Relion
650 SERIES
Busbar protection REB650
Version 1.1 ANSI
Technical manual

Advertisement

Table of Contents
loading

Related Manuals for ABB Relion 650 Series

Summary of Contents for ABB Relion 650 Series

  • Page 1 ® Relion 650 SERIES Busbar protection REB650 Version 1.1 ANSI Technical manual...
  • Page 3 Document ID: 1MRK 505 263-UUS Issued: November 2019 Revision: A Product version: 1.1 © Copyright 2011 ABB. All rights reserved...
  • Page 4 Copyright This document and parts thereof must not be reproduced or copied without written permission from ABB, and the contents thereof must not be imparted to a third party, nor used for any unauthorized purpose. The software or hardware described in this document is furnished under a license and may be used or disclosed only in accordance with the terms of such license.
  • Page 5 In case any errors are detected, the reader is kindly requested to notify the manufacturer. Other than under explicit contractual commitments, in no event shall ABB be responsible or liable for any loss or damage resulting from the use of this manual or the application of the equipment.
  • Page 6 Directive 2004/108/EC) and concerning electrical equipment for use within specified voltage limits (Low-voltage directive 2006/95/EC). This conformity is the result of tests conducted by ABB in accordance with the product standards EN 50263 and EN 60255-26 for the EMC directive, and with the product standards EN 60255-1 and EN 60255-27 for the low voltage directive.

  • Page 7: Table Of Contents

    Basic part for LED indication module................... 38 4.3.1 Identification........................... 38 4.3.2 Function block..........................39 4.3.3 Signals...............................39 4.3.4 Settings............................40 LCD part for HMI function keys control module.................40 4.4.1 Identification........................... 40 4.4.2 Function block..........................40 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 8 6.1.8 Technical data..........................70 Four step residual overcurrent protection EF4PTOC (51N/67N)..........70 6.2.1 Identification ..........................70 6.2.2 Functionality............................ 70 6.2.3 Function block..........................71 6.2.4 Signals............................... 71 6.2.5 Settings............................. 72 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 9 Pole discrepancy signaling from circuit breaker..............96 6.5.7.2 Unsymmetrical current detection..................97 6.5.8 Technical data..........................97 Negative sequence based overcurrent function DNSPTOC (46)..........97 6.6.1 Identification........................... 97 6.6.2 Functionality............................98 6.6.3 Function block..........................98 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 10 Two step residual overvoltage protection ROV2PTOV (59N)..........116 7.3.1 Identification..........................116 7.3.2 Functionality...........................116 7.3.3 Function block..........................116 7.3.4 Signals..............................117 7.3.5 Settings............................117 7.3.6 Monitored data..........................118 7.3.7 Operation principle........................118 7.3.7.1 Measurement principle......................118 7.3.7.2 Time delay..........................119 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 11 Signals............................136 9.1.2.5 Settings............................. 136 9.1.3 Local remote LOCREM......................... 136 9.1.3.1 Identification ........................... 136 9.1.3.2 Functionality..........................136 9.1.3.3 Function block.......................... 137 9.1.3.4 Signals............................137 9.1.3.5 Settings............................137 9.1.4 Local remote control LOCREMCTRL..................138 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 12 Function block..........................149 9.5.4 Signals.............................149 9.5.5 Settings............................149 9.5.6 Operation principle........................150 Automation bits AUTOBITS......................150 9.6.1 Identification..........................150 9.6.2 Functionality...........................151 9.6.3 Function block..........................151 9.6.4 Signals............................. 151 9.6.5 Settings............................153 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 13 Operation principle........................162 10.1.7 Technical data..........................163 10.2 Trip matrix logic TMAGGIO......................163 10.2.1 Identification..........................163 10.2.2 Functionality..........................163 10.2.3 Function block..........................164 10.2.4 Signals.............................164 10.2.5 Settings............................165 10.2.6 Operation principle........................166 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 14 Monitored data..........................184 10.6.7 Operation principle........................184 10.7 Integer to boolean 16 conversion IB16A..................185 10.7.1 Identification..........................185 10.7.2 Functionality..........................185 10.7.3 Function block..........................185 10.7.4 Signals.............................186 10.7.5 Settings............................186 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 15 Functionality..........................196 11.4.2 Measurements CVMMXN......................198 11.4.2.1 Identification ...........................198 11.4.2.2 Function block..........................198 11.4.2.3 Signals............................198 11.4.2.4 Settings............................. 199 11.4.2.5 Monitored data........................203 11.4.3 Phase current measurement CMMXU..................203 11.4.3.1 Identification ...........................203 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 16 Technical data..........................225 11.5 Event Counter CNTGGIO........................225 11.5.1 Identification..........................225 11.5.2 Functionality..........................225 11.5.3 Function block..........................225 11.5.4 Signals.............................226 11.5.5 Settings............................226 11.5.6 Monitored data..........................226 11.5.7 Operation principle........................227 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 17 Recording times........................251 11.6.6.9 Analog signals.......................... 252 11.6.6.10 Binary signals........................... 254 11.6.6.11 Trigger signals......................... 254 11.6.6.12 Post Retrigger..........................255 11.6.7 Technical data..........................255 11.7 Indications............................256 11.7.1 Functionality..........................256 11.7.2 Function block..........................256 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 18 Identification..........................264 11.12.2 Functionality..........................264 11.12.3 Function block..........................264 11.12.4 Signals.............................264 11.12.5 Settings............................265 11.12.6 Operation principle........................265 11.13 Station battery supervision SPVNZBAT..................265 11.13.1 Identification..........................265 11.13.2 Function block..........................266 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 19 Remaining life of the circuit breaker................... 283 11.16.7.7 Circuit breaker spring charged indication................. 284 11.16.7.8 Gas pressure supervision...................... 284 11.16.8 Technical data..........................285 11.17 Measurands for IEC 60870-5-103 I103MEAS................285 11.17.1 Functionality..........................285 11.17.2 Function block..........................286 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 20 11.24.1 Functionality..........................295 11.24.2 Function block..........................295 11.24.3 Signals.............................296 11.24.4 Settings............................296 Section 12 Metering......................297 12.1 Pulse counter PCGGIO........................297 12.1.1 Identification..........................297 12.1.2 Functionality..........................297 12.1.3 Function block..........................297 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 21 Signals............................. 312 13.5.5 Settings............................313 13.5.6 Operation principle ........................313 13.6 GOOSE function block to receive an integer value GOOSEINTRCV........313 13.6.1 Identification..........................313 13.6.2 Functionality..........................313 13.6.3 Function block..........................314 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 22 Operation principle........................324 14.2.4.1 Internal signals........................326 14.2.4.2 Run-time model........................328 14.2.5 Technical data..........................329 14.3 Time synchronization........................329 14.3.1 Functionality..........................329 14.3.2 Time synchronization TIMESYNCHGEN................... 329 14.3.2.1 Identification..........................329 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 23 Function block..........................340 14.5.4 Signals............................340 14.5.5 Settings............................340 14.5.6 Operation principle........................340 14.6 Change lock function CHNGLCK ....................341 14.6.1 Identification..........................341 14.6.2 Functionality..........................342 14.6.3 Function block..........................342 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 24 Operation principle........................352 14.12 Global base values GBASVAL......................352 14.12.1 Identification..........................352 14.12.2 Functionality..........................352 14.12.3 Settings............................353 14.13 Authority check ATHCHCK......................353 14.13.1 Identification..........................353 14.13.2 Functionality..........................353 14.13.3 Settings............................353 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 25 15.4.3 Optical serial rear connection....................372 15.4.4 Communication interfaces and protocols................372 15.4.5 Recommended industrial Ethernet switches................372 15.5 Connection diagrams........................373 15.5.1 Connection diagrams for REB650 A03A...................373 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 26 EMC compliance..........................391 Section 19 Time inverse characteristics................393 19.1 Application............................393 19.2 Operation principle........................395 19.2.1 Mode of operation........................395 19.3 Inverse time characteristics......................398 Section 20 Glossary......................423 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 27: Introduction

    The system engineer must have a thorough knowledge of protection systems, protection equipment, protection functions and the configured functional logic in the IEDs. The installation and commissioning personnel must have a basic knowledge in handling electronic equipment. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 28: Product Documentation

    IED should be commissioned. The operation manual contains instructions on how to operate the IED once it has been commissioned. The manual provides instructions for monitoring, controlling and setting the IED. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 29: Document Revision History

    Communication protocol manual, IEC 61850 1MRK 511 242-UUS Communication protocol manual, IEC 60870-5-103 1MRK 511 243-UUS Point list manual, DNP3 1MRK 511 244-UUS Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 30: Symbols And Conventions

    Abbreviations and acronyms in this manual are spelled out in the glossary. The glossary also contains definitions of important terms. • Push button navigation in the LHMI menu structure is presented by using the push button icons, for example: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 31 • Dimensions are provided both in inches and mm. If it is not specifically mentioned then the dimension is in mm. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 33: Available Functions

    52PD Pole discordance protection DNSPTOC Negative sequence based overcurrent function Voltage protection UV2PTUV Two step undervoltage protection OV2PTOV Two step overvoltage protection ROV2PTOV Two step residual overvoltage protection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 34: Control And Monitoring Functions

    Configurable logic blocks, set-reset memory flip-flop gate RSMEMORY Configurable logic blocks, reset-set memory flip-flop gate FXDSIGN Fixed signal function block B16I Boolean 16 to Integer conversion Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 35 IED status for IEC60870-5-103 I103SUPERV Supervison status for IEC60870-5-103 I103USRDEF Status for user defined signals for IEC60870-5-103 Metering PCGGIO Pulse counter logic ETPMMTR Function for energy calculation and demand handling Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 36: Designed To Communicate

    Setting group handling ACTVGRP Parameter setting groups TESTMODE Test mode functionality CHNGLCK Change lock function TERMINALID IED identifiers PRODINF Product information PRIMVAL Primary system values Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 37 FTP access with password DOSFRNT Denial of service, frame rate control for front port DOSLAN1 Denial of service, frame rate control for LAN1 DOSSCKT Denial of service, socket flow control Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 39: Analog Inputs

    Negative value of current or power means quantity direction out from the object. Directional conventions for directional functions (see figure 2) Forward means direction into the object. • Reverse means direction out from the object. • Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 40: Settings

    TRM - Channel 4 TRM - Channel 5 TRM - Channel 6 TRM - Channel 7 TRM - Channel 8 TRM - Channel 9 TRM - Channel 10 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 41 ToObject= towards protected object, ToObject FromObject= the opposite CTsec1 0.1 - 10.0 Rated CT secondary current CTprim1 1 - 99999 1000 Rated CT primary current Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 42 VTprim9 0.001 - 9999.999 0.001 132.000 Rated VT primary voltage VTsec10 0.001 - 999.999 0.001 Rated VT secondary voltage VTprim10 0.001 - 9999.999 0.001 Rated VT primary voltage Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 43: Local Human-Machine-Interface Lhmi

    BypassCommands Enable bypass of commands Local HMI signals 4.2.1 Identification GUID-03AB7AEE-87D3-4F3C-B6B9-B1EB1B538E38 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Local HMI signals LHMICTRL Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 44: Function Block

    ANSI/IEEE C37.2 identification identification device number Basic part for LED indication module LEDGEN Basic part for LED indication module GRP1_LED1 - GRP1_LED15 GRP2_LED1 - GRP2_LED15 GRP3_LED1 - GRP3_LED15 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 45: Function Block

    LEDGEN Output signals Name Type Description NEWIND BOOLEAN New indication signal if any LED indication input is set BOOLEAN A pulse is provided when the LEDs are acknowledged Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 46: Settings

