MOUNTING REQUIREMENTS

2-M4
PC CONFIGURATOR
The following parameter items can be configured with the PC configurator software (model: R7CFG).
Refer to the users manual of the software for detailed operations.
■ INTERFACE SETTING
PARAMETER
Communication Timeout

DATA ALLOCATION

'Begin' address is determined by the R7F4DD's node address and the master setting.
■ Without status
15 Output data
Begin + 0 Unused
■ With status
15 Output data
Begin + 0 Unused
+1 Status
unit: mm [inch]
125 [4.92]

SETTING RANGE

0 – 32767 (0.1 sec.)
0
R7F4DD-DAC16C
0
R7F4DD-DAC16C
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
10 (0.1 sec.)
15 Input data
Begin + 0 Unused
15 Input data
Begin + 0 Unused
R7F4DD-DAC16C-C
DEFAULT SETTING
0
R7F4DD-DAC16C
0
R7F4DD-DAC16C
EM-8007-E P. 6 / 8
