Summary of Contents for DigiTech B-COCKPiT BL18
- Page 1 B-COCKPiT BL-18 Operating Manual B-COCKPiT Operating Manual BL18 Model Version: CH-20200707 Shenzhen Digitech Co., Ltd. www.riding-evolved.com...
- Page 2 5. Do not dispose HMI or any other e-bike components into house-hold wastes, follow your local regulations and dispose them in an environmental-friendly manner. 6. Damage / malfunction caused by improper installation or usage are not covered by after-sales service. Shenzhen Digitech Co., Ltd. www.riding-evolved.com...
-
Page 3: Table Of Contents
Meter Interface ..................8 Miscellaneous Interfaces ................9 Error-Code Notification ................9 Maintenance and Service ................11 Maintenance and Cleaning ................. 11 After-sales Service .................. 11 Disposal ....................11 Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 4: Product Description And Specifications
Parts Description 1.77” LCD display Mounting Bracket “+” Button “i” Display function button “-” Button Technical Data Rated operating voltage 36V / 48 V DC Operating temperature -20°C ~ +45°C Storage temperature -20°C ~ +45°C Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 5: Dimensions And Features
Dimension E 39 mm Conformities Dimension F 22.2 mm IP-Level IPX5 (USB Cap Closed) Keypad Certifications CE / EN15194 / RoHS No. of Buttons Button Functions + / - / i * Available for BL18XS Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 6: Installation
Do Not Overtighten or it may cause damage to the HMI Connect the cables Arrow mark Arrow mark Securely connect the cables of B-COCKPiT with E-bike controller by aligning the 2 arrow marks. Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 7: System Operations
01：Controller reported power； method 02：The display detect the voltage and calculates Walk Mode 00：Yes; 01：No Default Assist 0-max Max Assist 00：Digitech（Default） ； SE** Logo 01：Neutral welcome screen； 02：Customized Logo Reset 00：Yes；01：No Serial 00：3.3V；01：5V communication Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 8: Button Functions
---- ---- & Press “+” and “-” buttons together: Short Press Long Press Long Press & Hold Meter Interface ---- Enter Menu Interface ---- Menu Interface ---- Save Changes and Exit ---- Meter Interface Shenzhen Digitech Co., Ltd. www.riding-evolved.com... -
Page 9: Miscellaneous Interfaces
Changing the parameters in “System Config” without proper knowledge may cause abnormal behaviors of the E-bike. And may even lead to unsafe situations. Consult with the manufacturer first before making any changes on your own. Miscellaneous Interfaces Error-Code Notification Shenzhen Digitech Co., Ltd. www.riding-evolved.com... - Page 10 Check motor connection, replace motor if necessary Speed Sensor Error Check sensor connection, replace sensor if necessary Brake Error Check Brake connection, replace brakes if necessary Communication Error Check connectors and contacts between each components Shenzhen Digitech Co., Ltd. www.riding-evolved.com...
-
Page 11: Maintenance And Service
Please contact support@riding-evolved.com for inquiries and after-sales services. Disposal Follow your local regulations and dispose the B-COCKPiT unit in an environmental-friendly manner. Do not dispose B-COCKPiT or any other e-bike components into house-hold wastes! Shenzhen Digitech Co., Ltd. www.riding-evolved.com...