    LCD part for HMI Function Keys FNKEYMD1 - Control module FNKEYMD5 4.4.2 Function block GUID-A803A728-5CFC-4606-98E4-793E873B99D4 v2 FNKEYMD1 ^LEDCTL1 ^FKEYOUT1 IEC09000327 V1 EN-US Figure 6: FNKEYMD1 function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 47: Signals

    Values (Range) Unit Step Default Description Type Disabled Disabled Function key type Menu shortcut Control MenuShortcut Main menu Main menu Events Measurements Diagnostics Disturbance records Clear Single Line Diagram Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 48: Operation Principle

    The LHMI includes a graphical monochrome display with a resolution of 320 x 240 pixels. The character size can vary. The display view is divided into four basic areas. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 49 If text, pictures or other items do not fit in the display, a vertical scroll bar appears on the right. The text in content area is truncated from the beginning if it does not fit in the display horizontally. Truncation is indicated with three dots. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 50 The LED is connected to the required signal with PCM600. GUID-11D6D98C-A2C9-4B2C-B5E0-FF7E308EC847 V1 EN-US Figure 10: Function button panel The alarm LED panel shows on request the alarm text labels for the alarm LEDs. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 51: Leds

    The push-buttons are also used to acknowledge alarms, reset indications, provide help and switch between local and remote control mode. The keypad also contains programmable push-buttons that can be configured either as menu shortcut or control buttons. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 52 Section 4 1MRK 505 263-UUS A Local Human-Machine-Interface LHMI GUID-23A12958-F9A5-4BF1-A31B-F69F56A046C7 V2 EN-US Figure 12: LHMI keypad Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 53 LHMI keypad with object control, navigation and command push-buttons and RJ-45 communication port 1...5 Function button Close Open Escape Left Down Right Enter Remote/Local Uplink LED Not in use Multipage Menu Clear Help Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 54: Led

    From local HMI • The active indications can be acknowledged/reset manually. Manual acknowledgment and manual reset have the same meaning and is a common signal for all the operating Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 55 This sequence follows all the time, with a steady light, the corresponding input signals. It does not react on acknowledgment or reset. Every LED is independent of the other LEDs in its operation. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 56 The low priority signal will be shown as acknowledged when the high priority signal resets. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 57 GUID-071B9EB5-A1D2-49C5-9458-4D21B7E068BE v2 If an indication with higher priority appears after acknowledgment of a lower priority indication the high priority indication will be shown as not acknowledged according to Figure Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 58 That means if an indication with higher priority has reset while an indication with lower priority still is active at the time of reset, the LED will change color according to Figure Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 59 IEC01000239 V2 EN-US Figure 23: Operating sequence 6 (LatchedReset-S), two indications within same disturbance Figure 24 shows the timing diagram for a new indication after tRestart time has elapsed. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 60 IEC01000241 V2 EN-US Figure 25: Operating sequence 6 (LatchedReset-S), two indications within same disturbance but with reset of activating signal between Figure 26 shows the timing diagram for manual reset. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 61: Function Keys

    The operation mode is set individually for each output, either OFF, TOGGLE or PULSED. Mode 0 (OFF) This mode always gives the output the value 0 (FALSE). Changes on the IO attribute are ignored. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 62 (they can be red, yellow or green). Each of these LEDs are controlled by three inputs, which are prioritized in the following order: Red - Yellow - Green Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 63 1MRK 505 263-UUS A Section 4 Local Human-Machine-Interface LHMI INPUT OUTPUT YELLOW GREEN Function key LED color yellow green Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 65: Differential Protection

    PID-2453-INPUTSIGNALS v4 Table 16: HZPDIF (87) Input signals Name Type Default Description GROUP Group signal for current input SIGNAL BLOCK BOOLEAN Block of function BLKTR BOOLEAN Block of trip Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 66: Settings

    HZPDIF (87), see figure 31. It is a simple one step function with an additional lower alarm level. By activating inputs, the HZPDIF (87) function can either be blocked completely, or only the trip output. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 67: Technical Data

    15 ms typically at 0 to 10 x V Reset time 90 ms typically at 10 to 0 x V Critical impulse time 2 ms typically at 0 to 10 x V Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 69: Current Protection

    V3P* TRST1 BLOCK TRST2 BLK1 TRST3 BLK2 TRST4 BLK3 PICKUP BLK4 PU_ST1 PU_ST2 PU_ST3 PU_ST4 PU_A PU_B PU_C ANSI08000002-1-en.vsd ANSI08000002 V1 EN-US Figure 32: OC4PTOC (51/67) function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 70: Signals

    PU_ST4 BOOLEAN Start signal from step 4 PU_A BOOLEAN Pickup signal from phase A PU_B BOOLEAN Pickup signal from phase B PU_C BOOLEAN Pickup signal from phase C Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 71: Settings

    5 - 2500 Phase current operate level for step3 in % of IBase 0.000 - 60.000 0.001 0.800 Definite time delay of step 3 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 72 Table 24: OC4PTOC (51_67) Non group settings (basic) Name Values (Range) Unit Step Default Description GlobalBaseSel 1 - 6 Selection of one of the Global Base Value groups MeasType Selection between DFT and RMS measurement Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 73: Monitored Data

    PICKUP, PU_STx, PU_A, PU_B and PU_C are, without delay, activated. Output signals PU_A, PU_B and PU_C are common for all steps. This means that the Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 74 (85%) and a memory voltage (15%). The following combinations are used. Phase-phase short circuit: ref_AB dir_AB ref_BC dir_BC –V ref_CA dir_CA Phase-ground short circuit: ref_A dir_A ref_B dir_B ref_C dirC Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 75 All four steps in OC4PTOC (51/67) can be blocked from the binary input BLOCK. The binary input BLKx (x=1, 2, 3 or 4) blocks the operation of respective step. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 76: Technical Data

    The four step residual overcurrent protection (EF4PTOC, 51N/67N) has independent inverse time delay settings for step 1 and 4. Step 2 and 3 are always definite time delayed. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 77: Function Block

    Block of step 1 (start and trip) BLK2 BOOLEAN Block of step 2 (start and trip) BLK3 BOOLEAN Block of step 3 (start and trip) BLK4 BOOLEAN Block of step 4 (start and trip) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 78: Settings

    Second harmonic restrain operation in % of IN magnitude DirModeSel1 Disabled Non-directional Directional mode of step 1 (off, non- Non-directional directional, forward, reverse) Forward Reverse Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 79 1 - 10000 Minimum operate current for step 3 in % of IBase HarmRestrain3 Disabled Enabled Enable block of step 3 from harmonic Enabled restrain Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 80 Table 30: EF4PTOC (51N_67N) Non group settings (basic) Name Values (Range) Unit Step Default Description GlobalBaseSel 1 - 6 Selection of one of the Global Base Value groups Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 81: Monitored Data

    CT input of the IED in PCM600). In such case the pre-processing block will calculate 3I from the first three inputs into the pre-processing block by using the following formula: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 82: Internal Polarizing

    This phasor is used together with the phasor of the operating current, in order to determine the direction to the ground fault Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 83 Dual polarizing When dual polarizing is selected the function will use the vectorial sum of the voltage based and current based polarizing in accordance with the following formula: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 84: External Polarizing For Ground-Fault Function

    Type of operating characteristic. By this parameter setting it is possible to select inverse or definitive time delay for step 1 and 4 separately. Step 2 and 3 are always definite time delayed. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 85: Directional Supervision Element With Integrated Directional Comparison Function

    When The operating and polarizing quantity are then used inside the directional element, as shown in figure 36, in order to determine the direction of the ground fault. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 86 These signals shall be used for communication based ground-fault teleprotection communication schemes (permissive or blocking). Simplified logic diagram for directional supervision element with integrated directional comparison step is shown in figure 37: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 87: Technical Data

    I < I Minimum operate time for (0.000-60.000) s ± 0.5% ± 25 ms inverse characteristics Timers (0.000-60.000) s ± 0.5% ±25 ms Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 88: Thermal Overload Protection, Two Time Constants Trpttr (49)

    Two warning pickup levels are available. This enables actions in the power system to be done before dangerous temperatures are reached. If the temperature continues to increase to the trip value, the protection initiates a trip of the protected transformer/generator. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 89: Function Block

    Trip Signal PICKUP BOOLEAN Pickup signal ALARM1 BOOLEAN First level alarm signal ALARM2 BOOLEAN Second level alarm signal LOCKOUT BOOLEAN Lockout signal WARNING BOOLEAN Trip within set warning time Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 90: Settings

    Table 36: TRPTTR (49) Non group settings (basic) Name Values (Range) Unit Step Default Description GlobalBaseSel 1 - 6 Selection of one of the Global Base Value groups Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 91: Monitored Data

    If this calculated relative temperature is larger than the relative temperature level corresponding to the set operate (trip) current a pickup output signal PICKUP is activated. The actual temperature at the actual execution cycle is calculated as: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 92 è ø final (Equation 11) EQUATION1176 V1 EN-US The calculated time to trip can be monitored as it is exported from the function as a real figure TTRIP. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 93 When the current is so high that it has given a pickup signal PICKUP, the estimated time to trip is continuously calculated and given as analog output TTRIP. If this calculated time get less than the setting time Warning, set in minutes, the output WARNING is activated. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 94 WARNING if time to trip < set value trip Calculation of time to TRESLO reset of lockout ANSI08000040-1-en.vsd ANSI08000040 V1 EN-US Figure 39: Functional overview of TRPTTR (49) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 95: Technical Data

    When those currents exceed the user defined settings, the function is activated. These conditions increase the security of the back-up trip command. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 96: Function Block

    PID-1160-OUTPUTSIGNALS v5 Table 40: CCRBRF (50BF) Output signals Name Type Description TRBU BOOLEAN Back-up trip by breaker failure protection function TRRET BOOLEAN Retrip by breaker failure protection function Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 97: Settings

    Name Type Values (Range) Unit Description REAL Measured current in phase A REAL Measured current in phase B REAL Measured current in phase C REAL Measured residual current Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 98: Operation Principle

    Internal logical signals PU_A, PU_B, PU_C have logical value 1 when current in respective phase has Pickup_PH . magnitude larger than setting parameter Internal logical signal PU_N has logical value 1 when neutral current has magnitude larger than Pickup_N . setting parameter Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 99: Technical Data

    The pole discrepancy function operates based on information from the circuit breaker logic with additional criteria from unsymmetrical phase currents when required. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 100: Function Block

    0.000 - 60.000 0.001 0.300 Time delay between trip condition and trip signal ContactSel Disabled Disabled Contact function selection PD signal from CB Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 101: Monitored Data

    43. C.B. poleDiscrepancy Signal from C.B. ANSI_en05000287.vsd ANSI05000287 V1 EN-US Figure 43: Pole discrepancy external detection logic Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 102: Pole Discrepancy Signaling From Circuit Breaker

    If one or two poles of the circuit breaker have failed to open or to close (pole discrepancy status), then the function input EXTPDIND is activated from the pole discrepancy signal in figure 43. After Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 103: Unsymmetrical Current Detection

    GUID-66A7DE2F-EBD6-4601-B0F7-2B568968EA33 v1 6.6.1 Identification GUID-F53558B3-4614-4502-82DD-B7BA07FB2723 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Negative sequence based DNSPTOC overcurrent function 3I2> IEC09000132 V2 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 104: Functionality

    BOOLEAN Enable signal for current multiplier - step1 (OC1) BLKOC2 BOOLEAN Block of over current function OC2 ENMLTOC2 BOOLEAN Enable signal for current multiplier - step 2 (OC2) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 105: Settings

    Low votlage level action for step 1 (Non- Block directional, Block, Memory) Memory Operation_OC2 Disabled Disabled Operation DISABLE/ENABLE for step 2 Enabled (OC2) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 106: Monitored Data

