Summary of Contents for Subject Link RPT-1008G-X2
- Page 1 Industrial Unmanaged Ethernet Switch Hardware User Manual RPT-1008G(-T)-X2 Version 1.0.0 Subject Link Inc 9F-1, No. 77, Sec 4., Nangjing E. Rd, Taipei City, 10580, Taiwan, R.O.C. Tel: +886 935 672 398 Mail: sales@sbjlink.com Web: www.sbjlink.com...
-
Page 2: Table Of Contents
Contents Overview ................................1 Package Check List ...........................1 Hardware Description ..........................2 Front Panel Instruction ..........................2 Dimensions ..............................2 Top View ..............................3 LED Instruction ............................3 Earth Grounding ............................3 Hardware Installation ...........................4 Wiring Power Inputs ..........................4 Wiring Fault Alarm ...........................4 Double-Secure Power Input Fault Alarm ..................4 Mounting ..............................5... -
Page 3: Overview
Overview This user manual is for "RPT-1008G(-T)-X2" with extended operating temperature (-40°C ~ 75°C (-40°F ~ 167°F)). This is an industrial unmanaged gigabit Ethernet switch with the following hardware features: Interface ▪ MDI/MDI-X function supported on all copper ports ▪ Embedded 8x Gigabit Ethernet ports ▪... -
Page 4: Hardware Description
Hardware Description RONT ANEL NSTRUCTION The following picture is the front panel for "RPT-1008G(-T)-X2". IMENSIONS WxHxD: 29x140x98 mm... -
Page 5: Top View
This is the top view of the RPT-1008G(-T) containing the ground, power inputs, fault alarm relay. LED I NSTRUCTION System LEDs Color Status Description Power is supplied on the power input 1. PWR1 Green Power is not supplied on the power input 1. Power is supplied on the power input 2. -
Page 6: Hardware Installation
Hardware Installation IRING OWER NPUTS Insert the positive and negative wires into the PWR1 (+,-) and PWR2 (+,-) on the 6-contact terminal block connector. Tighten the screws to prevent the wires from loosening. IRING AULT LARM Insert the wires into the left two contacts of the 6-contact terminal block (Fault Alarm Relay). -
Page 7: Mounting
OUNTING Din-Rail Mounting Screw the DIN-Rail bracket to the switch. Insert the top of the DIN-Rail bracket to the DIN- Rail track. Pull down the DIN-Rail bracket to the DIN-Rail track and check if it is mounted tightly on the DIN- Rail track. -
Page 8: Installation Steps
NSTALLATION TEPS Unpack The switch is well packed and shipped to our customers. Unpack it from the box. Check Content Items Please make sure all the items listed in the "Package Check List" are in the box. Mounting The DIN-Rail is screwed on the switch by default. If the DIN-Rail is not screwed to the switch, refer to the "DIN-Rail Mounting"... -
Page 9: Specification
Specification Technology IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX Standards IEEE 802.3ab 1000BaseT IEEE 802.3x Flow Control Processing Type Store and Forward 14,880pps for Ethernet port Transfer Rate 148,800pps for fast Ethernet port 1,488,000pps for gigabit Ethernet port Transmission Distance Up to 100M (Fast Ethernet) Transmission Speed Up to 1000Mbps Switch Properties... - Page 10 Protection Overload Current Protected, Reverse Polarity Protected Mechanical Construction Enclosure Steel metal Protection Class IP30 Dimensions 29x140x98 mm (WxHxD) Weight 0.75 kg Mounting DIN-Rail Mounting Environmental Limits Operating Temperature Extended: -40°C ~ 75°C (-40°F ~ 167°F) Storage Temperature -40°C ~ 85°C Ambient Relative 5 to 95%, (Non-Condensing)
