- Page 1 Industrial Managed Ethernet Switch Hardware User Manual RPT-2012G/GP-4F-T Quick Installation Guide Version 1.0.0 Subject Link Inc 9F-1, No. 77, Sec 4., Nangjing E. Rd, Taipei City, 10580, Taiwan, R.O.C. Tel: +886 935 672 398 Mail: sales@sbjlink.com Web: www.sbjlink.com...
-
Page 2: Table Of Contents
Contents Overview ................................1 Package Check List ...........................1 Hardware Description ..........................2 Front Panel Instruction ..........................2 Dimensions ..............................2 Top View ..............................3 LED Instruction ............................3 Reset Button ...............................4 USB Port ...............................4 Earth Grounding ............................4 Hardware Installation ...........................5 SFP Cabling ......................... 錯誤! 尚未定義書籤。 Wiring Power Inputs ..........................6 Wiring Fault Alarm ...........................6... -
Page 3: Overview
Overview This user manual is for "RPT-2012G" and "RPT-2012G-T", where "-T" refers to the extended temperature (-40°C ~ 75°C (-40°F ~ 167°F)) that is supported. This is an industrial managed gigabit PoE+ Ethernet switch with the following hardware features: Interface ▪... -
Page 4: Hardware Description
Hardware Description RONT ANEL NSTRUCTION The following picture is the front panel for "RPT-2012GP-4F(-T)". IMENSIONS WxHxD: 72x145x118 mm... -
Page 5: Top View
This is the top view of the RPT-2012GP-4F(-T) containing the ground, power inputs, and fault alarm relay. LED I NSTRUCTION System LEDs Color Status Description Power is supplied on the power input 1. PWR1 Green Power is not supplied on the power input 1. Power is supplied on the power input 2. -
Page 6: Reset Button
An IEEE 802.3at/af powered device is connected. PoE+ Amber Flashing PoE overload or power budget exceeded. P1 to P8 No IEEE 802.3at/af powered device is connected. ESET UTTON A multifunctional reset button is provided. Use a pointed object such as toothpick or paper clip (straightened) to press the reset button. -
Page 7: Hardware Installation
Hardware Installation Insert SFP Module Insert the SFP module. A triangle is available on the switch and SFP module. Push the SFP module down. Remove SFP Module Press and remove the SFP cable. Open the SFP module and remove it. -
Page 8: Wiring Power Inputs
IRING OWER NPUTS Insert the positive and negative wires into the PWR1 (+,-) and PWR2 (+,-) on the 4-contact terminal block connector. Tighten the screws to prevent the wires from loosening. IRING AULT LARM Insert the wires into the left two contacts of the 4-contact terminal block (Fault Alarm Relay). -
Page 9: Double-Secure Power Input Fault Alarm
OUBLE ECURE OWER NPUT AULT LARM The power inputs are designed as a "common negative", which implies that the negative input is connected, but "double-secure" is supported to prevent the unnotified failure of power from one of the negative inputs. Should one of the negative power inputs fail, the system will detect the failure. -
Page 10: Mounting
OUNTING Din-Rail Mounting Screw the DIN-Rail bracket to the switch. Insert the top of the DIN-Rail bracket to the DIN-Rail track. Pull down the DIN-Rail bracket to the DIN-Rail track and check if it is mounted tightly on the DIN- Rail track. -
Page 11: Installation Steps
NSTALLATION TEPS Unpack The switch is well packed and shipped to our customers. Unpack it from the box. Check Content Items Please make sure all the items listed in the "Package Check List" are in the box. Mounting The DIN-Rail is screwed on the switch by default. If the DIN-Rail is not screwed to the switch, refer to the "DIN-Rail Mounting"... -
Page 12: Specification
Specification Technology IEEE 802.3 10BaseT IEEE 802.3u 100BaseTX IEEE 802.3ab 1000BaseT IEEE 802.3z 1000BaseX IEEE 802.3x Flow Control IEEE 802.3af Power over Ethernet IEEE 802.3at PoE+ IEEE 802.3ad/802.1AX LACP IEEE 802.1D Spanning Tree Protocol Standards IEEE 802.1w Rapid STP IEEE 802.1s Multiple STP ITU-T G.8032 / Y.1344 ERPS IEEE 802.1Q VLAN Tagging IEEE 802.1ad Stacked VLANs... - Page 13 ACL Group VLAN IP Entries Routing Entries 512/256 host, 64/64 LPM (IPv4/IPv6) Interface 8x 10/100/1000T(x) with PoE+, auto negotiation speed duplex mode, RJ45 Port auto MDI/MDI-X Fiber Port 4x 1000F(x) SFP Slot PoE Pin Out V+, V+, V-, V-, for pin 1, 2, 3, 6, Endspan, MDI Mode A Per unit: PWR1, PWR2, Fault, Ring Master, Ring State LED Indicators Ports: Link/Active with highest speed(Green), low speed(Amber)
- Page 14 Enclosure Aluminum Protection Class IP30 Dimensions 72x145x118 mm (WxHxD) Weight 0.90 kg Mounting DIN-Rail Mounting, Optional Wall Mounting Kits Environmental Limits Standard: -10°C ~ 60°C (14°F ~ 140°F) Operating Temperature Extended: -40°C ~ 75°C (-40°F ~ 167°F) Storage Temperature -40°C ~ 85°C (-40°F ~ 185°F) Ambient Relative 5 to 95%, (Non-Condensing)