    DirMode_OC1 and DirMode_OC2 . At too low polarizing voltage the overcurrent feature can be either blocked, non-directional or use the voltage memory. This is controlled by settings ActLowVolt1_VM and ActLowVolt2_VM . Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 107: Technical Data

    10 ms typically at 0 to 2 x I 2 ms typically at 0 to 10 x I Impulse margin time 15 ms typically Dynamic overreach < 10% at t = 300 ms Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 109: Voltage Protection

    Function block M13794-3 v5 UV2PTUV (27) V3P* TRIP BLOCK TRST1 BLK1 TRST2 BLK2 PICKUP PU_ST1 PU_ST1_A PU_ST1_B PU_ST1_C PU_ST2 ANSI09000285-1-en.vsd ANSI09000285 V1 EN-US Figure 46: UV2PTUV (27) function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 110: Signals

    0.01 5.00 Definite time delay of step 1 t1Min 0.000 - 60.000 0.001 5.000 Minimum operate time for inverse curves for step 1 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 111: Monitored Data

    ConnType . The voltage related settings are made in of the measuring is done by the parameter percent of base voltage which is set in kV phase-to-phase voltage. This means operation for phase-to-ground voltage under: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 112: Measurement Principle

    EQUATION1608 V1 EN-US The lowest voltage is always used for the inverse time delay integration. The details of the different inverse time characteristics are shown in section 19.3"Inverse time characteristics". Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 113: Blocking

    3 and 3 out of 3 criteria to fulfill the PICKUP condition. The design of Two step undervoltage protection UV2PTUV (27) is schematically shown in Figure Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 114: Technical Data

    Inverse time characteristics for low See table and high step, see table Definite time delay, step 1 (0.00 - 6000.00) s ± 0.5% ± 25 ms Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 115: Two Step Overvoltage Protection Ov2Ptov (59)

    Function block M13803-3 v5 OV2PTOV (59) V3P* TRIP BLOCK TRST1 BLK1 TRST2 BLK2 PICKUP PU_ST1 PU_ST1_A PU_ST1_B PU_ST1_C PU_ST2 ANSI09000278-1-en.vsd ANSI09000278 V1 EN-US Figure 48: OV2PTOV function block (59) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 116: Signals

    Voltage start value (DT & IDMT) in % of VBase for step 1 0.00 - 6000.00 0.01 5.00 Definite time delay of step 1 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 117: Monitored Data

    Step 2 is always definite time delayed. VBase , which is set The voltage related settings are made in percent of the global set base voltage in kV, phase-to-phase. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 118: Measurement Principle

    C The type A curve is described as: V Vpickup − > Vpickup > (Equation 20) EQUATION1625 V2 EN-US The type B curve is described as: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 119: Blocking

    PICKUP output is reset. 7.2.7.3 Blocking M15330-20 v4 It is possible to block two step overvoltage protection (OV2PTOV ,59) partially or completely, by binary input signals where: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 120: Design

    1 out of 3 , 2 out of 3 or 3 out of 3 criteria to fulfill the PICKUP condition. The design of Two step overvoltage protection (OV2PTOV ,59) is schematically described in Figure Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 121: Technical Data

    ± 0.5% of V at V > V Reset ratio >95% Inverse time characteristics for low See table and high step, see table Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 122: Two Step Residual Overvoltage Protection Rov2Ptov (59N)

    Step 2 is always definite time delayed. 7.3.3 Function block M13812-3 v5 ROV2PTOV (59N) V3P* TRIP BLOCK TRST1 BLK1 TRST2 BLK2 PICKUP PU_ST1 PU_ST2 ANSI09000273_1_en.vsd ANSI09000273 V1 EN-US Figure 51: ROV2PTOV (59N) function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 123: Signals

    Minimum operate time for inverse curves for step 1 0.05 - 1.10 0.01 0.05 Time multiplier for the inverse time delay for step 1 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 124: Monitored Data

    Pickup1 and The residual voltage is measured continuously, and compared with the set values, Pickup2 . To avoid oscillations of the output PICKUP signal, a hysteresis has been included. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 125: Time Delay

    BLOCK: blocks all outputs BLK1: blocks all pickupand trip outputs related to step 1 BLK2: blocks all pickup and trip inputs related to step 2 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 126: Design

    4 input GRPx_N (x is equal to instance number 2 to 12) on the SMAI, VN is this signal else VN is the vectorial sum of the three inputs GRPx_A to GRPx_C. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 127: Technical Data

    Reset time, pickup function 40 ms typically at 2 to 0 x V Critical impulse time 10 ms typically at 0 to 2 x V Impulse margin time 15 ms typically Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 129: Secondary System Supervision

    8.1.3 Function block M13678-3 v5 SDDRFUF I3P* BLKZ V3P* BLKV BLOCK DLD1PH MCBOP DLD3PH ANSI08000220-1-en.vsd ANSI08000220 V1 EN-US Figure 53: SDDRFUF function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 130: Signals

    Pickup of negative sequence overvoltage element in % of VBase 3I2PU 1 - 100 Pickup of negative sequence undercurrent element in % of IBase Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 131: Monitored Data

    (see figure 54) • the zero-sequence voltage 3V • the zero-sequence current 3I • the negative sequence current 3I • the negative sequence voltage 3V Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 132: Delta Current And Delta Voltage Detection

    The following quantities are calculated in all three phases: • The change in voltage DV • The change in current DI Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 133 If this is considering to be an important disadvantage, connect the 52a input to FALSE. In this way only the first criterion can activate the delta function. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 134 DVDI detection Phase 3 Same logic as for phase 1 a<b a>b a<b a>b a<b a>b FuseFailDetDVDI Reclosing_Reclaim_and_Inhibit_timers%3DANSI100 00257%3D1%3Den%3DOriginal[1].vsd ANSI10000034 V1 EN-US Figure 55: Simplified logic diagram for DV/DI detection part Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 135: Dead Line Detection

    OptimZsNs ; Optimum of negative and zero sequence (the function that has the highest • magnitude of measured negative and zero sequence current will be activated) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 136 IED. Through OR gate it can be connected to both binary inputs and internal function outputs. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 137 BLKV 60 sec All VP > VsealInPU 5 sec VoltZeroSeq VoltNegSeq AllCurrLow ANSI10000041-1-en.vsd ANSI10000041 V1 EN-US Figure 57: Simplified logic diagram for fuse failure supervision function, Main logic Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 138: Technical Data

    (DT) type. The function trips after a predefined operating time and resets when the fault disappears. 8.2.3 Function block GUID-3F512745-A836-459E-99B6-DC0D0EBFB849 v4 GUID-6F85BD70-4D18-4A00-A410-313233025F3A V2 EN-US Figure 58: Function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 139: Signals

    Trip circuit supervision generates a current of approximately 1.0 mA through the supervised circuit. It must be ensured that this current will not cause a latch up of the controlled object. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 140: Technical Data

    Technical data GUID-3C50487E-47ED-4E5C-AA2E-FA0EB53376BC v1 GUID-CF26761C-55B8-41EF-B140-651F7F116003 v2 Table 85: TCSSCBR Technical data Function Range or value Accuracy Operate time delay (0.020 - 300.000) s ± 0,5% ± 110 ms Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 141: Control

    9.1.2.3 Function block M13469-3 v4 QCBAY LR_OFF PSTO LR_LOC UPD_BLKD LR_REM CMD_BLKD LR_VALID BL_UPD BL_CMD IEC09000080_1_en.vsd IEC09000080 V1 EN-US Figure 60: QCBAY function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 142: Signals

    The signals from the local HMI or from an external local/remote switch are applied via the function blocks LOCREM and LOCREMCTRL to the Bay control (QCBAY) function block. A parameter in Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 143: Function Block

    Table 91: LOCREM Non group settings (basic) Name Values (Range) Unit Step Default Description ControlMode Internal LR-switch Internal LR- Control mode for internal/external LR- External LR- switch switch switch Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 144: Local Remote Control Locremctrl

    INTEGER PSTO input channel 3 PSTO4 INTEGER PSTO input channel 4 PSTO5 INTEGER PSTO input channel 5 PSTO6 INTEGER PSTO input channel 6 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 145: Settings

    The local panel switch is a switch that defines the operator place selection. The switch connected to this function can have three positions remote/local/off. The positions are here defined so that Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 146 The switching of the Local/Remote switch requires at least system operator level. The password will be requested at an attempt to operate if authority levels have been defined in the IED. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 147: Local Remote/Local Remote Control Locrem/Locremctrl

    SLGGIO 9.2.1 Identification SEMOD167845-2 v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Logic rotating switch for function SLGGIO selection and LHMI presentation Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 148: Functionality

    Table 95: SLGGIO Input signals Name Type Default Description BLOCK BOOLEAN Block of function PSTO INTEGER Operator place selection BOOLEAN Binary "UP" command DOWN BOOLEAN Binary "DOWN" command Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 149 Selector switch position 28 BOOLEAN Selector switch position 29 BOOLEAN Selector switch position 30 BOOLEAN Selector switch position 31 BOOLEAN Selector switch position 32 SWPOSN INTEGER Switch position as integer value Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 150: Settings

    The positions and the block names are fully settable by the user. These names will appear in the menu, so the user can see the position names instead of a number. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 151: Selector Mini Switch Vsggio

    BLOCKED BOOLEAN The function is active but the functionality is blocked POSITION INTEGER Position indication, integer POS1 BOOLEAN Position 1 indication, logical signal Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 152: Settings

    Fixed signal function block (FXDSIGN) will allow operation from local HMI. As it can be seen, both indications and commands are done in double-bit representation, where a combination of signals on both inputs/outputs generate the desired result. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 153: Iec 61850 Generic Communication I/O Functions Dpggio

    Figure 65: DPGGIO function block 9.4.4 Signals PID-1881-INPUTSIGNALS v6 Table 102: DPGGIO Input signals Name Type Default Description OPEN BOOLEAN Open indication CLOSE BOOLEAN Close indication VALID BOOLEAN Valid indication Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 154: Settings

    Confirmation (status) of the result of the commands is supposed to be achieved by other means, such as binary inputs and SPGGIO function blocks. The commands can be pulsed or steady. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 155: Function Block

    Operation Disabled/Enabled Enabled Latched1 Pulsed Pulsed Setting for pulsed/latched mode for Latched output 1 tPulse1 0.01 - 6000.00 0.01 0.10 Output1 Pulse Time Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 156: Operation Principle

    SPC8GGIO function block is REMOTE. Automation bits AUTOBITS 9.6.1 Identification GUID-C3BB63F5-F0E7-4B00-AF0F-917ECF87B016 v3 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number AutomationBits, command function AUTOBITS for DNP3 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 157: Functionality

    Figure 67: AUTOBITS function block 9.6.4 Signals GUID-A43D3FA2-4188-4D5E-8413-94DE4FF43BB4 v1 PID-1812-INPUTSIGNALS v5 Table 107: AUTOBITS Input signals Name Type Default Description BLOCK BOOLEAN Block of function PSTO INTEGER Operator place selection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 158 Command out bit 28 CMDBIT29 BOOLEAN Command out bit 29 CMDBIT30 BOOLEAN Command out bit 30 CMDBIT31 BOOLEAN Command out bit 31 CMDBIT32 BOOLEAN Command out bit 32 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 159: Settings

    I103CMD is a command function block in control direction with pre-defined output signals. 9.7.2 Function block GUID-C0680812-C488-4546-AA65-F590955DBF0C v1 I103CMD BLOCK 16-AR 17-DIFF 18-PROT IEC10000282-1-en.vsd IEC10000282 V1 EN-US Figure 68: I103CMD function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 160: Signals

    I103IEDCMD is a command block in control direction with defined IED functions. 9.8.2 Function block GUID-52D27CDA-8805-48FA-99BE-2E05A438B0C7 v1 I103IEDCMD BLOCK 19-LEDRS 23-GRP1 24-GRP2 25-GRP3 26-GRP4 IEC10000283-1-en.vsd IEC10000283 V1 EN-US Figure 69: I103IEDCMD function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 161: Signals

