Page 8: Battery Features
- For maximum playtime, fully charge the battery. - You can play while charging. Power Saving Feature - When playing from battery power the OontZ Angle 3 will turn off after 15 minutes of not playing audio to conserve the battery charge. * Low Charge Remaining... -
Page 9: Charging The Battery
Charging the Battery - Insert the small end of the USB Type C Charging Cable into the USB Type C Charging Connector as Lit Red when charging: shown. - Slowly flashing Red - Insert the larger end of the USB battery is charging Type C Charging cable into a USB wall charger for a Smartphone or... - Page 10 Insert the larger end of the USB Type C Charging Cable into a USB wall charger for a Smartphone or iPhone (USB wall charger* that is 5V 3.0A maximum), or a USB port on your laptop/computer to charge the OontZ Angle 3 battery. Only use a USB wall charger that is UL listed. A USB wall charger will have the logo printed on it.
-
Page 11: Turning On And Off
Turning On and Off Turn ON Press and Release the Power Button Red Light turns on - will turn off after 3 seconds if playing from battery power Blue Light turns on - Flashing Blue The speaker is turned on and is in pairing mode - Solid Blue The speaker is turned on and has connected to an audio source device and is ready to play... - Page 12 Pair & Connect -- Step 1 - Make sure your OontZ Angle 3 battery has a sufficient charge, it is not able to connect when the charge is too low. - Your device needs to be within 100 unobstructed feet of the OontZ Angle 3 to pair and connect. If there is an issue when connecting please move your device closer to the speaker, then pair and connect.
- Page 13 - Go to Settings > Bluetooth, check Bluetooth is on - Select 'OontZ Angle 3 DS xxx' when it appears under DEVICES (xxx: 3 characters which are unique to your speaker) - Your device will connect in a few seconds...
-
Page 14: Pair & Connect -- Step 2
- Select the 'OontZ Angle 3 DS xxx' (xxx: 3 characters unique to your speaker) when it appears - The OontZ Angle 3 will make a 'ding' sound when connected To connect the next time, turn on the OontZ Angle 3 and say "Alexa, connect my speaker" or "Alexa, pair" Page 12... -
Page 15: From Your Amazon Echo Device
- or say "Alexa, disconnect my speaker" and the OontZ Angle 3 will automatically turn off after 15 minutes. - When you want to connect and play to the speaker again turn on the OontZ Angle 3 and say "Alexa, connect my speaker"... -
Page 16: To Play With Non-Bluetooth Audio Source Devices Use The 3.5Mm Audio Cable
- You are now ready to play. Important: The Bluetooth on the OontZ Angle 3 is disabled when a 3.5mm audio cable is connected to the speaker. You need to remove the 3.5mm audio cable from the speaker in order to connect to a Bluetooth device. -
Page 17: Ipx5 Water Resistance
Charging Cable, never use the speaker in the shower, bath, or near water, to prevent risk of electric shock. IPX5 rating - The OontZ Angle 3 can resist gentle water spray & splash but cannot be partially or fully submerged or left in a wet environment for an extended period of time, any of which could cause unrepairable damage to the speaker. -
Page 18: Wireless Hands Free Personal Speakerphone
Wireless Hands Free Personal Speakerphone - The Wireless Hands Free Personal Speakerphone feature works over Bluetooth with Smartphones and iPhones only - This feature is not supported when connected to PCs, laptops, Apple Mac or other types of devices. To answer an Incoming Call / To End a Call - Press and Release the Bluetooth Button To Reject an Incoming Call - Press and Hold Down the Bluetooth Button... - Page 19 OontZ Dual Speaker - Connect two OontZ Angle 3 Speakers Together Play your music wirelessly through both speakers up to 66 feet apart Left Channel - Right Channel Bluetooth for playing music for stereo separation Right Channel Left Channel Bluetooth...
- Page 20 - After a few seconds the Play Control Speaker will say “Left Channel” and the second speaker will say “Right Channel”. The Play Control Speaker speaker light will remain solid Blue and the second speaker light will be solid White. The OontZ Angle 3 speakers will be connected together for Left Channel - Right Channel and you are ready to play.
