- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-CAM-1080PTZ Full HD PTZ Camera USER MANUAL January 23, 2023 Hall Technologies February 03, 2023 Page 1 of 52...
- Page 2 8. Protect the power cord from being walked on or pinched particularly at plugs. 9. Only use attachments / accessories specified by the manufacturer. 10. Refer all servicing to qualified service personnel. Hall Technologies February 03, 2023 Page 2 of 52...
-
Page 3: Table Of Contents
Camera - image Troubleshooting Camera - focus No Image Camera - noise reduction Abnormal Image Shaky or Vibrating Image Video - format No Video in Soft Codec Version Specifications Restore Default Hall Technologies February 03, 2023 Page 3 of 52... -
Page 4: Introduction
Introduction OVERVIEW The HT-CAM-1080PTZ is an HD PTZ camera. With built-in AI intelligence, the camera can automatically pan, tilt, and/or zoom to the best view to include all participants or track a presenter, and regions can be set in the view to prevent the camera from tracking undesired areas. And, built around a low noise CMOS image sensor, the lens provides for a clean and clear video even in low lit areas. -
Page 5: Package Contents
Ÿ 1x USB 3.0 Type-B to Type-A Cable, 3m (9.8ft) Ÿ 1x 9-pin Female D-Sub to 8-pin Male mini-DIN cable Ÿ 1x IR Remote Control Ÿ 1x Power Adapter Ÿ 1x Wall Mount Hall Technologies February 03, 2023 Page 5 of 52... -
Page 6: Product Views
Product Views FRONT VIEW REAR VIEW DIMENSIONS VIEW Hall Technologies February 03, 2023 Page 6 of 52... - Page 7 8-pin mini-DIN loop through RS232 connection to next camera RS422/RS485 Phoenix connection for controlling the PTZ camera using RS422/RS485 protocols RJ45 Ethernet port, PoE DC12V Power supply connection (when not using PoE) Switch Power on/off switch Hall Technologies February 03, 2023 Page 7 of 52...
- Page 8 PRODUCT WIRING and CONNECTIONS DIAGRAM RS-232 INTERFACE Hall Technologies February 03, 2023 Page 8 of 52...
-
Page 9: Rotary Dial
A camera reboot is needed after changing the selection. By default, F is selected on the rotary dial, which allows for video format selection on the OSD menu (accessed with the remote control). Hall Technologies February 03, 2023 Page 9 of 52... -
Page 10: Installation
Secure the wall mount to the wall using the included M6 nuts and washers, or, if using drywall anchors in step one, secure using the drywall anchor screws. 4. Step Four Mount the camera to the top of the wall mount and secure with the included camera bolt. Hall Technologies February 03, 2023 Page 10 of 52... -
Page 11: Application Wiring G
Application Wiring There are many applications for using the HT-CAM-1080PTZ camera depending on the needs of the user. The following are some examples, which can also be used simultaneously. USB-B OUTPUT With the USB-B output the camera can be directly connected into any USB hub to be sent to the USB host for use with a laptop on a soft codec call. - Page 12 Using either the HDMI or HD-SDI video outputs, users can connect camera(s) to a larger video conference system. Pan, tilt, and zoom control can be accomplished over Ethernet or RS-232. STREAMING Using the LAN port the HT-CAM-1080PTZ can stream directly to a server or provide an RTSP stream. Hall Technologies February 03, 2023...