    I103USRCMD is a command block in control direction with user defined output signals. These FunctionType parameter for each block in the private range, and the function blocks include the Information number parameter for each output signal. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 162: Function Block

    0.400 Pulse length InfNo_1 1 - 255 Information number for output 1 (1-255) InfNo_2 1 - 255 Information number for output 2 (1-255) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 163: Function Commands Generic For Iec 60870-5-103 I103Gencmd

    Type Default Description BLOCK BOOLEAN Block of command PID-2662-OUTPUTSIGNALS v4 Table 120: I103GENCMD Output signals Name Type Description CMD_OFF BOOLEAN Command output OFF CMD_ON BOOLEAN Command output ON Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 164: Settings

    PID-2663-INPUTSIGNALS v5 Table 122: I103POSCMD Input signals Name Type Default Description BLOCK BOOLEAN Block of command POSITION INTEGER Position of controllable object SELECT BOOLEAN Select of controllable object Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 165: Settings

    Table 123: I103POSCMD Non group settings (basic) Name Values (Range) Unit Step Default Description FunctionType 1 - 255 Fucntion type (1-255) InfNo 160 - 196 Information number for command output (1-255) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 167: Logic

    Block of function TRINP_3P BOOLEAN Trip all phases SETLKOUT BOOLEAN Input for setting the circuit breaker lockout function RSTLKOUT BOOLEAN Input for resetting the circuit breaker lockout function Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 168: Settings

    IEDs binary outputs, as well as to other functions within the IED requiring this signal. ANSI05000789 V2 EN-US Figure 74: Simplified logic diagram for three pole trip Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 169: Technical Data

    IED. TMAGGIO output signals and the physical outputs allows the user to adapt the signals to the physical tripping outputs according to the specific application needs. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 170: Function Block

    Binary input 9 INPUT10 BOOLEAN Binary input 10 INPUT11 BOOLEAN Binary input 11 INPUT12 BOOLEAN Binary input 12 INPUT13 BOOLEAN Binary input 13 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 171: Settings

    Output pulse time OnDelay 0.000 - 60.000 0.001 0.000 Output on delay time OffDelay 0.000 - 60.000 0.001 0.000 Output off delay time Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 172: Operation Principle

    And for steady operation the of delay will start when all related inputs have reset. Detailed logical diagram is shown in figure Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 173: Configurable Logic Blocks

    OR function block. • INVERTER function blocks that inverts the input signal. • PULSETIMER function block can be used, for example, for pulse extensions or limiting of operation of outputs. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 174: Or Function Block

    One of the outputs is inverted. Function block GUID-7E0C103D-1072-4335-BF3A-CA644C1AF854 v2 INPUT1 INPUT2 NOUT INPUT3 INPUT4 INPUT5 INPUT6 IEC09000288-1-en.vsd IEC09000288 V1 EN-US Figure 77: OR function block Signals PID-1817-INPUTSIGNALS v7 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 175: Inverter Function Block Inverter

    INPUT IEC09000287-1-en.vsd IEC09000287 V1 EN-US Figure 78: INVERTER function block Signals PID-1815-INPUTSIGNALS v7 Table 134: INVERTER Input signals Name Type Default Description INPUT BOOLEAN Input signal PID-1815-OUTPUTSIGNALS v7 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 176: Pulsetimer Function Block

    BOOLEAN Output signal Settings PID-1820-SETTINGS v7 Table 138: PULSETIMER Non group settings (basic) Name Values (Range) Unit Step Default Description 0.000 - 0.001 0.010 Pulse time length 90000.000 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 177: Controllable Gate Function Block Gate

    Operation Disabled/Enabled Enabled 10.3.1.6 Exclusive OR function block XOR Identification GUID-84762172-8050-455D-8E17-D35A43430DF0 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Exclusive OR function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 178: Loop Delay Function Block Loopdelay

    The Logic loop delay function block (LOOPDELAY) function is used to delay the output signal one execution cycle. Function block GUID-EE44CFDF-C8F7-4870-BD1C-98D9CD91FD97 v3 LOOPDELAY INPUT IEC09000296-1-en.vsd IEC09000296 V1 EN-US Figure 82: LOOPDELAY function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 179: Timer Function Block Timerset

    The function block TIMERSET has pick-up and drop-out delayed outputs related to the input t ). signal. The timer has a settable time delay ( Input tdelay tdelay en08000289-2-en.vsd IEC08000289 V1 EN-US Figure 83: TIMERSET Status diagram Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 180: And Function Block

    The output OUT has a default value 0 initially, which suppresses one cycle pulse if the function has been put in the wrong execution order. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 181: Set-Reset Memory Function Block Srmemory

    The memory setting controls if the flip-flop after a power interruption will return the state it had before or if it will be reset. For a Set-Reset flip-flop, SET input has higher priority over RESET input. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 182: Reset-Set With Memory Function Block Rsmemory

    10.3.1.11 Reset-set with memory function block RSMEMORY Identification GUID-778F02C0-F3F5-492C-9D72-1E499E01F838 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Reset-set with memory function RSMEMORY block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 183 Inverted output signal Settings PID-1187-SETTINGS v7 Table 158: RSMEMORY Group settings (basic) Name Values (Range) Unit Step Default Description Memory Disabled Enabled Operating mode of the memory function Enabled Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 184: Technical Data

    The Fixed signals function (FXDSIGN) generates a number of pre-set (fixed) signals that can be used in the configuration of an IED, either for forcing the unused inputs in other function blocks to a certain level/value, or for creating certain logic. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 185: Function Block

    INTONE is an integer number, fixed to integer value 1 • INTALONE is an integer value FFFF (hex) • REALZERO is a floating point real number, fixed to 0.0 value Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 186: Boolean 16 To Integer Conversion B16I

    Table 161: B16I Input signals Name Type Default Description BLOCK BOOLEAN Block of function BOOLEAN Input 1 BOOLEAN Input 2 BOOLEAN Input 3 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 187: Settings

    Boolean 1, it corresponds to that integer 65535 is available on the output OUT. The B16I function is designed for receiving up to 16 booleans input locally. If the BLOCK input is activated, it will freeze the output at the last value. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 188: Boolean 16 To Integer Conversion With Logic Node Representation B16Ifcvi

    Functionality SEMOD175781-4 v4 Boolean 16 to integer conversion with logic node representation function (B16IFCVI) is used to transform a set of 16 binary (logical) signals into an integer. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 189: Function Block

    IN10 BOOLEAN Input 10 IN11 BOOLEAN Input 11 IN12 BOOLEAN Input 12 IN13 BOOLEAN Input 13 IN14 BOOLEAN Input 14 IN15 BOOLEAN Input 15 IN16 BOOLEAN Input 16 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 190: Settings

    Input 2 BOOLEAN Input 3 BOOLEAN Input 4 BOOLEAN Input 5 BOOLEAN Input 6 BOOLEAN Input 7 BOOLEAN Input 8 BOOLEAN Input 9 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 191: Integer To Boolean 16 Conversion Ib16A

    SEMOD158389-4 v4 IB16A BLOCK OUT1 OUT2 OUT3 OUT4 OUT5 OUT6 OUT7 OUT8 OUT9 OUT10 OUT11 OUT12 OUT13 OUT14 OUT15 OUT16 IEC09000036-1-en.vsd IEC09000036 V1 EN-US Figure 91: IB16A function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 192: Signals

    OUTx represents a value when activated. The value of each of the OUTx is in accordance with the table IB16A_1. When not activated the OUTx has the value 0. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 193 The sum of the numbers in column “Value when activated” when all OUTx (where x = 1 to 16) are active that is=1; is 65535. 65535 is the highest integer that can be converted by the IB16A function block. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 194: Integer To Boolean 16 Conversion With Logic Node Representation Ib16Fcvb

    Figure 92: IB16FCVB function block 10.8.4 Signals PID-1980-INPUTSIGNALS v6 Table 169: IB16FCVB Input signals Name Type Default Description BLOCK BOOLEAN Block of function PSTO INTEGER Operator place selection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 195: Settings

    IB16FCVB function block to a combination of activated outputs OUTx where 1≤x≤16. The values represented by the different OUTx are according to Table 171. When an OUTx is not activated, its value is 0. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 196 IB16FCVB can only be written to the block while the PSTO is in position “Remote”. If PSTO is in position ”Off” or ”Local”, then no changes are applied to the outputs. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 197: Monitoring

    Block of function BOOLEAN Input status 11.1.5 Settings PID-1822-SETTINGS v3 The function does not have any parameters available in Local HMI or Protection and Control IED Manager (PCM600). Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 198: Operation Principle

    GUID-EEB6E300-E0AA-4603-A929-5ACC930599C8 v1 SP16GGIO BLOCK ^IN1 ^IN2 ^IN3 ^IN4 ^IN5 ^IN6 ^IN7 ^IN8 ^IN9 ^IN10 ^IN11 ^IN12 ^IN13 ^IN14 ^IN15 ^IN16 IEC09000238_en_1.vsd IEC09000238 V1 EN-US Figure 94: SP16GGIO function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 199: Signals

    GROUP Output 2 status SIGNAL OUT3 GROUP Output 3 status SIGNAL OUT4 GROUP Output 4 status SIGNAL OUT5 GROUP Output 5 status SIGNAL Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 200: Operation Principle

    IEC 61850 generic communication I/O functions MVGGIO 11.3.1 Identification GUID-01F6727C-37E5-4C0F-B8C1-7CF25FD4BB09 v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number IEC61850 generic communication MVGGIO I/O functions Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 201: Functionality

    Zero point clamping in 0.001% of range MV hhLim -5000.00 - xBase 0.01 900.00 High High limit multiplied with the base 5000.00 prefix (multiplication factor) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 202: Monitored Data

    (CTs and VTs). During normal service by periodic comparison of the measured value from the IED with other independent meters the proper operation of the IED analog measurement Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 203 V: sequence voltages (positive, zero and negative sequence, magnitude and angle). The CVMMXN function calculates three-phase power quantities by using fundamental frequency phasors (DFT values) of the measured current respectively voltage signals. The measured power Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 204: Measurements Cvmmxn

    PID-1128-INPUTSIGNALS v6 Table 179: CVMMXN Input signals Name Type Default Description GROUP Three phase group signal for current inputs SIGNAL GROUP Three phase group signal for voltage inputs SIGNAL Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 205: Settings

    0.000 - 6.000 0.001 1.000 Magnitude factor to scale power calculations PowAngComp -180.0 - 180.0 Angle compensation for phase shift between measured I & V Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 206 Dead band Int deadband FrMin 0.000 - 100.000 0.001 0.000 Minimum value FrMax 0.000 - 100.000 0.001 70.000 Maximum value FrRepTyp Cyclic Cyclic Reporting type Dead band Int deadband Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 207 VLowLim 0.0 - 200.0 80.0 Low limit in % of UBase VLowLowLim 0.0 - 200.0 60.0 Low Low limit in % of UBase Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 208 IAngComp30 -10.000 - 10.000 0.001 0.000 Angle calibration for current at 30% of In IAngComp100 -10.000 - 10.000 0.001 0.000 Angle calibration for current at 100% of In Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 209: Monitored Data

    The available function blocks of an IED are depending on the actual hardware (TRM) and the logic configuration made in PCM600. CMMXU I3P* IA_RANGE IA_ANGL IB_RANGE IB_ANGL IC_RANGE IC_ANGL ANSI08000225-1-en.vsd ANSI08000225 V1 EN-US Figure 96: CMMXU function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 210: Signals

    ILRepTyp Cyclic Dead band Reporting type Dead band Int deadband ILAngDbRepInt 1 - 300 Type Cycl: Report interval (s), Db: In % of range, Int Db: In %s Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 211: Monitored Data

