NEC PlasmaSync 42XR4 Specifications page 2

Showcase series digital plasma displays
Hide thumbs


Advertisement

42XR4 40.2" (1022mm)
50XR5 48.3" (1226mm)
61XR4 58.1" (1476mm)
42XR4 36.1" (918mm)
50XR5 43.5" (1106mm)
61XR4 53.2" (1351mm)
42XR4 20.4" (518mm)
50XR5 24.5" (622mm)
61XR4 29.9" (760mm)
*42XR4 input panel located at the bottom of the unit.
UNIQUE FEATURES
Advanced AccuBlend
Ensures detailed images when non-native resolution
sources are connected to the projector.
Phosphor Protection
6 modes - A comprehensive set of built-in modes
protects your screen from image retention.
Enhanced Mass Area Superior Eliminates jagged lines, removes color separation
Sampling (Enhanced MASS)
and improves detail for crystal clear images.
Capsulated Color Filter™
CCF delivers realistic color reproduction creating the
(CCF) technology
greatest color space when plotted on the C.I.E.
Chromaticity chart. (50XR5, 61XR4)
AccuCrimson™ Filter
Further enhances the effects of the CCF producing
technology
better reds and greens. (50XR5, 61XR4)
Color Tune Technology
Adjust individual colors without affecting white balance.
Gamma 12
Provides the highest color processing in a plasma display
at 68.7 billion colors (4096 steps) resulting in increased
detail never seen before... no matter what the viewing
environment!
Crystal Clear Panel/Drive
Provides technology to improve brightness 130% and
contrast 100% over previous models and also removes
false contouring (42XR4 only).
Bonded Color Filter
Improves color, bright room contrast and sharpness
while reducing the multiple image reflections possible
with traditional filter technologies (42XR4 only).
Enhanced Split Screen
Yes
Closed captioning
Yes
composite video
VCR, video camera,
component
game system, DVD
DVD, satellite/ cable/
HDTV, game system
S-Video
high end VCR, video
camera, game system,
laser disc, low end DVD
For more information, call 1.800.NEC.INFO
or visit www.necvisualsystems.com
NEC is a registered trademark of NEC Corporation.
All other trademarks are the property of their respective owners.
All specifications subject to change without notice.
NEC Solutions (America), Inc.
Visual Systems Division
1250 Arlington Heights Rd., Suite 400
Itasca, IL 60143-1248
NEC 100519
42XR4 3.9" (98mm)
50XR5 3.9" (99mm)
61XR4 4.8" (123mm)
*
42XR4 24.0" (610mm)
50XR5 29.0" (736mm)
61XR4 34.6" (880mm)
HDMI
satellite/cable/HDTV, high end
DVD, video processor/scaler
RGB
PC, video processor/scaler,
satellite/cable/HDTV
Showcase Series
42XR4, 50XR5 and 61XR4 digital plasma displays.
PLASMA MODULE
Screen Size (Diagonal)
PX-42XR4A
PX-50XR5A
PX-61XR4A
Screen Aspect Ratio
16 to 9
Active Screen Area
PX-42XR4A
PX-50XR5A
PX-61XR4A
Native Resolution
PX-42XR4A
PX-50XR5A
PX-61XR4A
Pixel Pitch
PX-42XR4A
PX-50XR5A
PX-61XR4A
Color Processing
68.7 billion colors, 4096 levels
Viewing Angle
160°
Half Life
60,000 hours
Filter Type
Anti-reflective
SIGNAL COMPATIBILITY/CONNECTIVITY
Scan Rate
Horizontal
Vertical
Supported Video Standards
PAL, SECAM, 3.58/4.43 NTSC, ATSC
SD/HD Video Signal
480i, 480p, 525i, 525p, 540p, 625i, 625p, 720p, 1035i, 1080i,1080p
Compatibility
PC Signal Compatibility
VGA, SVGA, XGA, SXGA, UXGA, WideVGA (848x480, 852x480), WideXGA (1360x768)
Macintosh Compatibility
Yes
Input/Output Terminals
RGB
Video 1
Video 2
HD Video 1
HD Video 2
HD Video 3
HD Video 4
Audio
Audio
Internal amplifier, 8W x 2 output power (42XR4), 9W X 2 output power (50XR5 & 61XR4)
External Control
RS232, IR (IR loopthrough)
ELECTRICAL
Power Requirements
120-240V 50/60 Hz
Power Consumption
PX-42XR4A
PX-50XR5A
PX-61XR4A
Standby Power
0.9W
MECHANICAL
Dimensions (WxHxD)
PX-42XR4A
PX-50XR5A
PX-61XR4A
Net Weight
PX-42XR4A
PX-50XR5A
PX-61XR4A
Regulations
Regulatory FCC Classs B, UL6500, CSA60065
Fan Noise
PX-42XR4A
PX-50XR5A
PX-61XR4A
ENVIRONMENTAL
Operating Temperature
32°- 104° F (0° - 40° C)
Operating Humidity
20 - 80%
Operating Altitude
0 - 9180 feet (0 - 2800m)
Storage Temperature
14 - 122° F (-10 - 50° C)
Storage Humidity
10 - 90%
Storage Altitude
0 to 9840 feet (0 - 3000m)
WARRANTY
3 Years Parts & Labor/1 year plasma module
IN THE BOX
AC Power Cord, User Manual, Remote Control, Batteries, Cable Clamps
ACCESSORIES
PX-SP2U/S
Silver Speakers for 42XR4, 50XR5 and 61XR4
PX-SP2U/B
Black Speakers for 42XR4, 50XR5 and 61XR4
PX-ST2U
42" and 50" Tabletop Swivel Stand
PX-61ST2U
61" Tabletop Stand
PX-CV2U
Terminal cover for 50XR5 and 61XR4
4250WMK
Fixed and Tilt wall mount for 42XR and 50XR models
61WMK
Fixed and Tilt wall mount for 61XR
TM
42"
50"
61"
36.1 x 20.4 in, 918 x 518 mm
43.5 x 24.5 in, 1106 x 622 mm
53.2 x 29.9 in, 1351 x 760 mm
XGA 1024 x 768
WXGA 1365 x 768
WXGA 1365 x 768
0.900mm x 0.671mm
0.81mm x 0.81mm
0.99mm x 0.99mm
15.5 to 110.0 kHz auto, step scan
51 to120 Hz auto, step scan
15-pin mini D-sub
Composite RCA x 1
S-Video 4-Pin DIN
1 set RCA Component (Y,Pb,Pr/Y,Cb,Cr)
1 set RCA Component (Y,Pb,Pr/Y,Cb,Cr)
Digital HDMI with HDCP
Digital HDMI with HDCP
3 sets RCA stereo + external speaker jacks
285W Typical
435W Typical
540W Typical
40.2 x 24.0 x 3.9 in, 1022 x 610 x 98mm
48.3 x 29.0 x 3.9 in, 1226 x 736 x 99mm
58.1 x 34.6 x 4.8 in, 1476 x 880 x 123mm
59.5 lbs., 27.6 kg
97.9 lbs., 44.5 kg
134.2 lbs., 61.0 kg
20dB
20dB
22dB