-
Page 13: Control - Ir Remote Control L
OSD menu. F1: Turns off AI human detection. F2: Turns on AI human detection. F3: Toggles between Real-time Tracking mode and Region Tracking mode. F4: Change tracking target on Real-time Tracking mode. Hall Technologies February 03, 2023 Page 13 of 52... -
Page 14: Key Combinations
KEY COMBINATIONS Hall Technologies February 03, 2023 Page 14 of 52... -
Page 15: Osd Menu U
Simplified Chines | English MONOCULAR TRACKING Menu Item Description Selection Options Turn on/off AI tracking and select between OFF | ON: Region Tracking | ON: Real-time Tracking the two tracking modes. Tracking Hall Technologies February 03, 2023 Page 15 of 52... -
Page 16: Setup
Auto Flip OFF | ON installed upside down. CAMERA Menu Item Description Selection Options Change the image between various built-in Style Default | Normal | Clarity | Bright | Soft presets. Hall Technologies February 03, 2023 Page 16 of 52... -
Page 17: Camera - Exposure
Close | F11 | F9.6 | F8.0 | F6.8 | F5.6 | F4.8 | Iris opening (only available in AAE mode) F4.0 | F3.4 | F2.8 | F2.4 | F2.0 | F1.8 Hall Technologies February 03, 2023 Page 17 of 52... -
Page 18: Camera - Color
Control backlight compensation (only 0 ~ 10 available in Auto mode) Control the camera’s auto white balance AWB Sensitivity HIGH | MIDDLE | LOW sensitivity (only available in Auto mode) CAMERA - IMAGE Hall Technologies February 03, 2023 Page 18 of 52... -
Page 19: Camera - Focus
Set the camera’s focus zone for the auto AF Zone All | Top | Center | Bottom focus AF Sensitivity Set the sensitivity of the auto focus mode Low | Middle | High Hall Technologies February 03, 2023 Page 19 of 52... -
Page 20: Camera - Noise Reduction
Automatically slow down pan and tilt speeds when the camera is zoomed into objects that Speed by zoom ON | OFF are far away Zoom Speed Set the camera’s zoom speed 1 ~ 8 Hall Technologies February 03, 2023 Page 20 of 52... -
Page 21: Video Format
Set the speed of the camera when a preset is Preset Speed 1 ~ 10 recalled VIDEO FORMAT Menu Item Description Selection Options Select the desired resolution of the camera’s Video Format (shown) video output VERSION Displays the camera version. Hall Technologies February 03, 2023 Page 21 of 52... -
Page 22: Restore Default
RESTORE DEFAULT Menu Item Description Selection Options Restore factory defaults (color style and video Restore Default? YES | NO format are not restored to factory defaults) Hall Technologies February 03, 2023 Page 22 of 52... -
Page 23: Web Ui
4. Input Username and Password (default: admin / admin) and click Login to enter the main page of Web UI. The Web UI main page consists of three tabs along the top right: Preview, Monocular Tracking, and Configuration. The last button on the right is Logout. Hall Technologies February 03, 2023 Page 23 of 52... -
Page 24: Preview
Audio Mute: Click the button to mute audio. Stream Mode: Toggle the preview between Main Stream and Sub Stream. Full Mode: Click to enter full screen preview mode. Click “ESC” to escape. Hall Technologies February 03, 2023 Page 24 of 52... -
Page 25: Monocular Tracking
“Set”. Click on the box to enable the tracked region. Note: A minimum of 2 regions needs to be set, and each preset preview image must be continuous from left to right with overlap. Regional Settings Hall Technologies February 03, 2023 Page 25 of 52... -
Page 26: Configuration: Audio
Note: Some changes require the camera to be rebooted. CONFIGURATION: VIDEO CONFIGURE / VIDEO ENCODE The camera has the ability to have two streams: Main Stream and Sub Stream. The settings for those streams are found on this page. Hall Technologies February 03, 2023 Page 26 of 52... - Page 27 It is recommended to use no more than 50% of your available upload bandwidth capacity on a dedicated line. Bit Rate (Kb/S) • Main Stream: 64 ~ 102,400 Kbps • Sub Stream: 64 ~ 40,960 Kbps Hall Technologies February 03, 2023 Page 27 of 52...