    11.4.4 Phase-phase voltage measurement VMMXU 11.4.4.1 Identification GUID-726E0058-033D-4E90-870A-A870ADAD33B0 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Phase-phase voltage measurement VMMXU SYMBOL-UU V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 212: Function Block

    VAB Angle V_BC REAL V_BC Amplitude VBC_RANG INTEGER VBC Magnitude range VBC_ANGL REAL VBC Angle V_CA REAL V_CA Amplitude VCA_RANG INTEGER VCA Amplitude range VCA_ANGL REAL VCA Angle Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 213: Settings

    Values (Range) Unit Description V_AB REAL V_AB Amplitude VAB_ANGL REAL VAB Angle V_BC REAL V_BC Amplitude VBC_ANGL REAL VBC Angle V_CA REAL V_CA Amplitude VCA_ANGL REAL VCA Angle Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 214: Current Sequence Component Measurement Cmsqi

    REAL 3I0 Amplitude 3I0RANG INTEGER 3I0 Magnitude range 3I0ANGL REAL 3I0 Angle REAL I1 Amplitude I1RANG INTEGER I1Amplitude range I1ANGL REAL I1 Angle Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 215: Settings

    Hysteresis value in % of range and is common for all limits I2AngDbRepInt 1 - 300 Type Cycl: Report interval (s), Db: In % of range, Int Db: In %s Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 216: Monitored Data

    Voltage sequence measurement VMSQI 11.4.6.1 Identification GUID-861F85E4-ED53-4DC3-8BD4-2783FB6B89AD v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Voltage sequence measurement VMSQI U1, U2, U0 SYMBOL-TT V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 217: Function Block

    3V0ANGL REAL 3U0 Angle REAL U1 Amplitude V1RANG INTEGER V1 Magnitude range V1ANGL REAL U1 Angle REAL U2 Amplitude V2RANG INTEGER V2 Magnitude range V2ANGL REAL U2 Angle Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 218: Settings

    High limit (physical value) 3V0LowLim 0 - 2000000 213000 Low limit (physical value) 3V0LowLowLim 0 - 2000000 198000 Low Low limit (physical value) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 219: Monitored Data

    SYMBOL-UU V1 EN-US 11.4.7.2 Function block GUID-440B43E6-39FF-43A9-8E11-B45ACBCAC5CF v2 The available function blocks of an IED are depending on the actual hardware (TRM) and the logic configuration made in PCM600. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 220: Signals

    1 - 300 Type Cycl: Report interval (s), Db: In % of range, Int Db: In %s VMax 0 - 2000000 106000 Maximum value Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 221: Monitored Data

    The number of processed alternate measuring quantities depends on the type of IED and built-in options. The information on measured quantities is available for the user at different locations: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 222 Low limit and 4: below Low-low limit). The output may be connected to a measurement expander block (XP (RANGE_XP)) to get measurement supervision as binary signals. The logical value of the functional output signals changes according to figure 101. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 223 The picture is simplified: the process is not continuous but the values are evaluated with a time interval of one execution cycle from each other. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 224 The integral dead-band supervision is particularly suitable for monitoring signals with small variations that can last for relatively long periods. Even if integral dead-band reporting is selected, there will be a 30 s "back-ground" cyclic reporting as well. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 225: Measurements Cvmmxn

    = × × three phase power shall be PosSeq PosSeq PosSeq measured (Equation 28) EQUATION1565 V1 EN-US PosSeq (Equation 29) EQUATION1566 V1 EN-US Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 226 Once the complex apparent power is calculated then the P, Q, S, & PF are calculated in accordance with the following formulas: Re( ) (Equation 42) EQUATION1403 V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 227 This is achieved by magnitude and angle compensation at 5, 30 and 100% of rated current and voltage. The compensation below 5% and above 100% is constant and linear in between, see example in figure 105. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 228 Calculated is settable parameter by the end user which influence the filter properties Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 229 Practically, it means that active and reactive power will have positive values when they flow from the busbar towards the protected object and they will have negative values when they flow from the protected object towards the busbar. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 230: Phase Current Measurement Cmmxu

    Each magnitude output has a corresponding supervision level output (X_RANGE). The output signal is an integer in the interval 0-4, see section "Measurement supervision". Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 231: Technical Data

    Function block M13412-3 v4 CNTGGIO BLOCK VALUE1 COUNTER1 VALUE2 COUNTER2 VALUE3 COUNTER3 VALUE4 COUNTER4 VALUE5 COUNTER5 VALUE6 COUNTER6 RESET IEC09000090_1_en.vsd IEC09000090 V1 EN-US Figure 107: CNTGGIO function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 232: Signals

    Type Values (Range) Unit Description VALUE1 INTEGER Output of counter 1 VALUE2 INTEGER Output of counter 2 VALUE3 INTEGER Output of counter 3 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 233: Operation Principle

    HMI graphical display. 11.5.8 Technical data M13416-1 v4 Table 214: CNTGGIO technical data Function Range or value Accuracy Counter value 0-10000 Max. count up speed 10 pulses/s Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 234: Disturbance Report

    11.6.2 Disturbance report DRPRDRE GUID-D24C5F43-6EC0-4B12-BB57-6C7B2C7B84B8 v2 11.6.2.1 Identification M16055-1 v4 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Disturbance report DRPRDRE Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 235: Function Block

    MaxNoStoreRec 10 - 100 Maximum number of stored disturbances ZeroAngleRef 1 - 30 Trip value recorder, phasor reference channel OpModeTest Disabled Disabled Operation mode during test mode Enabled Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 236: Monitored Data

    Under level trig for analog channel 10 activated OvTrigStatCh10 BOOLEAN Over level trig for analog channel 10 activated UnTrigStatCh11 BOOLEAN Under level trig for analog channel 11 activated Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 237 Under level trig for analog channel 22 activated OvTrigStatCh22 BOOLEAN Over level trig for analog channel 22 activated UnTrigStatCh23 BOOLEAN Under level trig for analog channel 23 activated Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 238 Under level trig for analog channel 34 activated OvTrigStatCh34 BOOLEAN Over level trig for analog channel 34 activated UnTrigStatCh35 BOOLEAN Under level trig for analog channel 35 activated Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 239: Measured Values

    11.6.3.1 Identification GUID-99A9E7DA-0CE9-40A2-9B07-A3D613C0957D v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Analog input signals A1RADR Analog input signals A2RADR Analog input signals A3RADR Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 240: Function Block

    Group signal for input 7 SIGNAL GRPINPUT8 GROUP Group signal for input 8 SIGNAL GRPINPUT9 GROUP Group signal for input 9 SIGNAL GRPINPUT10 GROUP Group signal for input 10 SIGNAL Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 241: Settings

    (IEC-60870-5-103) InfNo4 0 - 255 Information number for analog channel 4 (IEC-60870-5-103) FunType5 0 - 255 Function type for analog channel 5 (IEC-60870-5-103) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 242 0.0 - 999999.9 Nominal value for analog channel 3 UnderTrigOp03 Disabled Disabled Use under level trigger for analog channel Enabled 3 (on) or not (off) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 243 Use under level trigger for analog channel Enabled 8 (on) or not (off) UnderTrigLe08 0 - 200 Under trigger level for analog channel 8 in % of signal Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 244: Analog Input Signals A4Radr

    11.6.4.2 Function block GUID-A65D9F65-E013-4E56-B208-73A168634147 v2 A4RADR ^INPUT31 ^INPUT32 ^INPUT33 ^INPUT34 ^INPUT35 ^INPUT36 ^INPUT37 ^INPUT38 ^INPUT39 ^INPUT40 IEC09000350-1-en.vsd IEC09000350 V1 EN-US Figure 110: A4RADR function block, derived analog inputs Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 245: Signals

    Disabled Disabled Operation On/off Enabled Operation38 Disabled Disabled Operation On/off Enabled Operation39 Disabled Disabled Operation On/off Enabled Operation40 Disabled Disabled Operation On/off Enabled Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 246 Information number for analog channel 39 (IEC-60870-5-103) FunType40 0 - 255 Function type for analog channel 40 (IEC-60870-5-103) InfNo40 0 - 255 Information number for analog channel40 (IEC-60870-5-103) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 247 0 - 5000 Over trigger level for analog channel 35 in % of signal NomValue36 0.0 - 999999.9 Nominal value for analog channel 36 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 248 Use over level trigger for analog channel Enabled 40 (on) or not (off) OverTrigLe40 0 - 5000 Over trigger level for analog channel 40 in % of signal Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 249: Binary Input Signals Bxrbdr

    B1RBDR, INPUT1 - INPUT16 • B2RBDR, INPUT17 - INPUT32 • B3RBDR, INPUT33 - INPUT48 • B4RBDR, INPUT49 - INPUT64 • B5RBDR, INPUT65 - INPUT80 • B6RBDR, INPUT81 - INPUT96 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 250: Settings

    Disabled Disabled Set LED on HMI for binary channel 1 Start Trip Pick up and trip TrigDR02 Disabled Disabled Trigger operation On/Off Enabled Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 251 Disabled Disabled Trigger operation On/Off Enabled SetLED10 Disabled Disabled Set LED on HMI for binary channel 10 Start Trip Pick up and trip Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 252 0 - 255 Information number for binary channel 3 (IEC -60870-5-103) FunType4 0 - 255 Function type for binary channel 4 (IEC -60870-5-103) Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 253 Information number for binary channel 15 (IEC -60870-5-103) FunType16 0 - 255 Function type for binary channel 16 (IEC -60870-5-103) InfNo16 0 - 255 Information number for binary channel 16 (IEC -60870-5-103) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 254 Show TrigLevel12 Trig on 0 Trig on 1 Trigger on positive (1) or negative (0) slope Trig on 1 for binary input 12 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 255: Operation Principle

    Sequential of events , Event recorder and Indications uses information from the binary input function blocks (BxRBDR). Trip value recorder uses analog information from the analog input function blocks (AxRADR). Disturbance recorder DRPRDRE acquires information from both AxRADR and BxRBDR. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 256 Long recording time will reduce the number of recordings to less than 100. The IED flash disk should NOT be used to store any user files. This might cause disturbance recordings to be deleted due to lack of disk space. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 257: Disturbance Information

    The total recording time, tRecording, of a recorded disturbance is: PreFaultrecT + tFault + PostFaultrecT or PreFaultrecT + TimeLimit , depending on tRecording = which criterion stops the current disturbance recording Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 258: Analog Signals

    (SMAI) and summation block (3PHSUM). The last 10 channels may be connected to internally calculated analog signals available as function block output signals (phase differential currents, bias currents and so on). Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 259 Operation = Enabled , waveform (samples) will also be recorded and reported in graph. The analog signals are presented only in the disturbance recording, but they affect the entire disturbance report when being used as triggers. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 260: Binary Signals

    If the average value is below the set threshold level for an undervoltage or undercurrent trigger, this trigger is indicated with a less than (<) sign with its name. The procedure is separately performed for each channel. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 261: Post Retrigger

    Maximum number of events in the Event recording per recording Maximum number of events in the Sequence of events 1000, first in - first out Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 262: Indications

    The LED indications display this information: Green LED: Steady light In Service Flashing light Internal fail Dark No power supply Yellow LED: SetLEDn setting in Disturbance report function. Function controlled by Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 263: Functionality

    Each recording can contain up to 150 time-tagged events. The event recorder information is available for the disturbances locally in the IED. The event recording information is an integrated part of the disturbance record (Comtrade file). Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 264: Signals

    Table 230: DRPRDRE technical data Function Value Buffer capacity Maximum number of events in disturbance report Maximum number of disturbance reports Resolution 1 ms Accuracy Depending on time synchronizing Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 265: Functionality

