- Page 1 Hall Technologies • 1234 Lakeshore Dr Suite #150 Coppell, TX 75019 • halltechav.com HT-CAM-4K-EPTZ Auto Framing 4K EPTZ Camera User Manual Version: 1.0 Hall Technologies February 9, 2022 Page 1 of 17...
- Page 2 3.4 Do not power on before completely installation. Magnetic Interference Electromagnetic fields at specific frequencies may affect the video image. This product is Class A. It may cause radio interference in household application. Appropriate measure is required. Hall Technologies February 9, 2022 Page 2 of 17...
-
Page 3: Table Of Contents
2.4.1 External Interface 3.Application Instruction 3.1 Remote Control 3.1.1 Keys Introduction 3.1.2 Applications 3.2 Menu Introduction 3.2.1 Main Menu 4. Maintenance and Troubleshooting 4.1 Camera Maintenance 4.2 Troubleshooting 5. Copyright Statement Hall Technologies February 9, 2022 Page 3 of 17... -
Page 4: Camera Installation
2. Connect the camera via USB cable to a computer, video conference terminal or other USB input device. Log in to the video conference software and select the device to see the image output. Hall Technologies February 9, 2022 Page 4 of 17... -
Page 5: Product Overview
Standard Accessory – IR Remote Control, USB3.0 Cable, User Manual 2.2 Main Features HT-CAM-4K-EPTZ is a 4K ultra-high-definition EPTZ camera with a new design. With AI intelligence, it can frame according to the number of people in the scene, and the characters will be framed in the middle. -
Page 6: Technical Parameter
Auto / Manual Focus Manual Exposure Auto / Manual/ On/Off ≥50dB USB Feature Operation Systems Windows 7(1080p or lower), Windows 8.1, Windows 10 ; macOS™ 10.10 or higher; Android ； Linux (UVC support) Hall Technologies February 9, 2022 Page 6 of 17... -
Page 7: Interfaces Instruction
20%～90% Working Temperature -10℃～+50℃ Working Humidity 20%～80% Dimension 180mm×42.5mm×46.3mm Weight Around 0.3kg Working Environment Indoor Accessory User Manual, USB 3.0 cable 2.4 Interface Instruction 2.4.1 External Interface Figure 2.4 Wiring Diagram Hall Technologies February 9, 2022 Page 7 of 17... -
Page 8: Application Instruction
1. In this manual, “press the key” means a click rather than a long-press, and a special note will be given if a long-press for more than one second is required. Hall Technologies February 9, 2022 Page 8 of 17... - Page 9 2. Zoom out the lens: press 【 】key 3. Long press these two buttons, it will continue to zoom in/out; release it halfway and stop. 6. Auto Framing Function On/Off Turn on/off Auto Framing Function Hall Technologies February 9, 2022 Page 9 of 17...
-
Page 10: Menu Introduction
1. Language Setting press 【← →】key to select Language 2. System Setting Move the pointer to the (Setup) in the Main Menu, click the【OK】key and enter into the SYSTEM SETTING menu as shown below: Hall Technologies February 9, 2022 Page 10 of 17... - Page 11 000, 1/10000 (only available in Manual and Shutter priority mode) Brightness: 0~23 (only available in Brightness priority mode) 4. Colour Move the pointer to the (COLOUR) in the Main Menu, click the【OK】and enter the COLOUR sub menu as follows: Hall Technologies February 9, 2022 Page 11 of 17...
- Page 12 AWB Sensitivity: high/middle/low (only available in automatic mode) Chroma: 0~8 5. Image Move the pointer to the (IMAGE) in the Menu, click the【OK】and enter into the IMAGE sub menu as follows: Hall Technologies February 9, 2022 Page 12 of 17...
- Page 13 REDUCTION menu as follows: 2D Noise Reduction: Auto, close, 1~7 3D Noise Reduction: Close, 1~8 7. Version Move the pointer to the (VERSION) in the Main Menu, click the【OK】and enter the (VERSION) as follows: Hall Technologies February 9, 2022 Page 13 of 17...
- Page 14 1 when all parameters or system parameters are restored. User should change the remoter address to be 1 (press No.1 according to the camera so to get normal operation) Hall Technologies February 9, 2022 Page 14 of 17...
-
Page 15: Maintenance And Troubleshooting
Check whether the video output cable or video display is normal f. Check whether the camera is properly recognized by the PC 2. No image sometimes a. Check the USB cable quality and that it is connected well. Hall Technologies February 9, 2022 Page 15 of 17... -
Page 16: Copyright Statement
Product specification and information in this manual is for reference only and subject to change without notice. All rights reserved. No reproducing is allowed without acknowledgement. Hall Technologies February 9, 2022 Page 16 of 17... - Page 17 © Copyright 2022. Hall Technologies All rights reserved. 1234 Lakeshore Drive, Suite #150 Coppell, TX 75019 halltechav.com / support@halltechav.com (714)641-6607 Hall Technologies February 9, 2022 Page 17 of 17...
