Method of Usage

I. Turn on the power supply of this product:
Product connection
Plugging-in diagram
diagram
II. Massage Function Control Operation:
1.Standby
·After the massage chair is powered on and turned off,
the remote controller is blank in the standby state (i.e.
the LED lamp is off) and cannot perform any operation
(except the key switch). You can use the armrest shortcut
keys to adjust the angle of the backrest and leg rest. You
can also use the voice control button for wakeup.
2.Start massage (power switch)
·Press the switch to start massage. Enter the start-up screen. The backrest will
maintain the default position, and the leg rest will be slightly raised. Just wait for
any one of automatic function programs in the automatic function selection
interface to start massage. If no "AUTO" function is selected within 5 minutes, the
massage chair will automatically shut down.
Power switch diagram
of the product
FU FU
T5 AL SE T5 AL SE
: :
25 0V 25 0V
PO
W ER
IN PU
T
Auto program
20:00
Fast massage
Comfort massage
Relax massage
Stretch massage
Full body massage
Meck&shoulder massage
Select the object with ▲▼ and press OK
12
Method of Usage
1) Lying angle adjustment
·After selecting any automatic function, the positions of the backrest and the leg
rest will be adjusted to the preset angles.
· After the angle is adjusted, the massage chair will automatically perform the
shoulder position and body shape detection. Wait for completion of such detection
(alternatively, press "OK" to skip the step).
Auto lying down
Attention! Ensure that there
are no objects around the
massage chair
Press OK to skip
2) Shoulder position adjustment
·After detecting the shoulder position, the buzzer will beep. If there is any difference
from the actual shoulder position, adjust it to the appropriate position by pressing
the "UP" or "DOWN" key. The shoulder position has 11 adjustable levels. If there is
no shoulder position adjustment within 10 seconds, the massage function will start
automatically. Press "OK" directly to start massage immediately. If no shoulder
position can be detected, massage will be started according to the shoulder height
by default. Note: During massage, under the information interface, you can press
"Right Button" to select the "Shoulder Adjustment" menu, and press "OK" to enter
the shoulder adjustment interface. You can also use "Up Key" or "Down Key" to
adjust the shoulder position.
20:00
Auto Mode Shoulder position
20:00
Comfort massage>
Knead
Back speed Back intensity
Air intensity Roll speed
Adjustment Shoulder
◀▶
Select the object with and press OK Pl e ase use ▲▼ to adj u st the shoul d er posi t i o n and press OK
Body sensing
Just a moment......
Press OK to skip
20:00
・Low shoulder position
・Suitable shoulder position
・High shoulder position
13