    IP11531-1 v1 M12700-1 v4 Table 231: DRPRDRE technical data Function Value Buffer capacity Maximum number of events in the list 1000 Resolution 1 ms Accuracy Depending on time synchronizing Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 266: Functionality

    The name of the analog input signal that appears in the Trip value recorder function is the user- defined name assigned when the IED is configured. The same name is used in the Disturbance recorder function . Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 267: Functionality

    The Disturbance recorder has no function block of it’s own. 11.11.3 Signals M12649-12 v4 See Disturbance report for input and output signals. 11.11.4 Settings M12648-9 v5 See Disturbance report for settings. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 268 The recording files comply with the Comtrade standard IEC 60255-24 and are divided into three files; a header file (HDR), a configuration file (CFG) and a data file (DAT). Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 269 Maximum total recording time (3.4 s recording time and maximum 340 seconds (100 recordings) at 50 Hz number of channels, typical value) 280 seconds (80 recordings) at 60 Hz Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 270 IEC09000215 V1 EN-US Figure 115: MVEXP function block 11.12.4 Signals GUID-8AFC0AEF-A8D9-4F31-873C-51FF237D540C v1 PID-1824-INPUTSIGNALS v9 Table 234: MVEXP Input signals Name Type Default Description RANGE INTEGER Measured value range Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 271 High 11.13 Station battery supervision SPVNZBAT 11.13.1 Identification GUID-2CE1CBF4-527A-4B42-B486-BA40FB3E2926 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Station battery supervision function SPVNZBAT U<> Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 272: Functionality

    Alarm when voltage has exceeded high limit for a set time PU_VLOW BOOLEAN Pick up signal when battery voltage drops below lower limit PU_VHI BOOLEAN Pick up signal when battery voltage exceeds upper limit Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 273: Settings

    The operation of the station battery supervision function can be described by using a module diagram. All the modules in the diagram are explained in the next sections. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 274: Technical Data

    Upper limit for the battery terminal (60-140) % of Vbat ± 1.0% of set battery voltage voltage Reset ratio, upper limit >95 % Timers (0.000-60.000) s ± 0.5% ± 110 ms Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 275: Insulation Gas Monitoring Function Ssimg (63)

    Pressure input from CB TEMP REAL Temperature of the insulation medium from CB PRES_ALM BOOLEAN Pressure alarm signal PRES_LO BOOLEAN Pressure lockout signal Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 276: Settings

    Two binary output signals are used from the circuit breaker to initiate alarm signals, pressure below alarm level and pressure below lockout level. If the input signal PRES_ALM is high, Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 277: Technical Data

    Binary information based on the oil level in the circuit breaker is used as input signals to the function. In addition, the function generates alarms based on received information. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 278: Function Block

    Level below alarm level LVL_LO BOOLEAN Level below lockout level TEMP REAL Temperature of the insulation medium TEMP_ALM BOOLEAN Temperature above alarm level TEMP_LO BOOLEAN Temperature above lockout level Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 279: Settings

    LVL_LO, level below lockout level alarm will be obtained. The input signal BLK_ALM is used to block the two alarms and the input signal BLOCK to block both alarms and the function. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 280: Technical Data

    2 t values. Alarms are generated when the calculated values exceed the threshold settings. The function contains a blocking functionality. It is possible to block the function outputs, if desired. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 281: Function Block

    CB close travel time exceeded set value SPRCHRAL BOOLEAN Spring charging time has crossed the set value OPRALM BOOLEAN Number of CB operations exceeds alarm limit Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 282: Settings

    Alarm level setting for close travel time OpenTimeCorr 0 - 100 Correction factor for open travel time CloseTimeCorr 0 - 100 Correction factor for CB close travel time Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 283: Monitored Data

    The functions can be enabled and disabled with the corresponding parameter values are Enable and Disable. The operation counters are cleared when Operation is set to Disabled . Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 284: Circuit Breaker Status

    The operation of the breaker status monitoring can be described by using a module diagram. All the modules in the diagram are explained in the next sections. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 285: Circuit Breaker Operation Monitoring

    POSOPEN and POSCLOSE auxiliary contacts. The inactive days NOOPRDAY is available through the Monitored data view. It is also possible to set the initial inactive days by using the InactDayInit parameter. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 286: Breaker Contact Travel Time

    Therefore, in order to incorporate the time t , a correction factor needs to be added with 10 to get the actual opening Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 287: Operation Counter

    OpNumLO setting, the OPRLOALM output is activated. exceeds the limit value set with the The binary outputs OPRLOALM and OPRALM are deactivated when the BLOCK input is activated. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 288: Accumulation Of I Y T

    LHMI or through tools via communications. The values can be reset by setting the Clear accum. breaking curr setting to true in the clear menu from LHMI. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 289: Remaining Life Of The Circuit Breaker

    CBLIFE_A (_B, _C). The values can be cleared by setting the parameter CB wear values in the clear menu from LHMI. CB wear values also resets the operation counter. Clearing Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 290: Circuit Breaker Spring Charged Indication

    The gas pressure supervision subfunction monitors the gas pressure inside the arc chamber. The operation of the subfunction can be described by using a module diagram. All the modules in the diagram are explained in the next sections. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 291: Technical Data

    ± 0.5% ± 25 ms 11.17 Measurands for IEC 60870-5-103 I103MEAS 11.17.1 Functionality GUID-557FB587-9127-4D99-B2C6-16445E06F220 v1 103MEAS is a function block that reports all valid measuring types depending on connected signals. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 292: Function Block

    MMXU function, to outputs on the fixed signal function block. 11.17.2 Function block GUID-EC5F1C83-0F47-4548-86E3-FFE056571241 v1 I103MEAS BLOCK V_AB ANSI10000287-1-en.vsd ANSI10000287 V1 EN-US Figure 132: I103MEAS function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 293: Signals

    0.00 - 2000.00 0.05 1200.00 Maximum value for active power MaxQ 0.00 - 2000.00 0.05 1200.00 Maximum value for reactive power MaxF 50.0 - 60.0 10.0 50.0 Maximum system frequency Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 294: Measurands User Defined Signals For Iec 60870-5-103 I103Measusr

    Service value for measurement on input 6 INPUT7 REAL Service value for measurement on input 7 INPUT8 REAL Service value for measurement on input 8 INPUT9 REAL Service value for measurement on input 9 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 295: Settings

    This block includes the defined for each output signal. 11.19.2 Function block GUID-FAC5A3DF-73CB-4A39-A213-5C21ACA05756 v1 I103AR BLOCK 16_ARACT 128_CBON 130_UNSU IEC10000289-1-en.vsd IEC10000289 V1 EN-US Figure 134: I103AR function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 296: Signals

    Table 262: I103EF Input signals Name Type Default Description BLOCK BOOLEAN Block of status reporting 51_EFFW BOOLEAN Information number 51, ground-fault forward 52_EFREV BOOLEAN Information number 52, ground-fault reverse Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 297: Settings

    76_TRANS 77_RECEV 78_ZONE1 79_ZONE2 80_ZONE3 81_ZONE4 82_ZONE5 84_STGEN 85_BFP 86_MTR_A 87_MTR_B 88_MTR_C 89_MTRN 90_IOC 91_IOC 92_IEF 93_IEF ARINPROG FLTLOC ANSI10000291-1-en.vsd ANSI10000291 V1 EN-US Figure 136: I103FLTPROT function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 298: Signals

    Information number 92, ground-fault trip, stage low 93_IEF BOOLEAN Information number 93, ground-fault trip, stage high ARINPROG BOOLEAN Autorecloser in progress (SMBRREC- INPROGR) FLTLOC BOOLEAN Faultlocator faultlocation valid (LMBRFLO-CALCMADE) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 299: Settings

    Information number 24, setting group 2 is active 25_GRP3 BOOLEAN Information number 25, setting group 3 is active 26_GRP4 BOOLEAN Information number 26, setting group 4 is active Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 300: Settings

    Information number 37, I high-high back-up protection 38_VTFF BOOLEAN Information number 38, fuse failure VT 46_GRWA BOOLEAN Information number 46, group warning 47_GRAL BOOLEAN Information number 47, group alarm Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 301: Settings

    Figure 139: IEC 60870-5-103I103USRDEF:1 11.24.2 Function block GUID-B8312E77-514D-4117-BB31-B9907755580C v1 I103USRDEF BLOCK ^INPUT1 ^INPUT2 ^INPUT3 ^INPUT4 ^INPUT5 ^INPUT6 ^INPUT7 ^INPUT8 IEC10000294-1-en.vsd IEC10000294 V1 EN-US Figure 140: I103USRDEF function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 302: Signals

    Information number for binary input 6 (1-255) InfNo_7 1 - 255 Information number for binary input 7 (1-255) InfNo_8 1 - 255 Information number for binary input 8 (1-255) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 303: Metering

    Description BLOCK BOOLEAN Block of function READ_VAL BOOLEAN Initiates an additional pulse counter reading BI_PULSE BOOLEAN Connect binary input channel for metering RS_CNT BOOLEAN Resets pulse counter value Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 304: Settings

    PID-1821-MONITOREDDATA v11 Table 275: PCGGIO Monitored data Name Type Values (Range) Unit Description CNT_VAL INTEGER Actual pulse counter value SCAL_VAL REAL Scaled value with time and status information Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 305: Operation Principle

    The BLOCKED signal is a steady signal and is set when the counter is blocked. There are two reasons why the counter is blocked: • The BLOCK input is set, or • The binary input module, where the counter input is situated, is inoperative. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 306: Technical Data

    Active as well as reactive values are calculated in import and export direction. Values can be read or generated as pulses. Maximum demand power values are also calculated by the function. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 307: Function Block

    Alarm for reactive reverse energy exceed limit in set interval EAFACC REAL Accumulated forward active energy value EARACC REAL Accumulated reverse active energy value Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 308: Settings

    Disabled Enabled Enable of zero point clamping detection Enabled function LevZeroClampP 0.001 - 10000.000 0.001 10.000 Zero point clamping level at active Power Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 309: Monitored Data

    MAXPAFD, MAXPARD, MAXPRFD, MAXPRRD for the active and reactive power forward and reverse direction until reset with input signal RSTDMD or from the local HMI reset menu. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 310: Technical Data

    Technical data SEMOD153707-2 v4 Table 282: ETPMMTR technical data Function Range or value Accuracy Energy metering MWh Export/Import, MVArh Input from MMXU. No extra error at steady Export/Import load Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 311: Station Communication

    All communication connectors, except for the front port connector, are placed on integrated communication modules. The IED is connected to Ethernet-based communication systems via the fibre-optic multimode LC connector (100BASE-FX). Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 312: Settings

    Horizontal communication via GOOSE for interlocking 13.3.1 Identification GUID-88FF25EF-7B29-4DF1-A832-8AB41474B69C v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Horizontal communication via GOOSEINTLKR GOOSE for interlocking Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 313: Function Block

    IEC09000099_1_en.vsd IEC09000099 V1 EN-US Figure 144: GOOSEINTLKRCV function block 13.3.3 Signals PID-1437-INPUTSIGNALS v7 Table 286: GOOSEINTLKRCV Input signals Name Type Default Description BLOCK BOOLEAN Block of output signals Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 314 Apparatus 11 position is closed APP11VAL BOOLEAN Apparatus 11 position is valid APP12_OP BOOLEAN Apparatus 12 position is open APP12_CL BOOLEAN Apparatus 12 position is closed Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 315: Settings

    Operation Disabled/Enabled Enabled 13.4 Goose binary receive GOOSEBINRCV 13.4.1 Identification GUID-54434BF4-C8DC-4F7B-99B5-519EB15F2A47 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Goose binary receive GOOSEBINRCV Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 316: Function Block

    Binary output 2 OUT2VAL BOOLEAN Valid data on binary output 2 OUT3 BOOLEAN Binary output 3 OUT3VAL BOOLEAN Valid data on binary output 3 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 317: Settings