-
Page 28: Configuration: Video Configure / Stream Publish
Note: Some changes require the camera to be rebooted. CONFIGURATION: VIDEO CONFIGURE / STREAM PUBLISH This page is used to push streams to a network server. The camera needs to be on the same network as the server. Hall Technologies February 03, 2023 Page 28 of 52... -
Page 29: Configuration: Video Configure / Rtp Multicast
Note: Some changes require the camera to be rebooted. CONFIGURATION: VIDEO CONFIGURE / RTP MULTICAST UI Element Description Enable Click to enable multicast/unicast streams. Hall Technologies February 03, 2023 Page 29 of 52... -
Page 30: Configuration: Video Configure / Video Parameters / Focus
AF-Zone Set the camera’s focus zone for the auto focus: All | Top | Center | Bottom AF-Sensitivity Set the sensitivity of the auto focus mode: High | Middle | Low Hall Technologies February 03, 2023 Page 30 of 52... -
Page 31: Configuration: Video Config/Video Parameters/Exposure
Select the priority setting of the camera’s iris opening: Close | F11 | F9.6 | F8.0 | F6.8 | Iris F5.6 | F4.8 | F4.0 | F3.4 | F2.8 | F2.4 |F2.0 | F1.8 Modify the settings of the dynamic range compression: Close | 1 to 8 Hall Technologies February 03, 2023 Page 31 of 52... -
Page 32: Configuration: Video Configure / Video Parameters / Color
WB Mode Control the white balance: Auto | Manual | One Push | VAR RG Tuning Fine tune red gain: -10 to 10 BG Tuning Fine tune blue gain: -10 to 10 Hall Technologies February 03, 2023 Page 32 of 52... -
Page 33: Configuration: Video Config / Video Parameters / Image
Modify the brightness levels (how dark or light the image is): 0 to 100 Modify the contrast levels. Higher contrast helps the image look lively; lower contrast Contrast makes the image look flat and monotonous: 0 to 100 Hall Technologies February 03, 2023 Page 33 of 52... -
Page 34: Configuration: Video Configure / Video Parameters / Nr
Reduce noise from one frame to the next by removing any oddity that does not appear in NR-2D each frame: OFF | 1 to 8 NR-3D Remove grainy fuzzy appearances of low light images: OFF | 1 to 8 Hall Technologies February 03, 2023 Page 34 of 52... - Page 35 CONFIGURATION: VIDEO CONFIGURE / VIDEO PARAMETERS / STYLE UI Element Description Change the image between the various built-in presets: Default | Normal | Clarity | Bright Style | Soft Hall Technologies February 03, 2023 Page 35 of 52...
-
Page 36: Configuration: Video Configure / Video Osd
Press to save changes. Once saved, a small pop-up window will appear in the bottom right Save of the screen saying the changes made have been saved. Note: Some changes require the camera to be rebooted. Hall Technologies February 03, 2023 Page 36 of 52... -
Page 37: Configuration: Video Configure / Osd Font Size
Press to save changes. Once saved, a small pop-up window will appear in the bottom right Save of the screen saying the changes made have been saved. Note: Some changes require the camera to be rebooted. Hall Technologies February 03, 2023 Page 37 of 52... -
Page 38: Configuration: Network Configure / Network Port
Note: Some changes require the camera to be rebooted. CONFIGURATION: NETWORK CONFIGURE / ETHERNET UI Element Description DHCP Click to enable DHCP mode; uncheck box to disable DHCP and enter Static mode. Hall Technologies February 03, 2023 Page 38 of 52... -
Page 39: Configuration: Network Configure / Dns
CONFIGURATION: NETWORK CONFIGURE / SRT SRT (Secure Reliable Transport) is a royalty-free, open-source video streaming transport protocol that delivers secure low-latency streaming performance over noise or unpredictable (lossy) networks such as the public internet. Hall Technologies February 03, 2023 Page 39 of 52... -
Page 40: Configuration: Network Configure / Rtsp
