MT1065/1075 Installation Guide
With Optional 2.7 - 4.2:1 Zoom Lens (MT60-26ZL)
Contents
Product Description, Lens Specs,
Screen/Aspect Ratio, Notes and Formulas
Diagrams and Distance Charts,
Cabinet Dimensions, Top, Front and Right
Bottom, Back and Left
Ceiling Mount Dimensions
Input Panel and Control Codes

Product Description

Type:
3 panel LCD projector,
1.0" p-Si TFT w/MLA
Resolution:
1024 x 768 (4:3)
1024 x 576 (16:9)

Lens Specifications

Throw Ratio: 2.7 - 4.2:1(for 100" diagonal)
Offset Angle: 5.1°-8.0° (for 100" diagonal)
Screen Sizes: 40"-500"
Screen/Aspect Ratio
Both 4:3 and 16:9 screens are fully supported with proper aspect ratio control for both type sources using NEC developed
scaling technology. By selecting the screen type in the menus, Aspect Ratio control is reconfigured for that screen type.
For a 4:3 screen; select "4:3" in the "Screen" menu for proper aspect ratio control of 4:3 and 16:9 sources.
For a 16:9 screen; select "16:9" in the "Screen" menu for proper aspect ratio control of 4:3 and 16:9 sources.
*Factory default "Screen" setting is "4:3".
Notes
For screen sizes not indicated on the projection charts, use the formulas below.
If a value in a chart does not match the results of the formulas, use the values in the chart.
The ceiling must be strong enough to support the projector and the installation must be in accordance with any local
building codes.
Distances are in inches, for millimeters multiply by 25.4.
Distances may vary ±5%.
Formulas
The Projection Formulas use the image width for calculation. Image width is the same for all aspect ratios, only vertical image size
varies. For proper projector placement, determine the image width for a desired screen size. Use the Screen Formulas below to
calculate all screen dimensions. Plug in the image width for "W" in the Projection Formulas.
Refer to the diagrams and charts for popular screen sizes on page 2.
Definitions:
W = Image Width
H = Image Height (Size)
B = Vertical distance between lens center and screen center
C = Throw distance
α = Projection angle
Projection Formulas:
B = 0.375W
C (wide) = 2.7264W – 5.276
C (tele) = 4.2864W – 5.354
α (wide) = tan
-1
(B/C(wide))
α (tele) = tan
-1
(B/C(tele))
Note: To avoid premature lamp failure, do not tilt the front of the projector up or down by more than 75° from level. Tilting the front of the
projector up or down from 15° to 75° might reduce lamp life by up to 25%.
www.necvisualsystems.com
4:3 Screens
16:9 Screens
Vertical Position for a 16:9 screen: The Vertical Position adjustment moves the 16:9
image up and down in the unused portion of the 4:3 panel. This adjustment is only
available when the projector is set for '16:9' in the 'Screen' menu. The range of Vertical
Position is dependent on aspect ratio and 3D Reform used. If 3D Reform is not used,
the approximate range of Vertical Position is +/-0.167H (H=Screen Height) when using
a 16:9 screen.
Pg. 1
Pg. 2
Pg. 3
Pg. 4
Pg. 5
Pg. 6
Pg. 7
Brightness:
MT1065 w/MT60-26ZL: 2900 ANSI lumens
MT1075 w/MT60-26ZL: 3500 ANSI lumens
Dimensions: 13.14"(W) x 5.48"(H) x 12.71"(D)
Weight:
13.2 lbs
Focal Length: 53.8mm – 82.9mm
F/#:
2.04 – 2.80
Power Zoom / Power Focus
4:3 Screen Formulas:
W = H x 4/3
H = W x 3/4
Screen Diagonal = W x 5/4
16:9 Screen Formulas:
W = H x 16/9
H = W x 9/16
Screen Diagonal = W x 18.358/16
NEC Solutions (America), Inc.
Visual Systems
Page 1 of 7
v2.0

Advertisement

loading

Summary of Contents for NEC MT1065

  • Page 1: Product Description

    (B/C(tele)) Note: To avoid premature lamp failure, do not tilt the front of the projector up or down by more than 75° from level. Tilting the front of the projector up or down from 15° to 75° might reduce lamp life by up to 25%.
  • Page 2: Ceiling Mounted

    * lens set back inside shroud 0.4" from front of cabinet Note: To avoid premature lamp failure, do not tilt the front of the projector up or down by more than 75° from level. Tilting the front of the projector up or down from 15° to 75° might reduce lamp life by up to 25%.
  • Page 3 * lens set back inside shroud 0.4" from front of cabinet Note: To avoid premature lamp failure, do not tilt the front of the projector up or down by more than 75° from level. Tilting the front of the projector up or down from 15° to 75° might reduce lamp life by up to 25%.
  • Page 4: Cabinet Dimensions

    Cabinet Dimensions The following drawings show the cabinet dimensions. Dimensions are in inches. For millimeters multiply by 25.4. IR SENSOR INTAKE 2.21 13.14 LAMP 3.63 IR SENSOR EXHAUST 4.92 3.19 IMAGE SENSOR www.necvisualsystems.com Page 4 of 7...
  • Page 5 Cabinet Dimensions (continued) The following drawings show the cabinet dimensions. Dimensions are in inches. For millimeters multiply by 25.4. MAX M4x8 INTAKE FOR MOUNT IR SENSOR 2.38 INTAKE (AIR FILTER) www.necvisualsystems.com 10.63 0.67 9.49 IR SENSOR 0.47 Page 5 of 7...
  • Page 6 Optional Ceiling Mount Dimensions (Model #: MT60CM) The following drawings show ceiling mount dimensions. Dimensions are in inches. For millimeters multiply by 25.4. 3.75 5.75 www.necvisualsystems.com Page 6 of 7...
  • Page 7: Input Panel

    None Communications: Full duplex NOTE 1: It is recommended to set the projector to “Idle Mode” in the Setup/Standby Mode menu for best Power ON response. NOTE 2: Pins 1, 4, 6, and 9 are used inside the projector. NOTE 3: Jumper “Request to send” and “Clear to Send” together on both ends of the cable to simplify cable connection.

This manual is also suitable for:

Mt1075