    Valid data on binary output 16 13.4.4 Settings PID-1436-SETTINGS v7 Table 291: GOOSEBINRCV Non group settings (basic) Name Values (Range) Unit Step Default Description Operation Disabled Disabled Operation Disabled/Enabled Enabled Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 318: Goose Function Block To Receive A Double Point Value Goosedprcv

    Name Type Description DPOUT INTEGER Double point output DATAVALID BOOLEAN Data valid for double point output COMMVALID BOOLEAN Communication valid for double point output TEST BOOLEAN Test output Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 319: Settings

    GOOSE function block to receive an GOOSEINTRCV integer value 13.6.2 Functionality GUID-27B1ED7A-C8E8-499E-89C1-C656FB0337F8 v1 GOOSEINTRCV is used to receive an integer value from the sender using IEC61850 protocol over GOOSE. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 320: Function Block

    The TEST output will go HIGH if the sending IED is in test mode. The input of this GOOSE block must be crossed in the SMT to receive the integer values. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 321: Goose Function Block To Receive A Measurand Value Goosemvrcv

    TEST IEC10000251-1-en.vsd IEC10000251 V1 EN-US Figure 148: GOOSEMVRCV function block 13.7.4 Signals PID-2530-INPUTSIGNALS v6 Table 298: GOOSEMVRCV Input signals Name Type Default Description BLOCK BOOLEAN Block of function Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 322: Settings

    GOOSE function block to receive a single point value GOOSESPRCV 13.8.1 Identification GUID-F2B30A70-842E-435E-8FAB-B1E58B9C0164 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number GOOSE function block to receive a GOOSESPRCV single point value Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 323: Functionality

    The DATAVALID output will be HIGH if the incoming message is with valid data. The COMMVALID output will become LOW when the sending IED is under total failure condition and the GOOSE transmission from the sending IED does not happen. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 324: Iec 60870-5-103 Communication Protocol

    RevPolarity Disabled Enabled Invert polarity Enabled CycMeasRepTime 1.0 - 1800.0 Cyclic reporting time of measurments MasterTimeDomain Master time domain Local Local with DST Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 325 Step Default Description TimeSyncMode IEDTime IEDTime Time synchronization mode LinMastTime IEDTimeSkew EvalTimeAccuracy Evaluate time accuracy for invalid time 10ms 20ms 40ms EventRepMode SeqOfEvent SeqOfEvent Event reporting mode HiPriSpont Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 327: Basic Ied Functions

    1 DebounceTime1 0.000 - 0.100 0.001 0.005 Debounce time for input 1 OscillationCount1 0 - 255 Oscillation count for input 1 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 328 0.000 - 0.100 0.001 0.005 Debounce time for input 9 OscillationCount9 0 - 255 Oscillation count for input 9 OscillationTime9 0.000 - 600.000 0.001 0.000 Oscillation time for input 9 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 329: Self Supervision With Internal Event List

    Real time clock error DISABLE BOOLEAN Application Disable 14.2.2.4 Settings PID-1308-SETTINGS v3 The function does not have any settings available in Local HMI or Protection and Control IED Manager (PCM600). Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 330: Internal Event List Selfsupevlst

    (INTERNAL FAIL) located on the power supply module. This output relay is activated (no fault) and deactivated (fault) by the Internal Fail signal, see Figure 151. Also the software watchdog timeout and the undervoltage detection of the PSM will deactivate the relay. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 331 Supply fault ReBoot I/O INTERNAL FAIL Fault Internal Fail (CPU) I/O nodes = BIO xxxx = Inverted signal IEC09000390-1-en.vsd IEC09000390 V1 EN-US Figure 151: Hardware self-supervision, potential-free contact Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 332: Internal Signals

    SELFSUPEVLST function provides several status signals, that tells about the condition of the IED. As they provide information about the internal status of the IED, they are also called internal signals. The internal signals can be divided into two groups. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 333 IEC 61850 Error, DNP3 Error Real Time Clock Error This signal will be active if there is a hardware error with the real time clock. Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 334: Run-Time Model

    Figure 153. Adx_Low Controller Adx_High en05000296-2-en.vsd IEC05000296 V2 EN-US Figure 153: Simplified drawing of A/D converter for the IED. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 335: Technical Data

    Micro SCADA OPC server should not be used as a time synchronization source. 14.3.2 Time synchronization TIMESYNCHGEN 14.3.2.1 Identification GUID-68BC32C7-88FB-4101-A245-A9DCCB6E70EF v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Time synchronization TIMESYNCHGE Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 336: Settings

    Time system, summer time begin DSTBEGIN 14.3.4.1 Identification GUID-78DA3FFB-315B-4B4A-9C75-E20D03C6AFFE v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Time system, summer time begins DSTBEGIN Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 337: Settings

    Time system, summer time ends DSTEND 14.3.5.1 Identification GUID-755A8B4F-6452-44F6-9544-DC25C5650B01 v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Time system, summer time ends DSTEND Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 338: Settings

    TIMEZONE 14.3.6.2 Settings PID-1843-SETTINGS v7 Table 316: TIMEZONE Non group settings (basic) Name Values (Range) Unit Step Default Description NoHalfHourUTC -24 - 24 Number of half-hours from UTC Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 339: Time Synchronization Via Irig-B

    Protection Commu Events and control Disabled - nication functions SNTP Time- IRIG-B regulator SW- time IEC60870-5-103 ANSI09000210-1-en.vsd ANSI09000210 V1 EN-US Figure 154: Design of time system (clock synchronization) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 340: Real-Time Clock (Rtc) Operation

    If the synchronization message, which is similar to the other messages, from its origin has an offset compared to the internal time in the IED, the message is used directly for Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 341: Synchronization Alternatives

    The “B” in IRIG-B states that 100 bits per second are transmitted, and the message is sent every second. After IRIG-B there numbers stating if and how the signal is modulated and the information transmitted. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 342: Technical Data

    Creating and switching between fine-tuned setting sets, either from the local HMI or configurable binary inputs, results in a highly adaptable IED that can cope with a variety of system scenarios. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 343: Setting Group Handling Setgrps

    Parameter setting groups ACTVGRP 14.4.3.2 Function block GUID-FDEE7E61-236D-4E2E-A182-7CCD3D8EFEC6 v2 ACTVGRP ACTGRP1 GRP1 ACTGRP2 GRP2 ACTGRP3 GRP3 ACTGRP4 GRP4 GRP_CHGD ANSI09000064-1-en.vsd ANSI09000064 V1 EN-US Figure 156: ACTVGRP function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 344: Signals

    This means that if for example both group four and group two are set to activate, group two will be the one activated. Every time the active group is changed, the output signal GRP_CHGD is sending a pulse. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 345: Test Mode Functionality Testmode

    All testing will be done with actually set and configured values within the IED. No settings will be changed, thus mistakes are avoided. Forcing of binary output signals is only possible when the IED is in test mode. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 346: Function Block

    14.5.6 Operation principle IP12116-1 v3 M12015-4 v7 Put the IED into test mode to test functions in the IED. Set the IED in test mode by Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 347: Change Lock Function Chnglck

    SCADA databases with test events, for example during a maintenance test. 14.6 Change lock function CHNGLCK 14.6.1 Identification GUID-6039E749-18CB-46C4-A4AD-3A8F09378522 v2 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Change lock function CHNGLCK Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 348: Functionality

    CHNGLCK input, that logic must be designed so that it cannot permanently issue a logical one on the CHNGLCK input. If such a situation would occur in spite of these precautions, then please contact the local ABB representative for remedial action. 14.6.3...

  • Page 349: Ied Identifiers Terminalid

    IED identifiers (TERMINALID) function allows the user to identify the individual IED in the system, not only in the substation, but in a whole region or a country. Use only characters A-Z, a-z and 0-9 in station, object and unit names. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 350: Settings

    They are very helpful in case of support process (such as repair or maintenance). 14.8.3 Settings GUID-168CD792-8811-43B5-8760-74ED82DE17F7 v3 The function does not have any parameters available in the local HMI or PCM600. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 351: Primary System Values Primval

    Signal matrix for analog inputs SMAI_20_1 GUID-893B456E-18C3-43B8-84A6-9E53D803C66C v1 14.10.2.1 Identification GUID-A13C0C27-1238-4C63-AA9F-6789F2A5C4C9 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Signal matrix for analog inputs SMAI_20_1 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 352: Function Block

    GROUP SIGNAL Quantity connected to the third analog input GROUP SIGNAL Quantity connected to the fourth analog input GROUP SIGNAL Calculated residual quantity if inputs 1-3 are connected Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 353: Settings

    Table 332: SMAI_20_1 Non group settings (advanced) Name Values (Range) Unit Step Default Description Negation Disabled Disabled Negation NegateN Negate3Ph Negate3Ph+N MinValFreqMeas 5 - 200 Limit for frequency calculation in % of VBase Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 354: Signal Matrix For Analog Inputs Smai_20_2

    Second analog input used for phase B or BC quantity GRP2_C STRING Third analog input used for phase C or CA quantity GRP2_N STRING Fourth analog input used for residual or neutral quantity Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 355: Settings

    Table 336: SMAI_20_2 Non group settings (advanced) Name Values (Range) Unit Step Default Description Negation Disabled Disabled Negation NegateN Negate3Ph Negate3Ph+N MinValFreqMeas 5 - 200 Limit for frequency calculation in % of VBase Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 356: Operation Principle

    Summation block 3 phase function 3PHSUM is used to get the sum of two sets of three-phase analog signals (of the same type) for those IED functions that might need it. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 357: Function Block

    Linear combination of input 2 signals from both SMAI blocks GROUP SIGNAL Linear combination of input 3 signals from both SMAI blocks GROUP SIGNAL Linear combination of input 4 signals from both SMAI blocks Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 358: Settings

    This is an advantage since all applicable functions in the IED use a single source of base values. This facilitates consistency throughout the IED and also facilitates a single point for updating values when necessary. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 359: Settings

    There are different levels (or types) of users that can access or operate different areas of the IED and tools functionality. The pre-defined user types are given in table Table 342. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 360: Authorization Handling In The Ied

    “✳✳✳✳✳✳✳✳”. The user must scroll for every letter in the password. After all the letters are introduced (passwords are case sensitive) choose OK and press the key again. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 361: Authority Status Athstat

    At least one user is logged on 14.14.5 Settings GUID-ECE18AA9-15CC-4522-AA31-78C4F0F052E4 v1 The function does not have any parameters available in Local HMI or Protection and Control IED Manager (PCM600) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 362: Operation Principle

    Denial of service, frame rate control DOSFRNT for front port 14.15.2.2 Function block GUID-F5C2ECFE-460C-4916-8441-3D778672F8B5 v1 DOSFRNT LINKUP WARNING ALARM IEC09000133-1-en.vsd IEC09000133 V1 EN-US Figure 164: DOSFRNT function block Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 363: Signals

    Denial of service, frame rate control for LAN1 port DOSLAN1 14.15.3.1 Identification GUID-C8EAE89C-6916-435E-B343-41289CB10213 v1 Function description IEC 61850 IEC 60617 ANSI/IEEE C37.2 identification identification device number Denial of service, frame rate control DOSLAN1 for LAN1 port Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 364: Function Block

    Number of non IP packets received in normal mode NonIPPackRecPoll INTEGER Number of non IP packets received in polled mode NonIPPackDisc INTEGER Number of non IP packets discarded Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 365: Operation Principle

    CPU load. The function has the following outputs: • LINKUP indicates the Ethernet link status • WARNING indicates that communication (frame rate) is higher than normal • ALARM indicates that the IED limits communication Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 367: Ied Physical Connections

