Industrial Managed Ethernet Switch Hardware User Manual
RPT-2010G-2F(-T)-X2
Quick Installation Guide
Version 1.0.0
Subject Link Inc
9F-1, No. 77, Sec 4., Nangjing E. Rd, Taipei City, 10580, Taiwan, R.O.C.
Tel: +886 935 672 398
Mail:
sales@sbjlink.com
Web: www.sbjlink.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RPT-2010G-2F and is the answer not in the manual?

Questions and answers

Summary of Contents for Subject Link RPT-2010G-2F

  • Page 1 Industrial Managed Ethernet Switch Hardware User Manual RPT-2010G-2F(-T)-X2 Quick Installation Guide Version 1.0.0 Subject Link Inc 9F-1, No. 77, Sec 4., Nangjing E. Rd, Taipei City, 10580, Taiwan, R.O.C. Tel: +886 935 672 398 Mail: sales@sbjlink.com Web: www.sbjlink.com...
  • Page 2: Table Of Contents

    Contents Overview ..............................1 Package Check List ..........................1 Hardware Description ..........................2 Front Panel Instruction ........................2 Dimensions ............................2 Top View ..............................3 LED Instruction .............................3 Reset Button ............................4 USB Port ..............................4 Earth Grounding ..........................4 Hardware Installation ..........................5 SFP Cabling ............................5 Wiring Power Inputs ..........................7 Wiring Fault Alarm ..........................7...
  • Page 3: Overview

    DIN-Rail Mounting, Optional Wall Mounting ACKAGE HECK The "RPT-2010G-2F (-T)" is shipped with the following items. Ensure that all the items are in the box. If any item is missing or damaged, contact us for assistance. ▪ RPT-2010G-2F/RPT-2010G-2F-T switch x 1 ▪...
  • Page 4: Hardware Description

    Hardware Description RONT ANEL NSTRUCTION The following picture is the front panel for "RPT-2010G-2F(-T)". IMENSIONS WxHxD: 72x145x118 mm...
  • Page 5: Top View

    This is the top view of the RPT-2010G-2F(-T) containing the ground, power inputs, and fault alarm relay. LED I NSTRUCTION System LEDs Color Status Description Power is supplied on the power input 1. PWR1 Green Power is not supplied on the power input 1.
  • Page 6: Reset Button

    ESET UTTON A multifunctional reset button is provided. Use a pointed object such as toothpick or paper clip (straightened) to press the reset button. Continuous Action Seconds Save the running configuration to the USB device named "running-config". Reboot the system. More than 7 Reset the system to factory default and reboot it.
  • Page 7: Hardware Installation

    SFP C ABLING There are 2x 1000 SFP Slot SFP Slots on the "RPT-2010G-2F(-T)" switch. The 100Tx SFP module is not supported in this model. The following table is the SFP modules that is recommend to the users. Part No.
  • Page 8 Insert SFP Module Insert the SFP module. A triangle is available on the switch and SFP module. Push the SFP module down. Remove SFP Module Press and remove the SFP cable. Open the SFP module and remove it.
  • Page 9: Wiring Power Inputs

    IRING OWER NPUTS Insert the positive and negative wires into the PWR1 (+,-) and PWR2 (+,-) on the 4-contact terminal block connector. Tighten the screws to prevent the wires from loosening. IRING AULT LARM Insert the wires into the left two contacts of the 4-contact terminal block (Fault Alarm Relay).
  • Page 10: Double-Secure Power Input Fault Alarm

    OUBLE ECURE OWER NPUT AULT LARM The power inputs are designed as a "common negative", which implies that the negative input is connected, but "double-secure" is supported to prevent the unnotified failure of power from one of the negative inputs. Should one of the negative power inputs fail, the system will detect the failure.
  • Page 11: Mounting

    OUNTING Din-Rail Mounting Screw the DIN-Rail bracket to the switch. Insert the top of the DIN-Rail bracket to the DIN-Rail track. Pull down the DIN-Rail bracket to the DIN-Rail track and check if it is mounted tightly on the DIN- Rail track.
  • Page 12: Installation Steps

    NSTALLATION TEPS Unpack The switch is well packed and shipped to our customers. Unpack it from the box. Check Content Items Please make sure all the items listed in the "Package Check List" are in the box. Mounting The DIN-Rail is screwed on the switch by default. If the DIN-Rail is not screwed to the switch, refer to the "DIN-Rail Mounting"...
  • Page 13: Specification

    Specification Technology IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX IEEE 802.3ab 1000BaseT IEEE 802.3z 1000BaseX IEEE 802.3x Flow Control IEEE 802.3az Energy-Efficient Ethernet IEEE 802.3ad/802.1AX LACP IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid STP Standards IEEE 802.1s Multiple STP ITU-T G.8032 / Y.1344 ERPS IEC 62439-2 Media Redundancy Protocol IEEE 802.1Q VLAN Tagging IEEE 802.1ad Stacked VLANs...
  • Page 14 ACL Group Interface 8x 10/100/1000T(x), auto negotiation speed duplex mode, auto RJ45 Port MDI/MDI-X Fiber Port 2x 1000F(x) SFP Slot Per unit: PWR1, PWR2, Fault, Ring Master, Ring State LED Indicators Ports: Link/Active with highest speed(Green), low speed(Amber) Alarm Contact 1x relay output with current carrying capacity of 1A @ 24 VDC 1x isolated input from the electronics.
  • Page 15 UL 60950-1/62368 (Pending) IEC 61000-6-2 Certifications IEC 61000-6-4 EN 50121-4 MTBF >100,000 hours Warranty 5 Years Subject Link Inc 9F-1, No. 77, Sec 4., Nangjing E. Rd, Taipei City, 10580, Taiwan, R.O.C. Tel: +886 935 672 398 Mail: sales@sbjlink.com Web: www.sbjlink.com...