Press to save changes. Once saved, a small pop-up window will appear in the bottom right Save of the screen saying the changes made have been saved. Note: Some changes require the camera to be rebooted. Hall Technologies February 03, 2023 Page 40 of 52... -
Page 41: Configuration: System Configure / System Attribute
Press to save changes. Once saved, a small pop-up window will appear in the bottom right Save of the screen saying the changes made have been saved. Note: Some changes require the camera to be rebooted. Hall Technologies February 03, 2023 Page 41 of 52... -
Page 42: Configuration: System Configure / System Time
Note: Some changes require the camera to be rebooted. Time Settings Select the time settings. Computer Time Shows the connected computer’s time. Sync Sync’s the selected time to the camera. Hall Technologies February 03, 2023 Page 42 of 52... -
Page 43: Configuration: System Configure / User Set
3. Update the HTML5***.mrg (HTML) last (if there is no HTML file then ignore this step) 4. After updating all files restore the camera to factory default. 5. If needed, clean all cache of the browser after performing the update. Hall Technologies February 03, 2023 Page 43 of 52... -
Page 44: Configuration: System Configure / Default
CONFIGURATION: SYSTEM CONFIGURE / DEFAULT Click “Restore factory defaults” to return the camera’s settings to the factory defaults. A pop-up screen will ask to confirm the desire to reset the camera to the factory defaults. Hall Technologies February 03, 2023 Page 44 of 52... -
Page 45: Configuration: System Configure / Reboot
The following are instructions to utilizing the HT-CAM-1080PTZ camera in the Google Meet, Microsoft Teams, and Zoom soft codec applications (connecting the camera’s USB-B output to the laptop’s USB input). The HT-CAM-1080PTZ is not limited to these three. (For soft codec applications outside of these three please refer to their user manual.) GOOGLE MEET To use the camera in Google Meet, open “More Options”, then click “Settings.”... -
Page 46: Microsoft Teams
MICROSOFT TEAMS To use the camera in Microsoft Teams, open "Device Settings" located in the “More” menu below tab. In Video Settings, select the “HD-CAMERA”. Hall Technologies February 03, 2023 Page 46 of 52... -
Page 47: Zoom
To use the camera in Zoom, click on the “up” arrow on the microphone and camera buttons located on the bottom left part of the Zoom screen. In the video settings, select the “HD Camera” for the camera. VIDEO Hall Technologies February 03, 2023 Page 47 of 52... -
Page 48: Troubleshooting
Any external vibration that is affecting the camera will be more apparent when the camera is zoom in on people or objects. c. If the desire is to be able to change the video format on the OSD, make sure the arrow is pointed to F. Hall Technologies February 03, 2023 Page 48 of 52... -
Page 49: No Video In Soft Codec
YUY2/NV12: 1920x1080 | 1280x720 | 1024x576 | 800x600 | 800x448 | 640x480 | 640x360 | 480x270 | 320x180 - @30/25/20/15/10/5fps 72.5° W Aperture F=1.8~2.4 Optical Zoom / Digital Zoom 12X / 15X Hall Technologies February 03, 2023 Page 49 of 52... - Page 50 10M/100M adaptive Ethernet port with PoE Network Protocol RTSP, RTMP, ONVIF, GB/T28181, VISCA over IP, IP VISCA, RTMPS, SRT Control Interface Connections 1x 4-Pin Phoenix, RS232-IN, RS232-OUT, RS422 compatible with RS485 Hall Technologies February 03, 2023 Page 50 of 52...
- Page 51 20% to 80%, non-condensing Power Consumption 5W (Max) (5V, 1A) Device Dimension (W x H x D) 181mm x 115mm x 149mm / 7.13” x 4.53” x 5.87” Product Net Weight 1.15kg Environment Indoor Hall Technologies February 03, 2023 Page 51 of 52...
- Page 52 © Copyright 2022. Hall Technologies All rights reserved. 1234 Lakeshore Drive - Suite #150, Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies February 03, 2023 Page 52 of 52...