    The IED shall be grounded with a 6 Gauge flat copper cable. The ground lead should be as short as possible, less than 59.06 inches (1500 mm). Additional length is required for door mounting. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 368 Section 15 1MRK 505 263-UUS A IED physical connections GUID-C75F6FD4-485D-464D-B7B0-55FD1AA608E9 V1 EN-US Figure 166: Protective ground pin is located below connector X102 on the 6U half 19” case Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 369: Inputs

    Table 350: Auxiliary voltage supply of 48-125 V DC Case Terminal Description 6U half 19” X410-1 - Input X410–2 + Input The two LEDs indicate the following conditions: Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 370: Binary Inputs

    - for input 1 BIO_3 X324-2 Binary input 1 + BIO_3 X324-3 X324-4 Common - for inputs 2-3 X324-5 Binary input 2 + BIO_3 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 371 Binary input 6 + BIO_4 X329-14 Binary input 7 + BIO_4 X329-15 X329-16 Common - for inputs 8-9 X329-17 Binary input 8 + BIO_4 X329-18 Binary input 9 + BIO_4 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 372 Binary input 5 + BIO_6 X339-11 X339-12 Common - for inputs 6-7 X339-13 Binary input 6 + BIO_6 X339-14 Binary input 7 + BIO_6 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 373: Outputs

    X307-6 X307-7 Power output 4, normally open PSM_102 BO4_PO X307-8 X307-9 Power output 5, normally open PSM_102 BO5_PO X307-10 X307-11 Power output 6, normally open PSM_102 BO6_PO X307-12 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 374 PCM600 info Hardware module Hardware channel instance X336-1 Power output 1, normally open BIO_6 BO1_PO X336-2 X336-3 Power output 2, normally open BIO_6 BO2_PO Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 375: Outputs For Signalling

    BIO_3 BO8_SO X321-15 Signal outputs 4 and 5, common X321-16 Signal output 6, normally closed BIO_3 BO9_SO X321-17 Signal output 6, normally open X321-18 Signal output 6, common Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 376 Hardware channel instance X336-7 Signal output 1, normally open BIO_6 BO4_SO X336-8 Signal output 1 X336-9 Signal output 2, normally open BIO_6 BO5_SO Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 377: Irf

    IP address automatically if the DHCPServer is enabled in LHMI. There is a DHCP server inside IED for the front interface only. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 378: Station Communication Rear Connection

    ● ● IEC 60870-5-103 ● ● ● = Supported 15.4.5 Recommended industrial Ethernet switches GUID-41F05A0B-D39C-4BF7-829A-EB37C5D37CF4 v4 ABB recommends three third-party industrial Ethernet switches. • RuggedCom RS900 • RuggedCom RS1600 • RuggedCom RSG2100 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 379: Connection Diagrams

    1MRK 505 263-UUS A Section 15 IED physical connections 15.5 Connection diagrams 15.5.1 Connection diagrams for REB650 A03A GUID-6C27423C-0350-4732-B8A0-A79C6505944B v1.1.1 1MRK006502-MB-1-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 380 Section 15 1MRK 505 263-UUS A IED physical connections 1MRK006502-MB-2-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 381 1MRK 505 263-UUS A Section 15 IED physical connections 1MRK006502-MB-3-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 382 Section 15 1MRK 505 263-UUS A IED physical connections 1MRK006502-MB-4-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 383 1MRK 505 263-UUS A Section 15 IED physical connections 1MRK006502-MB-5-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 384 Section 15 1MRK 505 263-UUS A IED physical connections 1MRK006502-MB-6-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 385 1MRK 505 263-UUS A Section 15 IED physical connections 1MRK006502-MB-7-1.1-ANSI V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 386 Section 15 1MRK 505 263-UUS A IED physical connections 1MRK006502-MB-8-1.1-ANSI V2 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 387: Labels

    Transformer designations Transformer input module, rated currents and voltages Optional, customer specific information Order number, dc supply voltage and rated frequency Product type, description and serial number Product type Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 388 IEC19000100 V1 EN-US Caution label Warning label Class 1 laser product label It is used when an optical SFP or an MR/LR LDCM is configured in the product. Earthing Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 389: Technical Data

    Ripple in the DC auxiliary voltage Max 15% of the DC value (at frequency of 100 Hz) Maximum interruption time in the 50 ms at V auxiliary DC voltage without resetting the IED Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 390: Energizing Inputs

    24...250 V DC Current drain 1.6...1.8 mA Power consumption/input <0.3 W Threshold voltage 15...221 V DC (parametrizable in the range in steps of 1% of the rated voltage) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 391: Signal Outputs

    L/R<40 ms, at V< 48/110/220 V DC Control voltage range 20...250 V DC Current drain through the monitoring circuit ~1.0 mA Minimum voltage over the TCS contact 20 V DC Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 392: Data Communication Interfaces

    Table 379: Degree of protection of flush-mounted IED Description Value Front side IP 40 Table 380: Degree of protection of the LHMI Description Value Front and side IP40 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 393: Environmental Conditions And Tests

    96 h at +85ºC Damp heat steady state 240 h at +40ºC IEC 60068-2-78 tests humidity 93% cyclic 6 cycles at +25 to +55ºC IEC 60068-2-30 humidity 93...95% Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 395: Ied And Functionality Tests

    Power frequency (50 Hz) magnetic IEC 61000-4-8, level 5 field • 1000 A/m • Continuous 100 A/m Power frequency immunity test IEC 60255-22-7, class A IEC 61000-4-16 Table continues on next page Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 396: Insulation Tests

    1.2/50 μs, source energy 0.5 J, communication Insulation resistance measurements IEC 60255-5 ANSI C37.90-2005 • Isolation resistance >100 MΏ, 500 V DC Protective bonding resistance IEC 60255-27 • Resistance <0.1 Ώ (60 s) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 397: Mechanical Tests

    LV directive 2006/95/EC Standard EN 60255-27 (2005) 18.5 EMC compliance GUID-9B1F0C9F-664E-41C8-ADA3-4376E096A9C9 v4 Table 387: EMC compliance Description Reference EMC directive 2004/108/EC Standard EN 50263 (2000) EN 60255-26 (2007) Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 399: Time Inverse Characteristics

    Figure 168: Three overcurrent protections connected in series Stage 3 Time Stage 2 Stage 2 Stage 1 Stage 1 Stage 1 Fault point position en05000130.vsd IEC05000130 V1 EN-US Figure 169: Definite time overcurrent characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 400 Figure 171: Selectivity steps for a fault on feeder B1 where: is The fault occurs is Protection B1 trips is Breaker at B1 opens is Protection A1 resets Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 401: Operation Principle

    (pickup value minus the hysteresis) and the reset time has elapsed. The general expression for inverse time curves is according to equation 47. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 402 ÷ A td ç ÷ è ø Pickupn è ø (Equation 49) EQUATION1643 V1 EN-US For the numerical protection the sum below must fulfil the equation for trip. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 403 In order to fully comply with IEC curves definition setting parameter tMin shall be set to the value which is equal to the operating time of the selected IEC inverse time curve for measured current of Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 404: Inverse Time Characteristics

    Thus, if only the inverse time delay is required, it is of utmost importance to set the definite time delay for that stage to zero. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 405 40 ms IEC Very inverse A=13.5, P=1.0 IEC Inverse A=0.14, P=0.02 IEC Extremely inverse A=80.0, P=2.0 IEC Short time inverse A=0.05, P=0.04 IEC Long time inverse A=120, P=1.0 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 406 EQUATION1662 V1 EN-US Type C curve: td = (0.05-1.10) in steps of 0.01 unless otherwise stated × æ ö VPickup ç × ÷ 0.035 è ø VPickup EQUATION1663 V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 407 VPickup EQUATION1662 V1 EN-US Type C curve: td = (0.05-1.10) in steps of 0.01 × æ ö VPickup ç × ÷ 0.035 è ø VPickup EQUATION1663 V1 EN-US Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 408 Section 19 1MRK 505 263-UUS A Time inverse characteristics SEMOD118114-4 v4 A070750 V2 EN-US Figure 173: ANSI Extremely inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 409 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070751 V2 EN-US Figure 174: ANSI Very inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 410 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070752 V2 EN-US Figure 175: ANSI Normal inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 411 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070753 V2 EN-US Figure 176: ANSI Moderately inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 412 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070817 V2 EN-US Figure 177: ANSI Long time extremely inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 413 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070818 V2 EN-US Figure 178: ANSI Long time very inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 414 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070819 V2 EN-US Figure 179: ANSI Long time inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 415 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070820 V2 EN-US Figure 180: IEC Normal inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 416 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070821 V2 EN-US Figure 181: IEC Very inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 417 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070822 V2 EN-US Figure 182: IEC Inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 418 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070823 V2 EN-US Figure 183: IEC Extremely inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 419 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070824 V2 EN-US Figure 184: IEC Short time inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 420 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070825 V2 EN-US Figure 185: IEC Long time inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 421 1MRK 505 263-UUS A Section 19 Time inverse characteristics A070826 V2 EN-US Figure 186: RI-type inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 422 Section 19 1MRK 505 263-UUS A Time inverse characteristics A070827 V2 EN-US Figure 187: RD-type inverse time characteristics Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 423 1MRK 505 263-UUS A Section 19 Time inverse characteristics GUID-ACF4044C-052E-4CBD-8247-C6ABE3796FA6 V1 EN-US Figure 188: Inverse curve A characteristic of overvoltage protection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 424 Section 19 1MRK 505 263-UUS A Time inverse characteristics GUID-F5E0E1C2-48C8-4DC7-A84B-174544C09142 V1 EN-US Figure 189: Inverse curve B characteristic of overvoltage protection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 425 1MRK 505 263-UUS A Section 19 Time inverse characteristics GUID-A9898DB7-90A3-47F2-AEF9-45FF148CB679 V1 EN-US Figure 190: Inverse curve C characteristic of overvoltage protection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 426 Section 19 1MRK 505 263-UUS A Time inverse characteristics GUID-35F40C3B-B483-40E6-9767-69C1536E3CBC V1 EN-US Figure 191: Inverse curve A characteristic of undervoltage protection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 427 1MRK 505 263-UUS A Section 19 Time inverse characteristics GUID-B55D0F5F-9265-4D9A-A7C0-E274AA3A6BB1 V1 EN-US Figure 192: Inverse curve B characteristic of undervoltage protection Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...

  • Page 429: Glossary

    Central processor unit Carrier receive Cyclic redundancy check CROB Control relay output block Carrier send Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 430 Electrical and functional description for digital lines used by local telephone companies. Can be transported over balanced and unbalanced lines Communication interface module with carrier of GPS receiver module Graphical display editor within PCM600 Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 431 Ingression protection, according to IEC standard, level IP40-Protected against solid foreign objects of 1mm diameter and greater. IP 54 Ingression protection, according to IEC standard, level IP54-Dust-protected,protected againstsplashing water. Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 432 Parameter setting tool within PCM600 PT ratio Potential transformer or voltage transformer ratio PUTT Permissive underreach transfer trip RASC Synchrocheck relay, COMBIFLEX Relay characteristic angle RFPP Resistance for phase-to-phase faults Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 433 FTP, UDP and RDP. TNC connector Threaded Neill-Concelman, a threaded constant impedance version of a BNC connector TPZ, TPY, TPX, TPS Current transformer class according to IEC User management tool Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 434 Three times zero-sequence current. Often referred to as the residual or the -fault current Three times the zero sequence voltage. Often referred to as the residual voltage or the neutral point voltage Busbar protection REB650 Technical manual © Copyright 2011 ABB. All rights reserved...
  • Page 436 ABB AB Substation Automation Products SE-721 59 Västerås, Sweden Phone +46 (0) 21 32 50 00 Scan this QR code to visit our website www.abb.com/substationautomation © Copyright 2011 ABB. All rights reserved.

This manual is also suitable for:

Reb650

Table of Contents
